2016 Audi A5 RS

GermanyGasolineAWDConvertible

Specifications

Vehicle Details

Year
2016
Make
Audi
Model
A5
Variant
RS
Body Style
Convertible
Generation
8T Facelift
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic (Dual-clutch), 7-speed

Powertrain

Engine Name
RS 5 Cabriolet S Tronic
Engine Configuration
V
Power (hp)
450 hp
Power (kW)
331 kW
Torque
430 Nm (317 lb-ft)
Top speed
250 km/h (155 mph)
0–60 mph
4.7 seconds (estimated)
0–100 km/h
4.9 seconds
Displacement
4,163 cc

Dimensions

Length
4,649 mm (183.0 in)
Width
1,860 mm (73.2 in)
Height
1,380 mm (54.3 in)
Wheelbase
2,751 mm (108.3 in)
Curb weight
1,995 kg (4,398 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
8,250 rpm
Rev. at Max Torque
4,000 - 6,000 rpm
Engine Fluids
Engine Oil, Volume
9.7 litres
Engine Configuration
Bore
84.5 mm (3.3 in)
Stroke
92.8 mm (3.7 in)
Compression Ratio
12.3 :1
Engine Configuration
V-Engine
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Air Filter
90,000 km (55,923 mi)
Brake Fluid
2 years
Oil Change & Engine Filter
15,000 km / 1 years
Interior Filter
30,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Dual-clutch), 7-speed
Gear Selector
Paddles

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
365 mm (14.4 in)
Cooling
Ventilated
Rear Brakes
Diameter
330 mm (13.0 in)
Cooling
Ventilated
Brakes Material
Carbon Ceramic
Optional

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
61 litres
Lockable Fuel Cap
Yes
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 5
Emission Class
F
Fuel Consumption NEDC
City
14.6 litres / 100 km
Highway
8.5 litres / 100 km
Combined
10.7 litres / 100 km
Emission NEDC
CO₂, Combined
249 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,020 mm (79.5 in)
Track, Front
1,586 mm (62.4 in)
Track, Rear
1,582 mm (62.3 in)
Overhang, Front
873 mm (34.4 in)
Overhang, Rear
1,025 mm (40.4 in)
Turning Circle
11.6 m
Ground Clearance
114 - 127 mm (4.5 - 5.0 in)

Interior

Head Room, Front
1,015 mm (40.0 in)
Head Room, Rear
923 mm (36.3 in)
Leg Room, Front
1,049 mm (41.3 in)
Leg Room, Rear
810 mm (31.9 in)
Hip Room, Front
1,458 mm (57.4 in)
Hip Room, Rear
1,245 mm (49.0 in)
Shoulder Room, Front
1,378 mm (54.3 in)
Shoulder Room, Rear
1,190 mm (46.9 in)

Weight

Gross Weight
2,420 kg (5,335 lb)
Max Trailer Load, braked 12%
0 kg (0 lb)
Max Trailer Load, braked 8%
0 kg (0 lb)
Max Trailer Load, unbraked
0 kg (0 lb)
Cargo Capacity
425 kg (937 lb)
Max Roof Load
0 kg (0 lb)
Max Towbar Download
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Cabriolet Soft-top
Pillars
A
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Platform
Volkswagen Group
MLB

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
User Memory
Optional
Heated
Yes
Automatic Tilt Down
Optional
Turning Signal
Yes
Mirror Shape, Driver side
Aspheric
Mirror Shape, Passenger side
Aspheric
Windscreen Wipers
Heated Washer Nozzles
Yes
Intermittent Control
Yes
Windscreen Wipers: Connector type, Front
Slim Push Button
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
Noise Reducing Windows
Optional
Windows › Heated Windows
Front
Optional
Windows › Noise Reducing Windows
Front
Optional
Other Equipment
Spoiler
Fixed
Antenna
Yes

Lights

Main Beam
Xenon
Low Beam
Xenon
Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
Headlight Washers
Fog Lights
Front
Halogen
Rear
LED
Special Features
Main Beam Assist
Optional
Adaptive Headlights
Optional
Dynamic Turn Signal
Optional
Dynamic Cornering Lights
Optional
Come Home/Leaving Lights
Optional

Colour

Accent
Silver
Cabriolet Top Colour
Black
Door Handles
Same as Car

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Indirect
Number of Bolts
5 pcs
Bolt Distance
112
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
66.5
Central Bore (CB), rear
66.5
Fastening Type
  • Lug Bolts
  • Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Yes
Tightening Torque
120 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Controls
Rotary Dials
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
Media Format
  • MP3
  • WMA
App-Connect
Optional
Bluetooth
Optional
WiFi
Optional
Connectivity › Radio
DAB
Optional
Connectivity › Media Format
CD
Yes
DVD
Optional
Memory Card Reader
SD
Connectivity › Media Inputs
AUX
Yes
Connectivity › Bluetooth
Phone
Optional
Audio
Optional
Displays
Center Display
Yes
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
8 pcs
Speakers Max. Watt
80 W
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Back Pocket
Optional
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Glove Compartment
Cooled
Optional
Lockable
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Guide Light
Entry Guard
Lights › Guide Light
Footwell
Optional
Side Mirrors
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
  • Front
  • Trunk
Carpets
  • Front
  • Rear
Ashtray
Front (Retractable)
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster
Other Equipment › Carpets
Material
Textile
Colour
Black

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Electro-mechanical
Adjustments
  • Tilt
  • Telescope
Sport
Yes
Number of Spokes
3
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Menu Navigation
Scrolling Wheel
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Channels
Yes
Volume
Scrolling Wheel
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Light
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
380 litres
Volume, Back Seat Collapsed
750 litres
Volume (Roof Folded)
320 litres
Depth
1,066 mm (42.0 in)
Width
934 mm (36.8 in)
Opening Width
952 mm (37.5 in)
Sill Height
662 mm (26.1 in)

Design

Entry Guard Material
Stainless steel
Pedals
Stainless Steel

Seats

Colour & Material
Upholstery
  • Alcantara
  • Leather
Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
  • Manual
  • Powered
Lumbar Support
Powered
Collapsible
Yes
Front Seats › Adjustments, Driver › Collapsible
Easy Entry
Yes
Manual
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Powered
Collapsible
Yes
Front Seats › Adjustments, Passenger › Collapsible
Easy Entry
Yes
Manual
Yes
Front Seats
Heated Seats
Optional
Armrest
Middle
Ventilated Seats
Optional
Type of Seat
Sport Seats
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Ventilated Seats
Driver
Optional
Passenger
Optional
Second Seat Row
Collapsible
Yes
Number of Seats
2
Type of Seat
Adult
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Features

Comfort Features

Cameras
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional
Start & Stop
Yes
Driving Mode Selection
  • Comfort
  • Dynamic
  • Eco
  • Individual
  • Auto
Dynamic Chassis Control (DCC)
Optional
Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Yes
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Yes
First Aid Kit
Yes
Bicycle Holder
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Speed Assist
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes
Differential Lock
Electronic

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Optional
Light Sensor
Optional
Rain Sensors
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Active Bonnet
Yes
Immobiliser
Electronic
Yes
Anti-theft Alarm
Interior Monitoring
Yes

Safety Testing

General
Test Year
2009
Adult Occupant
93 %
Child Occupant
84 %
Vulnerable Road Users
39 %
Safety Assist
71 %
Overall
5/5 stars
Adult Occupant
Total Points
34 /38
Lateral Impact
14.5 /16
Rear Impact
2.4 /4
Child Occupant
Total Points
43 /49
Safety Features
7 /13
CRS Installation Check
12 /12
Vulnerable Road Users
Total Points
27.4 /49
Pedestrian
  • 16.6
  • 5.5
  • 5.3
Safety Assist
Speed Assistance (points)
1.3 /3
Lane Support (points)
0 /4

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: Optional
  • Rear: Yes

Other

Warranty

Manufacturer
2 years
Manufacturer (SWE)
2 years
Manufacturer (NO)
5 years
Manufacturer (NO)
100,000 km (62,137 mi)
Body Protection
3 years
Paintwork
3 years
Rust Damage
12 years

Identification

VIN Location
Engine Compartment, Bulkhead
Right
Left Side Casing of Window
Yes
Trunk
on Floor
On-board Diagnostic, Port Location
Steering Wheel, Lower Left

Car Classification

American Classification
Entry-Level Luxury Car
British Classification
Compact Executive Car
Australian Classification
Medium Car
European Segment
D-Segment
Car.info Classification
  • Medium Executive Car
  • Sports Car

Spare Parts BETA

Bulb Types
Low Beam
  • D3S (xenon)
  • H7
Main Beam
H7
Bi-Xenon
D3S
Fog Light, Front
H8
Fog Light, Rear
BA15s (P21W)
Cornering Light
H7
Rear/Brake Light
BA15s (P21W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAY9s (H21W)
Turn Indicators, Rear
W2.1×9.5d (W16W)
Glove Compartment
W2.1×9.5d (W5W)
Read Light
W2.1×9.5d (W5W)
Trunk
W2.1×9.5d (W5W)
Entry Light
W2.1×9.5d (W5W)
License Plate Light
SV8.5 (C5W)

Similar convertibles

Suggested vehicles
