2015 Cadillac ATS

United StatesGasolineRWDCoupe

Photos

Specifications

Vehicle Details

Year
2015
Make
Cadillac
Model
ATS
Body Style
Coupe
Generation
1st Generation Facelift
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
3.6 V6 Hydra-Matic
Engine Configuration
V
Power (hp)
325 hp
Power (kW)
239 kW
Torque
373 Nm (275 lb-ft)
Displacement
3,564 cc

Dimensions

Length
4,663 mm (183.6 in)
Width
1,842 mm (72.5 in)
Height
1,392 mm (54.8 in)
Wheelbase
2,775 mm (109.3 in)
Curb weight
1,570 kg (3,461 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,800 rpm
Rev. at Max Torque
4,800 rpm
Redline
7,200 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
10.2 litres
Engine Configuration
Bore
94 mm (3.7 in)
Stroke
85.6 mm (3.4 in)
Compression Ratio
11.5 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
72,000 km / 4 years
Spark Plug
156,000 km (96,934 mi)
Brake Fluid
240,000 km / 10 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Interior Filter
36,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic, 6-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.06 :1
2nd Gear
2.37 :1
3rd Gear
1.55 :1
4th Gear
1.16 :1
5th Gear
0.85 :1
6th Gear
0.67 :1
Final Drive
3.27 :1
Reverse
3.2 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
300 - 321 mm (11.8 - 12.6 in)
Width
26 mm (1.0 in)
Cooling
Ventilated
Rear Brakes
Diameter
315 mm (12.4 in)
Width
23 mm (0.9 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Electronic Damper Control (EDC)
Optional
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
60.5 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption EPA
City
19 MPG
Highway
28 MPG

Dimensions & Weight

Exterior

Track, Front
1,532 mm (60.3 in)
Track, Rear
1,567 mm (61.7 in)
Turning Circle
11 - 11.1 m

Interior

Head Room, Front
955 mm (37.6 in)
Head Room, Rear
892 mm (35.1 in)
Leg Room, Front
1,074 mm (42.3 in)
Leg Room, Rear
851 mm (33.5 in)
Hip Room, Front
1,374 mm (54.1 in)
Hip Room, Rear
1,130 mm (44.5 in)
Shoulder Room, Front
1,374 mm (54.1 in)
Shoulder Room, Rear
1,298 mm (51.1 in)

Weight

Weight Distribution, front
52 %
Weight Distribution, rear
48 %

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Alpha Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
User Memory
Yes
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Intermittent Control
Yes
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered (Safety Lock)
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Windows › Window Lifts, Features
Pinch Protection
  • Driver
  • Passenger
One-touch up/down
  • Driver
  • Passenger
Other Equipment
Sunroof
Optional
Antenna
Yes
Other Equipment › Sunroof
Sun Blind
Optional

Lights

Main Beam
Xenon
Low Beam
Xenon
Rear Lights
LED
Daytime Running Light
Halogen
Special Features
  • Main Beam Assist
  • Dynamic Cornering Lights
  • Headlight Washers
  • Headlight Range Adjustment

Colour

Finish
Metallic
Door Handles
Chrome

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
115
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
70.3
Fastening Type
Lug Nuts
Tightening Torque
140 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Instrument Cluster › Trip Computer
Display
5.7"
Climate Control
Climate Control
Automatic
Air Condition
Yes
Micro Filter
Yes
Outside Temperature Indicator
Yes
Controls
Buttons
Connectivity
Radio
  • AM
  • FM
  • DAB+
App-Connect
Optional
Bluetooth
  • Phone
  • Audio
Cellular Network
Optional
Connectivity › Radio
HD Radio
Optional
Connectivity › Media Format
Memory Card Reader
SD
Connectivity › Media Inputs
AUX
Front
USB
USB-A
Connectivity › Media Inputs › USB
Placement
Front
Number of Ports
2 pcs
Connectivity › App-Connect
Android Auto
Optional
Apple CarPlay
Optional
Connectivity › Cellular Network
4G
Optional
Connectivity › Cellular Network › 4G
3G
Optional
Displays
Center Display
8"
Center Display Controls
  • Touchscreen
  • Gesture Control
Displays › Center Display
Type
Colour
Features
Active Noise Cancellation
Optional
Speakers
Total Number of Speakers
10 - 13 pcs
Speaker Brand
Bose
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Lockable
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
  • Front
  • Rear
Guide Light
  • Entry Guard
  • Door Handles (Exterior)
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
  • Front
  • Trunk
230V Outlet
Optional
Ashtray
Front
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
Center Display
Other Equipment › 230V Outlet
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Electric
Adjustments
User Memory
Number of Spokes
3
Material
Leather
Multifunction Steering Wheel
Menu Navigation
Buttons
Cruise Control
  • Speed Up/Down (Buttons)
  • Resume
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Buttons
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Hatch Through Rear Seats
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
294 litres

Design

Interior Decor Material
Plastic
Pedals
  • Aluminium
  • Sport

Seats

Front Seats › Adjustments, Driver
Seat Depth
Powered
Cushion Edge
Manual
Backrest Angle
Powered
Lumbar Support
Powered
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Seat Height
Powered
Cushion Edge
Manual
Lumbar Support
Powered
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
  • Driver
  • Passenger
Armrest
Middle
Type of Seat
Sport Seats
Front Seats › Power Seat, Driver
User Memory
Yes
Front Seats › Heated Seats
Areas
  • Cushion
  • Backrest
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
2
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Remote Engine Start
Optional
Cruise Control
Yes
Cameras
Rear
Wireless Phone Charger
Front
Cruise Control
Adaptive Cruise Control
Optional
Cameras
View Location
Center Display

Other Features

GPS
Optional
Horn
Dual Note

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Optional
Lane Assist System
Yes
Sign Assist
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Optional
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Anti-theft Alarm
Interior Monitoring
Yes
Back-up Horn
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag
Curtain Airbag

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left

Car Classification

American Classification
Entry-Level Luxury Car
British Classification
Compact Executive Car
Australian Classification
Medium Car
European Segment
D-Segment
Car.info Classification
Medium Executive Car
