2016 Cadillac CTS

United StatesGasolineRWDSedan

Photos

Specifications

Vehicle Details

Year
2016
Make
Cadillac
Model
CTS
Body Style
Sedan
Generation
3rd Generation Facelift
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic (Electrohydraulic), 8-speed

Powertrain

Engine Name
CTS-V (EU) Hydra-Matic
Engine Configuration
V
Power (hp)
649 hp
Power (kW)
477 kW
Torque
855 Nm (631 lb-ft)
Top speed
320 km/h (199 mph)
0–60 mph
3.5 seconds (estimated)
0–100 km/h
3.7 seconds
Displacement
6,162 cc

Dimensions

Length
5,050 mm (198.8 in)
Width
1,863 mm (73.3 in)
Height
1,447 mm (57.0 in)
Wheelbase
2,910 mm (114.6 in)
Curb weight
1,850 kg (4,079 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,400 rpm
Rev. at Max Torque
3,600 rpm
Engine Fluids
Engine Oil, Volume
9.5 litres
Engine Coolant, Volume
12.2 litres
Engine Configuration
Bore
103.3 mm (4.1 in)
Stroke
92 mm (3.6 in)
Compression Ratio
10 :1
Engine Configuration
V-Engine
Supercharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
72,000 km / 4 years
Spark Plug
156,000 km (96,934 mi)
Brake Fluid
240,000 km / 10 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Rear Axle, Oil
72,000 km (44,739 mi)
Interior Filter
36,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 8-speed
Gear Selector
  • Stick
  • Paddles
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.56 :1
2nd Gear
2.97 :1
3rd Gear
2.08 :1
4th Gear
1.69 :1
5th Gear
1.27 :1
6th Gear
1 :1
7th Gear
0.85 :1
8th Gear
0.65 :1
Final Drive
2.85 :1
Reverse
3.82 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
390 mm (15.4 in)
Width
36 mm (1.4 in)
Cooling
Ventilated
Rear Brakes
Diameter
365 mm (14.4 in)
Width
28 mm (1.1 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Strut Bar
Front
Anti-roll Bar
  • Front
  • Rear
Electronic Damper Control (EDC)
Yes
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
72 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 6
Emission Control
  • Catalyst
  • Adaptive Cylinder Management
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
City
20 litres / 100 km
Highway
8.9 litres / 100 km
Combined
13 litres / 100 km
Emission NEDC
CO₂, City
459 g/km
CO₂, Highway
203 g/km
CO₂, Combined
298 g/km

Dimensions & Weight

Exterior

Track, Front
1,576 mm (62.0 in)
Track, Rear
1,863 mm (73.3 in)
Turning Circle
12.3 m

Interior

Head Room, Front
995 mm (39.2 in)
Head Room, Rear
952 mm (37.5 in)
Leg Room, Front
1,081 mm (42.6 in)
Leg Room, Rear
899 mm (35.4 in)
Hip Room, Front
1,366 mm (53.8 in)
Hip Room, Rear
1,353 mm (53.3 in)
Shoulder Room, Front
1,446 mm (56.9 in)
Shoulder Room, Rear
1,392 mm (54.8 in)

Weight

Gross Weight
2,350 kg (5,181 lb)
Cargo Capacity
500 kg (1,102 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Alpha Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
User Memory
Yes
Heated
Yes
House Colour
Same as Car
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Tinted Windows
Yes
Windows › Window Lifts, Features
One-touch up/down
  • Driver
  • Passenger
Other Equipment
Tow Hitch
Tow Hitch Preparation
Normal Roof
Yes
Antenna
Yes

Lights

Daytime Running Light
LED
Fog Lights
Yes
Special Features
  • Automatic Headlight Activation
  • Headlight Washers
Fog Lights
Front
Yes
Rear
Yes
Fog Lights › Front
Cornering Lights
Yes

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Anti-Theft Locking Lug Nuts/Bolts
Yes
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
  • DAB+
Media Format
CD
Media Inputs
USB
Bluetooth
  • Phone
  • Audio
  • Siri Eyes Free
Connectivity › Media Format
Memory Card Reader
SD
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
8 - 12.3"
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Features
Active Noise Cancellation
Optional
Speakers
Total Number of Speakers
11 - 13 pcs
Speaker Brand
Bose
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
Yes
Lights
Read Light
Front
Guide Light
  • Entry Guard
  • Footwell (Front)
  • Door Handles (Exterior)
  • Bottom of the Doors
Ambient Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
Carpets
  • Front
  • Rear
Ashtray
Yes
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Carpets
Material
Textile

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Yes
Adjustments
User Memory
Material
Leather
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Cruise Control
Yes
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Volume
Yes
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Automatic Open
Yes
Automatic Close
Yes
Barrier Net/Grid
Yes
Light
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
388 litres

Seats

Colour & Material
Upholstery
Leather
Front Seats › Adjustments, Driver
Lumbar Support
Powered
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Number of Driver Seat Adjustments, Powered
8
Power Seat, Driver
Yes
Heated Seats
  • Driver
  • Passenger
Ventilated Seats
  • Driver
  • Passenger
Front Seats › Adjustments, Passenger
Lumbar Support
Powered
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Power Seat, Driver
User Memory
Yes
Front Seats › Heated Seats
Areas
  • Cushion
  • Backrest
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Yes
Centre Seat
Yes

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Cruise Control
Yes
Cameras
Rear
Wireless Phone Charger
Yes
Cruise Control
Adaptive Cruise Control
Optional

Other Features

GPS
Optional
Driving Mode Selection
  • Snow
  • Sport

Accessories

Tire Repair Kit
Yes
Coat Hanger
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Yes
Lane Assist System
Yes
Sign Assist
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes

Brake Systems

Traction Control System (TCS)
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Yes
Rain Sensors
Yes
Parking Sensors
Front
Optional
Side
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Child Safety Locks
Yes
Active Bonnet
Yes
Anti-theft Alarm
Interior Monitoring
Yes
Back-up Horn
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Knee Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Mid-Size Luxury Car
British Classification
Executive Car
Australian Classification
Large Car
European Segment
E-Segment
Car.info Classification
Executive Car
