2016 Hyundai Tucson

South KoreaDieselAWDWagon

Photos

Specifications

Vehicle Details

Year
2016
Make
Hyundai
Model
Tucson
Body Style
Wagon
Generation
TL
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
AWD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
2.0 CRDi 4WD
Engine Configuration
Inline
Power (hp)
185 hp
Power (kW)
136 kW
Torque
400 Nm (295 lb-ft)
Top speed
201 km/h (125 mph)
0–60 mph
9.0 seconds (estimated)
0–100 km/h
9.5 seconds
Displacement
1,995 cc

Dimensions

Length
4,480 mm (176.4 in)
Width
1,850 mm (72.8 in)
Height
1,650 mm (65.0 in)
Wheelbase
2,670 mm (105.1 in)
Curb weight
1,587 kg (3,499 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,000 rpm
Rev. at Max Torque
1,750 - 2,750 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
  • 15W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
  • 15W-40
Engine Oil, Volume
7.6 litres
Engine Configuration
Bore
84 mm (3.3 in)
Stroke
90 mm (3.5 in)
Compression Ratio
16 :1
Engine Configuration
Inline
Turbocharger
Yes
Service Intervals
Oil Change & Engine Filter
15,000 km / 1 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
305 mm (12.0 in)
Width
25 mm (1.0 in)
Cooling
Ventilated
Rear Brakes
Diameter
302 mm (11.9 in)
Width
10 mm (0.4 in)

Suspensions

Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
62 litres
Emission
Emission Standard
Euro 6
Fuel Consumption NEDC
City
7.1 – 8 litres / 100 km
Highway
5.2 – 5.6 litres / 100 km
Combined
5.9 – 6.5 litres / 100 km
Emission NEDC
CO₂, Combined
154 – 170 g/km

Dimensions & Weight

Exterior

Track, Front
1,620 mm (63.8 in)
Track, Rear
1,630 mm (64.2 in)
Turning Circle
10.8 m
Ground Clearance
170 mm (6.7 in)

Interior

Head Room, Front
1,005 mm (39.6 in)
Head Room, Rear
995 mm (39.2 in)
Leg Room, Front
1,053 mm (41.5 in)
Leg Room, Rear
970 mm (38.2 in)
Hip Room, Front
1,412 mm (55.6 in)
Hip Room, Rear
1,384 mm (54.5 in)
Shoulder Room, Front
1,450 mm (57.1 in)
Shoulder Room, Rear
1,400 mm (55.1 in)

Weight

Gross Weight
2,250 kg (4,960 lb)
Max Trailer Load, braked 12%
1900 – 2200 kg (4,189 – 4,850 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
635 kg (1,400 lb)
Max Roof Load
100 kg (220 lb)
Max Towbar Download
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Hyundai-Kia Platforms
J Platform (J6)

Equipment

Side Mirrors
Mirror Type
Conventional
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)

Lights

Main Beam
Halogen
Low Beam
Halogen
Special Features
Headlight Range Adjustment

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
107 - 127 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Oil Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Square
Climate Control
Climate Control
Manual
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Phone
Connectivity › Media Inputs
AUX
Yes
USB
USB-A
Interior Storage › Storage Compartments
Glove Compartment
Lockable
Armrest Hatch
  • Front
  • Back
Coin Holder
Yes
Card Holder
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
Front
Guide Light
Entry Guard
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Other Equipment › Clock
Digital
Center Display

Steering Wheel

Multifunction Steering Wheel
Yes
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Cover
Sliding (Manual)
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
515 litres
Volume, Back Seat Collapsed
1,500 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats
Armrest
Middle
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Speed Assist
Optional
Hill Start Assist (HSA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Immobiliser
Yes
Central Locking
Remote
Active Bonnet
Yes

Safety Testing

General
Test Year
2015
Adult Occupant
86 %
Child Occupant
85 %
Vulnerable Road Users
71 %
Safety Assist
71 %
Overall
5/5 stars
Test Year
2015
Overall Score
35.53
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
14.53
Side Impact
16
Pole
2
Whiplash Protection (Assessment)
Good
Pedestrian
Protection (Assessment)
Marginal
Safety Assist
Seat Belt Reminders
3
Frontal Crash
Front Driver Side
5/5 stars
Front Passenger Side
5/5 stars
Side Crash
Side Crash, Driver
5/5 stars
Side Crash, Passenger
5/5 stars
Front Seat Rating
5/5 stars
Combined Rear Seat Rating
5/5 stars
Side Barrier Rating
5/5 stars
Overall Side Pole Star Rating
4/5 stars
Rollover
Rollover Resistance
15.5 %
Overall Safety Rating
5/5 stars
Overall Frontal Rating
5/5 stars
Overall Side Rating
5/5 stars
Rollver
4/5 stars
IIHS
Test Year
2016
Award
Top Safety Pick+
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
H7
Fog Light, Front
H8
Fog Light, Rear
BA15s (P21W)
Cornering Light
H7
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
  • BA15s (P21W)
  • BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Type
Crossover (G)
