2016 Suzuki Ignis

JapanGasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2016
Make
Suzuki
Model
Ignis
Body Style
Hatchback
Generation
FF
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic Semi-automatic
  • Manual, 5-speed

Powertrain

Engine Name
1.2 Dualjet DOHC 16V VVT
Engine Configuration
Inline
Power (hp)
90 hp
Power (kW)
66 kW
Torque
120 Nm (89 lb-ft)
Top speed
170 km/h (106 mph)
0–60 mph
11.6 seconds (estimated)
0–100 km/h
12.2 seconds
Displacement
1,242 cc

Dimensions

Length
3,700 mm (145.7 in)
Width
1,660 mm (65.4 in)
Height
1,595 mm (62.8 in)
Wheelbase
2,435 mm (95.9 in)
Curb weight
820 kg (1,808 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,400 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-16
  • 0W-20
  • 5W-30
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Bore
73 mm (2.9 in)
Stroke
74.2 mm (2.9 in)
Compression Ratio
12.5 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Service Intervals
Air Filter
40,000 km / 3 years
Spark Plug
10,000 km / 7 years
Oil Change & Engine Filter
20,000 km / 1 years

Transmission & Drivetrain

Transmission
  • Automatic Semi-automatic
  • Manual, 5-speed

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Suspension, Front
Independent
Yes
Suspension, Rear
Dependent
Yes

Fuel

General
Tank Volume
32 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 6
Fuel Consumption NEDC
City
5.5 litres / 100 km
Highway
4.1 litres / 100 km
Combined
4.7 litres / 100 km
Emission NEDC
CO₂, Combined
104 – 107 g/km

Dimensions & Weight

Exterior

Track, Front
1,460 mm (57.5 in)
Track, Rear
1,470 mm (57.9 in)
Turning Circle
9.4 m
Ground Clearance
180 mm (7.1 in)

Interior

Head Room (est.), Rear
950 - 980 mm (37.4 - 38.6 in)
Leg Room (est.), Rear
800 - 840 mm (31.5 - 33.1 in)

Weight

Gross Weight
1,330 kg (2,932 lb)
Max Trailer Load, braked 12%
1,000 kg (2,205 lb)
Max Trailer Load, unbraked
400 kg (882 lb)
Cargo Capacity
425 – 510 - 510 kg (1,124 - 1,124 lb)
Max Roof Load
50 kg (110 lb)
Max Towbar Download
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Manual
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
  • Second Row
  • Rear Window
Other Equipment
Roof Railing
Yes
Spoiler
Optional
Antenna
Optional
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Other Equipment › Spoiler
Fixed
Optional

Lights

Rear Lights
Halogen
Fog Lights
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
54.1
Central Bore (CB), rear
54.1
Fastening Type
Lug Nuts
Tightening Torque
95 Nm
Rim Type
Disc Wheel
Tire Pressure Monitoring System (TPMS)
Direct
Optional

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Digital
Odometer Limit
1,000,000 km/miles
Climate Control
Air Condition
Optional
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
Optional
Bluetooth
Optional
Connectivity › Radio
AM
Optional
FM
Optional
CD
Optional
MP3
Optional
USB
Optional
Displays
Center Display
Yes
Rear-view Mirror
Anti-glare
Manual
Interior Storage › Storage Compartments
Glove Compartment
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
Front
Other Equipment
Clock
Yes
12V Outlet
Front
Cigarette Lighter
Yes
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster

Steering Wheel

Power Steering
Yes
Number of Spokes
3
Colour
Black

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
505 litres
Volume, Back Seat Collapsed
1,101 litres
Depth
608 mm (23.9 in)
Depth, Back Seat Collapsed
1,243 mm (48.9 in)
Width
990 mm (39.0 in)
Width, Between Wheel Arches
943 mm (37.1 in)
Height
948 mm (37.3 in)
Sill Height
738 mm (29.1 in)

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black
Transmission Knob Material
Plastic

Seats

Colour & Material
Upholstery
Textile
Seat Colour
Black
Stitching Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats
Heated Seats
Optional
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Heated Seats › Cushion
Backrest
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
2
Type of Seat
Adult
Height Adjustment
Yes
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
50/50

Features

Comfort Features

Keyless Start
Optional
Cruise Control
Optional
Cruise Control
Rear
Optional

Other Features

GPS
Optional
Start & Stop
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Speed Assist
Optional
Hill Start Assist (HSA)
Optional

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Yes
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Central Locking
Yes

Safety Testing

General
Test Year
2016
Adult Occupant
79 %
Child Occupant
79 %
Vulnerable Road Users
67 %
Safety Assist
25 %
Overall
3/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
100,000 km / 3 years
Body Protection
3 years
Paintwork
3 years
Rust Damage
12 years

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes
Pillar
B-Pillar, Right

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car

ACRISS

Category
Economy (E)
Type
4-5 Doors (D)
