2014 Cadillac CTS V-Sport

United StatesGasolineRWDSedan

Photos

Specifications

Vehicle Details

Year
2014
Make
Cadillac
Model
CTS
Variant
V-Sport
Body Style
Sedan
Generation
3rd Generation
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic (Electrohydraulic), 8-speed

Powertrain

Engine Name
V-Sport 3.6 V6 TT Automatic
Engine Configuration
V
Power (hp)
426 hp
Power (kW)
313 kW
Torque
583 Nm (430 lb-ft)
Displacement
3,564 cc

Dimensions

Length
4,966 mm (195.5 in)
Width
1,833 mm (72.2 in)
Height
1,454 mm (57.2 in)
Wheelbase
2,910 mm (114.6 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,750 rpm
Rev. at Max Torque
3,500 - 4,500 rpm
Redline
6,500 rpm
Engine Fluids
Engine Oil, Volume
6.6 litres
Engine Coolant, Volume
12.8 litres
Engine Configuration
Bore
94 mm (3.7 in)
Stroke
85.6 mm (3.4 in)
Compression Ratio
10.2 :1
Engine Configuration
V-Engine
Turbocharger
Twin-turbo
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
72,000 km / 4 years
Spark Plug
96,000 km (59,652 mi)
Brake Fluid
240,000 km / 10 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Transmission, Fluid
156,000 km (96,934 mi)
Transmission, Fluid Filter
156,000 km (96,934 mi)
Rear Axle, Oil
156,000 km (96,934 mi)
Interior Filter
36,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 8-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.6 :1
2nd Gear
2.72 :1
3rd Gear
1.86 :1
4th Gear
1.46 :1
5th Gear
1.23 :1
6th Gear
1 :1
7th Gear
0.82 :1
8th Gear
0.69 :1
Final Drive
2.85 :1
Reverse
4.06 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
321 - 345 mm (12.6 - 13.6 in)
Cooling
Ventilated
Rear Brakes
Diameter
315 mm (12.4 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Electronic Damper Control (EDC)
Yes
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
72 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption EPA
City
17 MPG
Highway
25 MPG

Dimensions & Weight

Exterior

Track, Front
1,560 mm (61.4 in)
Track, Rear
1,568 mm (61.7 in)
Turning Circle
11.3 - 11.5 m

Interior

Head Room, Front
995 mm (39.2 in)
Head Room, Rear
952 mm (37.5 in)
Leg Room, Front
1,081 mm (42.6 in)
Leg Room, Rear
899 mm (35.4 in)
Hip Room, Front
1,366 mm (53.8 in)
Hip Room, Rear
1,353 mm (53.3 in)
Shoulder Room, Front
1,446 mm (56.9 in)
Shoulder Room, Rear
1,392 mm (54.8 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Alpha Platform

Equipment

Other Equipment
Normal Roof
Yes

Interior

Seats

Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40

Trunk

Rear Trunk
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
447 litres
