2016 Lada X-Ray

RussiaGasolineFWDCrossover

Photos

Specifications

Vehicle Details

Year
2016
Make
Lada
Model
X-Ray
Body Style
Crossover
Generation
1st Generation
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.6 i 16V Manual
Engine Configuration
Inline
Power (hp)
110 hp
Power (kW)
81 kW
Torque
150 Nm (111 lb-ft)
Top speed
171 km/h (106 mph)
0–60 mph
9.8 seconds (estimated)
0–100 km/h
10.3 seconds
Displacement
1,598 cc

Dimensions

Length
4,165 mm (164.0 in)
Width
1,764 mm (69.4 in)
Height
1,570 mm (61.8 in)
Wheelbase
2,592 mm (102.0 in)
Curb weight
1,190 kg (2,624 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
4,000 rpm
Engine Configuration
Bore
79.5 mm (3.1 in)
Stroke
80.5 mm (3.2 in)
Compression Ratio
10.7 :1
Engine Configuration
Inline
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Engine Cooling
Liquid Cooling

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes

Fuel

General
Tank Volume
50 litres
General › Fuel Cap Position
Rear
Right
Fuel Consumption NEDC
City
9.4 litres / 100 km
Highway
5.6 litres / 100 km
Combined
6.9 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,484 mm (58.4 in)
Track, Rear
1,524 mm (60.0 in)
Ground Clearance
195 mm (7.7 in)

Interior

Head Room (est.), Rear
991 mm (39.0 in)
Leg Room (est.), Rear
900 - 920 mm (35.4 - 36.2 in)

Weight

Gross Weight
1,650 kg (3,638 lb)
Cargo Capacity
460 kg (1,014 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon (Crossover)
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Windscreen Wipers
Intermittent Control
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Tinted Windows
Optional
Safety Glass
Yes
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Antenna
Yes

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
60.1
Fastening Type
Lug Bolts

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Displays
Center Display
Yes
Displays › Center Display
Type
Colour
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Manual
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Lights
Read Light
  • Front
  • Rear
Guide Light
Entry Guard
Other Equipment
Clock
Yes
12V Outlet
Yes
Carpets
Optional
Other Equipment › Carpets
Front
Optional
Rear
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Number of Spokes
3
Colour
Black

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
361 litres
Volume, Back Seat Collapsed
1,207 litres

Other

Car Classification

American Classification
Subcompact SUV
European Segment
J-Segment JB-Segment
Car.info Classification
Small SUV
