GenerationGMT610 Facelift TransmissionAutomatic (Electrohydraulic), 6-speed 9.8 litresEngine Coolant, Volume18.9 litres Full Synthetic Viscosity10W-30 Engine Fluids › Engine Coolant
Car Battery
- Voltage
- 12 V
- Battery Capacity
- 61 Ah
- Cold Start Power
- 770 A
- Secondary Battery
- Optional
- Alternator Charge Current
- 145 A
- Alternator Voltage
- 14 V
Engine Configuration
- Bore
- 103 mm (4.1 in)
- Stroke
- 99 mm (3.9 in)
- Compression Ratio
- 16.8 :1
- Engine Configuration
- V-Engine
- Turbocharger
- Yes
- Synchronization
- Timing Chain
- Engine Placement
- Front
- Engine Mount
- Longitudinally
- Type of Combustion Engine
Service Intervals
- Air Filter
- 72,000 km / 4 years
- Fuel Filter
- 36,210 km (22,500 mi)
- Oil Change & Engine Filter
- 12,070 km / 1 years
- Engine Coolant
- 240,000 km / 5 years
- Transmission, Fluid
- 80,000 km (49,710 mi)
- Transmission, Fluid Filter
- 80,000 km (49,710 mi)
- Accessory Belt
- 240,000 km (149,129 mi)
Fuel SystemElectronic (Direct) Fuel Injection Engine CoolingLiquid Cooling 4th Gear1.15 :1Yes
Emission › Emission Control › Selective Catalyst Reduction (SCR)
- Tank Volume (DEF)
- 20 litres
Rear Brakes
- Diameter
- 330 mm (13.0 in)
- Width
- 30 mm (1.2 in)
Leg Room, Front1,049 mm (41.3 in) Hip Room, Front1,664 mm (65.5 in) Shoulder Room, Front1,748 mm (68.8 in) Rear Doors- Sliding Right
- Dual Swing-out
Platform
- General Motors Platforms
- GMT Platform (GMT610)
Odometer Limit1,000,000 km/miles Instrument Cluster › Trip Computer
Instrument Cluster › Trip Computer › Display
- Type
- Monochrome
- Shape
- Square
Climate Control
- Air Condition
- Optional
- Outside Temperature Indicator
- Optional
- Number of Vents, Front
- 5 pcs
- Controls
- Rotary Dials
Climate Control › Air Condition
- Refrigerant
- R134A
- Refrigerant, Capacity
- 900 g
Connectivity
- Radio
- Optional
- Bluetooth
- Optional
- Cellular Network
- Optional
- WiFi
- Optional
Connectivity › Radio
- AM
- Optional
- FM
- Optional
- XM
- Optional
- RDS
- Optional
- CD
- Optional
- DVD
- Optional
- MP3
- Optional
- WMA
- Optional
Connectivity › Media Inputs
Connectivity › Media Inputs › USB
- USB-A
- Optional
- Number of Ports
- 1 pcs
Connectivity › Cellular Network
Displays
- Center Display
- 8"
- Equalizer
- Optional
Displays › Center Display Controls
- Touchscreen
- Optional
- Buttons
- Optional
- Rotary Dial
- Optional
Displays › Center Display Controls › Buttons
Speakers
- Total Number of Speakers
- 2 pcs
Interior Storage › Storage Compartments
- Door
- Driver Side
- Passenger Side
- Total Number of Compartments
- 12 pcs
Interior Storage › Cup Holders
Interior Storage › Cup Holders › Front
Other Equipment › Make-up Mirror
- Driver Side
- Optional
- Passenger Side
- Optional
- Make-up Light
- Optional
Other Equipment
- Clock
- Yes
- 12V Outlet
- Front
- 110V Outlet
- Front
- Carpets
- Optional
- Ashtray
- Optional
- Cigarette Lighter
- Optional
Other Equipment › Ashtray
Passenger
Optional
Height Adjustable Retractor
Type of Belt
- Three-Point-Belt
- Front Seats
Van
Australian ClassificationVan European SegmentM-Segment Car.info ClassificationCargo Van 2,141 mm (84.3 in)
Dimensions › Wheel Base
- L1
- 3,429 mm (135.0 in)
- L2
- 3,937 mm (155.0 in)
Dimensions › Turning Circle
Side Door › Side Door Height
Side Door › Side Door Width
- L1
- 1,120 mm (44.1 in)
- L2
- 1,120 mm (44.1 in)
Side Door › Ground to Door Height
- L1H1
- 511 mm (20.1 in)
- L1H2
- 498 mm (19.6 in)
Rear Doors › Rear Doors Height
Rear Doors
- Rear Doors Width
- 1,448 mm (57.0 in)
Rear Doors › Sill Height
- L1H1
- 704 mm (27.7 in)
- L1H2
- 693 mm (27.3 in)
Cargo Space › Cargo Volume
- L1H1
- 7,569 litres
- L2H1
- 8,970 litres
Cargo Space › Depth
- L1
- 3,246 mm (127.8 in)
- L2
- 3,754 mm (147.8 in)
Cargo Space › Space Width, Between Wheel Arches
- L1
- 1,282 mm (50.5 in)
- L2
- 1,290 mm (50.8 in)
Weight › Max Trailer Load, braked
Yes
Windows
- Window Lifts, Front
- Manual
- Heated Windows
- Optional
- Tinted Windows
- Optional
- Rear Windows, Pop-out
- Optional
Windows › Window Lifts, Front
Windows › Heat-Insulating Windows
Windows › Tinted Windows
- Windscreen, upper part
- Optional
- Second Row
- Optional
- Rear Window
- Optional
Windows › Rear Windows, Pop-out
Other Equipment
- Normal Roof
- Yes
- Antenna
- Optional
- Air Intakes
- 1-port
- Number of Exhaust Pipes
- 1
- Mud Flaps
- Optional
Other Equipment › Mud Flaps
- Front
- Optional
- Rear
- Optional
Number of Passenger Seat Adjustments, Powered6 Number of Passenger Seat Adjustments, Total4 - 8 Power Seat, DriverOptional Power Seat, PassengerOptional Front Seats › Adjustments, Passenger
- Seat Depth
- Yes
- Seat Height
- Optional
- Backrest Angle
- Manual
Optional
Curtain Airbag
DriverOptional
PassengerOptional
Rear-
Airbag cut-off Switch
Driver-
PassengerOptional
Rear-
LCVDrivetrain
RWD Transmission
Automatic (Electrohydraulic), 6-speed
