2014 Chevrolet Camaro ZL1

United States Gasoline RWD Convertible

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2014
Make: Chevrolet
Model: Camaro
Variant: ZL1

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2014
Make: Chevrolet
Model: Camaro
Variant: ZL1

Body Style

Convertible

Generation

5th Generation Facelift

Seats

4

Doors

2

Fuel

Gasoline

Drivetrain

RWD

Transmission

Automatic
Manual, 6-speed

Powertrain

Engine Name: ZL1 Convertible
Engine Configuration: V
Power (hp): 587 hp
Power (kW): 432 kW
Torque: 754 Nm (556 lb-ft)
Top speed: 250 km/h (155 mph)
0–60 mph: 4.1 seconds
0–100 km/h: 4.3 seconds
Displacement

Dimensions

Length: 4,841 mm (190.6 in)
Width: 1,918 mm (75.5 in)
Height: 1,376 mm (54.2 in)
Wheelbase: 2,852 mm (112.3 in)
Curb weight: 1,987 kg (4,381 lb)

Engine & Performance

Engine

Engine Specification

Rev. at Max Power: 6,000 rpm
Rev. at Max Torque: 4,200 rpm
Redline: 6,200 rpm

Engine Fluids

Synthetic Oil (viscosity): 5W-30
5W-40
10W-30
10W-40
Semi-synthetic Oil (viscosity)

Similar convertibles

Suggested vehicles

View all

2014 Roush Mustang Stage

6,162 cc

5W-30
5W-40
10W-30
10W-40
10W-50
15W-40
20W-40
20W-50

Engine Oil, Volume

4.7 litres

Car Battery

Voltage: 12 V
Battery Capacity: 80 Ah
Cold Start Power: 800 A
Alternator Charge Current: 150 A
Alternator Voltage: 12 V

Engine Configuration

Bore: 103.25 mm (4.1 in)
Stroke: 92 mm (3.6 in)
Compression Ratio: 9.1 :1
Engine Configuration: V-Engine
Supercharger: Yes
Synchronization: Timing Chain
Engine Placement: Front
Engine Mount: Longitudinally
Type of Combustion Engine

Transmission & Drivetrain

Transmission: Automatic
Manual, 6-speed

Gear Ratio

1st Gear: 2.66 :1
2nd Gear: 1.78 :1
3rd Gear: 1.3 :1
4th Gear: 1 :1
5th Gear: 0.8 :1
6th Gear

Brakes

Parking Brake

Manual: Lever

Parking Brake › Manual

Material: Plastic

Front Brakes: Disc Brakes
Rear Brakes: Disc Brakes
Brakes Material: Aluminium

Front Brakes

Suspensions

Spring, Front: Coil
Spring, Rear: Coil
Anti-roll Bar: Rear

Suspension, Front

Independent: Multi-link

Suspension, Rear

Independent: Multi-link

Fuel

General

Tank Volume: 72 litres

General › Fuel Cap Position

Rear: Right

Emission

Emission Standard: Euro 5
Emission Class: G

Fuel Consumption NEDC

City

Performance

Braking

100-0 km/h: 38.4 m

Quarter Mile: 12.4 sec
Drag Coefficient: 0.37

Dimensions & Weight

Exterior

Track, Front: 1,618 mm (63.7 in)
Track, Rear: 1,618 mm (63.7 in)
Turning Circle: 11.5 m
Ground Clearance: 102 mm (4.0 in)

Interior

Exterior

Chassis & Body

Chassis

Chassis: Cabriolet Soft-top
Pillars: A

Doors

Front Doors: Conventional
Door Handles: Pull-out

Platform

Interior

Equipment

Instrument Cluster

Trip Computer: Yes
Head-up Display (HUD): Yes
Speedometer: Analogue
Tachometer: Analogue
Fuel Gauge: Analogue

Instrument Cluster › Trip Computer

Features

Comfort Features

Keyless Entry: Yes
Keyless Start: Optional
Remote Engine Start: Optional
Cruise Control: Yes
Cameras: Rear

Other Features

Safety & Security

Airbags

Total Number of Airbags: 8

Feature

Driver

Passenger

Rear

Frontal Airbag

DriverYes

Other

Identification

VIN Location

Left Side Casing of Window: Yes
Pillar: B-Pillar, Left

Car Classification

American Classification: Convertible
British Classification: Convertible
Australian Classification

Piston

Fuel System

Electronic Fuel Injection

Camshaft Type

OHC

Engine Block

Aluminium

Engine Heads

Aluminium

Engine Cooling

Liquid Cooling

0.63 :1

Final Drive

3.73 :1

Reverse

2.9 :1

Diameter

370 mm (14.6 in)

Width

30 mm (1.2 in)

Cooling

Ventilated

Rear Brakes

Diameter: 365 mm (14.4 in)
Width: 28 mm (1.1 in)
Cooling: Ventilated

16.8 – 19.6 litres / 100 km

Highway

12.4 – 13.1 litres / 100 km

Combined

14.7 – 16.8 litres / 100 km

Fuel Consumption EPA

City: 12 – 14 MPG
Highway: 18 – 19 MPG
Combined: 14 – 16 MPG

Emission NEDC

CO₂, Combined: 286 – 351 g/km

Head Room, Front

960 mm (37.8 in)

Head Room, Rear

907 mm (35.7 in)

Leg Room, Front

1,077 mm (42.4 in)

Leg Room, Rear

759 mm (29.9 in)

Shoulder Room, Front

1,445 mm (56.9 in)

Shoulder Room, Rear

1,080 mm (42.5 in)

Weight

Max Roof Load: 0 kg (0 lb)
Weight Distribution, front: 52 %
Weight Distribution, rear: 48 %

General Motors Platforms

Zeta Platform

Equipment

Side Mirrors

Mirror Type: Conventional
Adjustments: Electrical
Automatic Anti-glare: Driver side
Heated: Yes
Turning Signal: Optional
House Colour: Same as Car
Mirror Shape, Driver side: Flat
Mirror Shape, Passenger side

Lights

Main Beam: Xenon
Low Beam: Xenon
Rear Lights: Halogen
Daytime Running Light: LED
Fog Lights: Yes

Fog Lights

Front: Yes

Rims & Tires

Tire Pressure Monitoring System (TPMS): Yes
Number of Bolts: 5 pcs
Bolt Distance: 120
Nut/Bolt Dimensions: M14x1.5
Central Bore (CB), front: 67.1
Fastening Type: Lug Nuts
Tightening Torque: 190 Nm
Rim Material: Alloy

Display

Yes

Climate Control

Climate Control: Manual
Number of Climate Zones: 1
Air Condition: Yes
Micro Filter: Yes
Number of Vents, Front: 7 pcs
Number of Vents, Rear: 7 pcs

Connectivity

Radio: AM
FM
XM
Media Inputs: USB
Bluetooth: Yes

Connectivity › Media Inputs

AUX: Yes

Displays

Center Display: 7"
Center Display Controls: Touchscreen

Speakers

Total Number of Speakers: 9 pcs

Rear-view Mirror

Anti-glare: Automatic

Interior Storage › Storage Compartments

Glove Compartment: Cooled
Total Number of Compartments: 4 pcs

Interior Storage

Cup Holders: Yes

Interior Storage › Cup Holders

Front: 2

Lights

Read Light: Front
Rear

Other Equipment

12V Outlet: Front

Steering Wheel

Multifunction Steering Wheel: Yes
Power Steering: Yes
Adjustments: Tilt
Telescope
Material: Leather
Colour: Black
Steering Ratio: 16 :1
Answer Phone: Yes
Volume: Yes

Trunk

Rear Trunk: Yes

Rear Trunk

Volume: 308 litres
Volume (Roof Folded): 289 litres

Design

Interior Decor Material: Leather
Interior Decor Colour: Black
Transmission Knob Material: Leather
Colour: Red

Seats

Colour & Material

Upholstery: Leather
Suede Microfiber
Seat Colour: Black

Front Seats › Adjustments, Driver

Seat Depth: Yes
Seat Height: Yes
Cushion Tilt: Yes
Backrest Angle: Yes
Headrest, Height

GPS

Optional

Passenger

Yes

Rear-

Side Chest Airbag

DriverYes

PassengerYes

Rear-

Side Head Airbag

DriverYes

PassengerYes

Rear-

Curtain Airbag

DriverYes

PassengerYes

RearYes

Airbag cut-off Switch

Driver-

PassengerYes

Rear-

Seat Belt

Type of Belt

Three-Point-Belt: Yes

Feature

Driver

Passenger

Rear

Seat Belt Reminder

DriverYes

PassengerYes

Rear

Assist Systems

Electronic Stability Control (ESC): Yes

Brake Systems

Anti-lock Braking System (ABS): Yes
Traction Control System (TCS): Yes
Electronic Brake Assist (BA/EBA): Yes

Sensors

Parking Sensors: Rear
Light Sensor: Yes

Other Features

Immobiliser: Yes
Anti-theft Alarm: Yes
Central Locking: Yes
Emergency Call: Yes

Safety Testing

General

Not Tested by Euro NCAP: Yes

Child Protection

Isofix: Passenger: -
Rear: Yes

Sports Car

European Segment

S-Segment

Car.info Classification

Sports Car

UNECE Category

M1

ACRISS

Type: Roadster (N)

Camaro

8.9

€67,000

MSRP · EUR

Body

Convex

Windscreen Wipers

Windscreen Wipers: Connector type, Front: Hook
Number of Windscreen Wipers, Front: 2

Windows

Window Lifts, Front: Powered
Heated Windows: Rear

Other Equipment

Spoiler: Fixed
Antenna: Shark Fin
Whip
Air Intakes: 1-port
Number of Exhaust Pipes: 2

Mute Audio

Yes

Front Seats

Power Seat, Driver: Yes
Power Seat, Passenger: Yes
Heated Seats: Yes
Armrest: Yes
Type of Seat: Sport Seats

Front Seats › Heated Seats

Areas: Cushion

Second Seat Row

Number of Seats: 2

-

Belt Pretensioner

DriverYes

PassengerYes

Rear-

Convertible
