2016 Fiat Fiorino

ItalyNatural Gas CngFWDLCV

Photos

Specifications

Vehicle Details

Year
2016
Make
Fiat
Model
Fiorino
Body Style
LCV
Generation
Typ 225
Doors
3
Fuel
Natural Gas Cng
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.4 CNG Manual
Engine Configuration
Inline
Power (hp)
77 hp
Power (kW)
57 kW
Torque
104 Nm (77 lb-ft)
Displacement
1,368 cc

Dimensions

Length
3,959 mm (155.9 in)
Width
1,716 mm (67.6 in)
Height
1,721 mm (67.8 in)
Wheelbase
2,513 mm (98.9 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
3,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
3.7 litres
Engine Configuration
Bore
72 mm (2.8 in)
Stroke
84 mm (3.3 in)
Compression Ratio
11.1 :1
Engine Configuration
Inline
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Timing Interval
120,000 km / 5 years
Air Filter
60,000 km (37,282 mi)
Spark Plug
60,000 km (37,282 mi)
Brake Fluid
60,000 km / 2 years
Interior Filter
30,000 km / 1 years

Fuel

General
Tank Volume
45 litres

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes

Dimensions & Weight

Exterior

Track, Front
1,464 mm (57.6 in)
Track, Rear
1,465 mm (57.7 in)
Turning Circle
9.95 m
Ground Clearance
130 - 150 mm (5.1 - 5.9 in)

Exterior

Chassis & Body

Chassis
Chassis
LCV (Panel Van)
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Sliding (Right)
Platform
Fiat Platforms
Small Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Heated
Optional
House Colour
Black
Windscreen Wipers
Rear Wiper
Optional
Windows
Heated Windows
Optional
Heat-Insulating Windows
Yes
Windows › Heated Windows
Rear
Optional
Other Equipment
Roof Railing
Optional
Antenna
Yes

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Optional

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
98
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
58.1
Fastening Type
Lug Bolts
Tightening Torque
86 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Air Condition
Optional
Outside Temperature Indicator
Optional
Connectivity
Radio
Optional
Bluetooth
Optional
Connectivity › Radio
CD
Optional
MP3
Optional
WMA
Optional
USB
Optional
Connectivity › Bluetooth
Phone
Optional
Interior Storage › Storage Compartments
Glove Compartment
Optional
Interior Storage › Storage Compartments › Glove Compartment
Lockable
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › 12V Outlet
Trunk
Optional

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Yes
Power Steering
Tilt
Optional

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Optional
Rear Trunk
Volume
360 litres
Volume, Back Seat Collapsed
2,500 litres

Design

Interior Decor Material
Textile
Interior Decor Colour
Black

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Front Seats
Heated Seats
Optional
Second Seat Row
Collapsible
Yes
Type of Seat
Adult
Colour & Material
Upholstery
Textile

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Belt Pretensioner
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Assist Systems

Electronic Stability Control (ESC)
Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Optional
Electronic Brake Assist (BA/EBA)
Optional

Sensors

Parking Sensors
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Optional
Central Locking
Remote
Optional

Airbags

Feature
Frontal Airbag
Side Chest Airbag

Other

Identification

VIN Location
Passenger Seat
in Front of
Trunk
Right Side

Car Classification

European Segment
M-Segment
Car.info Classification
Cargo Van
