2015 Brilliance H530

ChinaGasolineFWDSedan

Photos

Specifications

Vehicle Details

Year
2015
Make
Brilliance
Model
H530
Body Style
Sedan
Generation
1st Generation Facelift
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 5-speed

Powertrain

Engine Name
1.6
Engine Configuration
Inline
Power (hp)
118 hp
Power (kW)
87 kW
Torque
151 Nm (111 lb-ft)
Top speed
175 km/h (109 mph)
0–60 mph
10.8 seconds (estimated)
0–100 km/h
11.3 seconds
Displacement
1,586 cc

Dimensions

Length
4,708 mm (185.4 in)
Width
1,788 mm (70.4 in)
Height
1,475 mm (58.1 in)
Wheelbase
2,700 mm (106.3 in)
Curb weight
1,290 kg (2,844 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,600 - 6,000 rpm
Rev. at Max Torque
4,000 rpm
Engine Configuration
Bore
75 mm (3.0 in)
Stroke
90 mm (3.5 in)
Compression Ratio
10.5 :1
Engine Configuration
Inline
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 5-speed
Gear Ratio
1st Gear
3.58 – 3.94 :1
2nd Gear
1.95 – 2.09 :1
3rd Gear
1.35 – 1.38 :1
4th Gear
0.96 – 1.03 :1
5th Gear
0.71 – 0.77 :1
Final Drive
3.35 – 3.42 :1
Reverse
3.69 – 4.05 :1

Brakes

Parking Brake
Manual

Fuel

General
Tank Volume
55 litres
Emission
Emission Standard
Euro 4
Fuel Consumption NEDC
Highway
5.8 – 6 litres / 100 km
Combined
7.3 – 7.5 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,545 mm (60.8 in)
Track, Rear
1,514 mm (59.6 in)
Overhang, Front
948 mm (37.3 in)
Overhang, Rear
1,060 mm (41.7 in)
Turning Circle
10 m
Ground Clearance
120 mm (4.7 in)

Interior

Head Room (est.), Rear
960 - 1,000 mm (37.8 - 39.4 in)
Leg Room (est.), Rear
950 - 1,000 mm (37.4 - 39.4 in)

Weight

Gross Weight
1680 – 1730 kg (3,704 – 3,814 lb)
Cargo Capacity
390 kg (860 lb)
Permitted Axle Load, front
890 – 915 kg (1,962 – 2,017 lb)
Permitted Axle Load, rear
790 – 815 kg (1,742 – 1,797 lb)
Weight Distribution, front
59 %
Weight Distribution, rear
41 %

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Optional
Turning Signal
Yes
House Colour
Same as Car
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Tinted Windows
  • Front
  • Second Row
  • Rear Window
Other Equipment
Sunroof
Openable
Antenna
Shark Fin
Number of Exhaust Pipes
1

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
LED
Fog Lights
Yes
Fog Lights
Rear
Yes

Colour

Finish
Metallic

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
57.1
Rim Material
Alloy
Number of Spokes
5
Rim Colour
Silver

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Micro Filter
Yes
Number of Vents, Front
4 pcs
Connectivity
Radio
  • AM
  • FM
Bluetooth
Yes
Connectivity › Media Inputs
AUX
Yes
USB
Yes
Connectivity › Media Inputs › USB
Number of Ports
1 pcs
Displays
Center Display
Yes
Speakers
Total Number of Speakers
4 - 8 pcs
Rear-view Mirror
Anti-glare
Automatic
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Yes
Back Pocket
Yes
Sunglass Compartment
Optional
Coin Holder
Yes
Total Number of Compartments
4 pcs
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
3
Rear
2
Lights
Read Light
  • Front
  • Rear
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Yes
Adjustments
Tilt
Colour
Black
Channels
Yes
Volume
Yes
Multifunction Steering Wheel
Menu Navigation
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
520 litres

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black
Transmission Knob Material
Plastic
Colour
Grey

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Cushion Tilt
Yes
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Second Seat Row
Armrest
Yes
Collapsible
Yes

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Rear Centre Seat Belt
Yes
Centre Rear Seat
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes
Child Safety Locks
Yes

Airbags

Feature
Frontal Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: Yes
  • Rear: Yes

Other

Car Classification

American Classification
Mid-Size Car
European Segment
D-Segment
Car.info Classification
Medium Executive Car
