2014 Honda Civic

JapanDieselFWDHatchback

Photos

Specifications

Vehicle Details

Year
2014
Make
Honda
Model
Civic
Body Style
Hatchback
Generation
9th Generation
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
FWD
Transmission
Manual, 6-speed

Powertrain

Engine Name
2.2 i-DTEC Manual
Engine Configuration
Inline
Power (hp)
150 hp
Power (kW)
110 kW
Torque
350 Nm (258 lb-ft)
Top speed
217 km/h (135 mph)
0–60 mph
8.1 seconds (estimated)
0–100 km/h
8.5 seconds
Displacement
2,199 cc

Dimensions

Length
4,300 mm (169.3 in)
Width
1,770 mm (69.7 in)
Height
1,470 mm (57.9 in)
Wheelbase
2,595 mm (102.2 in)
Curb weight
1,338 kg (2,950 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,000 rpm
Rev. at Max Torque
2,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 5W-30
Engine Oil, Volume
5.5 litres
Engine Configuration
Bore
85 mm (3.3 in)
Stroke
96.9 mm (3.8 in)
Compression Ratio
16.3 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Oil Change & Engine Filter
20,000 km / 1 years

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
50 litres
Emission
Emission Standard
Euro 5
Emission Class
A
Emission Control
Particle Filter
Fuel Consumption NEDC
City
5.1 litres / 100 km
Highway
3.7 litres / 100 km
Combined
4.2 litres / 100 km
Emission NEDC
CO₂, Combined
110 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,065 mm (81.3 in)
Track, Front
1,535 mm (60.4 in)
Track, Rear
1,540 mm (60.6 in)
Turning Circle
11.3 m
Ground Clearance
135 - 140 mm (5.3 - 5.5 in)

Interior

Head Room, Front
995 mm (39.2 in)

Weight

Gross Weight
1,910 kg (4,211 lb)
Max Trailer Load, braked 12%
1,500 kg (3,307 lb)
Max Trailer Load, unbraked
500 kg (1,102 lb)
Cargo Capacity
572 kg (1,261 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C

Equipment

Side Mirrors
Mirror Type
Conventional
Heated
Optional
Turning Signal
Yes
House Colour
Same as Car
Mirror Shape, Driver side
Aspheric
Windscreen Wipers
Rear Wiper
Optional
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Antenna
Optional

Lights

Daytime Running Light
LED
Fog Lights
Yes
Fog Lights
Rear
Yes
Main Beam Assist
Optional
Headlight Washers
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
64.1
Fastening Type
Lug Nuts
Tightening Torque
108 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Optional
Pollen Filter
Optional
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
Optional
App-Connect
Optional
Bluetooth
Optional
Connectivity › Radio
CD
Optional
MP3
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Connectivity › Bluetooth
Phone
Optional
Displays
Center Display
6.1 - 6.5"
Displays › Center Display
Touchscreen
Optional
Speakers
Subwoofer
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Back Pocket
Optional
Sunglass Compartment
Optional
Under Seats
Rear
Interior Storage › Storage Compartments › Glove Compartment
Light
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Lights
Read Light
Optional
Guide Light
Yes
Lights › Read Light
Front
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front
Carpets
Yes
Other Equipment › Make-up Mirror
Make-up Light
Optional
Other Equipment › 12V Outlet
Rear
Optional
Trunk
Optional

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope

Trunk

Rear Trunk
Yes
Cover
Optional
Cargo Hooks
Yes
Second Trunk Compartment
Optional
Light
Yes
Rear Trunk
Volume
477 litres
Volume, Back Seat Collapsed
1,210 litres
Depth
800 mm (31.5 in)
Depth, Back Seat Collapsed
1,600 mm (63.0 in)
Width
1,050 mm (41.3 in)
Height
820 mm (32.3 in)
Cover
Foldable
Optional

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Yes
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Second Seat Row
Collapsible
Manual
Height Adjustment
Yes
Second Seat Row › Collapsible
Split Fold Ratio
60/40
Heated Seats
Optional

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Optional
Cameras
Optional
Cruise Control
Adaptive Cruise Control
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional
Start & Stop
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes
Parking Assist
Optional
Lane Departure Warning (LDW)
Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2012
Adult Occupant
94 %
Child Occupant
83 %
Vulnerable Road Users
69 %
Safety Assist
86 %
Overall
5/5 stars
Overall Score
36.03
ANCAP Safety Rating
5
ASEAN NCAP
Test Year
2013
Adult Occupant
5/5 stars
Adult Occupant, Points
14.63
Child Occupant
82 %
Adult Occupant
Frontal Offset
15.03
Side Impact
16
Pole
2
Safety Assist
Seat Belt Reminders
3

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car

Spare Parts BETA

Bulb Types
Low Beam
  • D4S (xenon)
  • H7
Main Beam
H7
Bi-Xenon
D4S
Fog Light, Front
H11
Fog Light, Rear
W3×16d (W21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
  • BAU15s (PY21W)
  • WX3×16d (WY21W)
Turn Indicators, Rear
  • BAU15s (PY21W)
  • WX3×16d (WY21W)
Trunk
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Type
4-5 Doors (D)
