2016 Toyota Hilux

JapanDieselRWDPickup

Photos

Specifications

Vehicle Details

Year
2016
Make
Toyota
Model
Hilux
Body Style
Pickup
Generation
AN120/AN130
Seats
2
Doors
2
Fuel
Diesel
Drivetrain
RWD
Transmission
  • Manual, 5
  • 6-speed

Powertrain

Engine Name
2.5
Engine Configuration
Inline
Power (hp)
102 hp
Power (kW)
75 kW
Displacement
2,494 cc

Dimensions

Length
5,330 mm (209.8 in)
Width
1,800 mm (70.9 in)
Height
1,795 mm (70.7 in)
Wheelbase
3,085 mm (121.5 in)
Curb weight
1,740 kg (3,836 lb)

Engine & Performance

Engine

Engine Configuration
Bore
92 mm (3.6 in)
Stroke
93.8 mm (3.7 in)
Compression Ratio
18.5 :1
Engine Configuration
Inline
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Brake Fluid
40,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
160,000 km (99,419 mi)

Transmission & Drivetrain

Transmission
  • Manual, 5
  • 6-speed

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
80 litres
Fuel Consumption NEDC
City
9.6 – 9.9 litres / 100 km
Highway
6.9 – 7.1 litres / 100 km
Combined
8.4 – 8.7 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,495 mm (58.9 in)
Track, Rear
1,510 mm (59.4 in)
Overhang, Front
1,000 mm (39.4 in)
Ground Clearance
227 mm (8.9 in)

Weight

Gross Weight
2600 – 2620 kg (5,732 – 5,776 lb)
Cargo Capacity
750 kg (1,653 lb)
Max Roof Load
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Pickup
Pillars
A-B
Doors
Front Doors
Conventional
Platform
Toyota Platform
IMV Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Windows
Window Lifts, Front
Powered

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Optional

Rims & Tires

Number of Bolts
6 pcs
Bolt Distance
139.7
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
106.2
Fastening Type
Lug Nuts
Tightening Torque
105 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Optional
Connectivity
Radio
Optional
Bluetooth
Optional
Connectivity › Radio
AM
Optional
FM
Optional
CD
Optional
MP3
Optional
WMA
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Displays
Center Display
Yes
Interior Storage › Storage Compartments
Glove Compartment
Yes
Lights
Read Light
Front

Steering Wheel

Multifunction Steering Wheel
Yes

Seats

Colour & Material
Upholstery
Textile
Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats
Heated Seats
Optional

Features

Other Features

GPS
Optional
Start & Stop
Optional
Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Yes
First Aid Kit
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Speed Assist
Optional
Hill Start Assist (HSA)
Yes
Sign Assist
Optional
Trailer Assist
Optional
Trailer Stability Assist (TSA)
Optional
Emergency Stop Signal (ESS)
Optional

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2016
Adult Occupant
85 %
Child Occupant
82 %
Vulnerable Road Users
73 %
Safety Assist
25 %
Overall
3/5 stars
Adult Occupant
Total Points
32.6 /38
Frontal Impact
13.8 /16
Lateral Impact
16 /16
Rear Impact
2.7 /4
Child Occupant
Total Points
40.3 /49
Crash Test Performance
  • 13.5
  • 8 /16
Safety Features
8 /13
CRS Installation Check
10.8 /12
Vulnerable Road Users
Pedestrian
  • 18.9
  • 6
  • 6

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Other

Identification

VIN Location
Engine Compartment, Inner Wing
Left
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Longerun Frame
Behind Right Rear Wheel

Car Classification

American Classification
Mid-Size Pickup Truck
British Classification
Pick-up
Australian Classification
Ute
European Segment
J-Segment JD-Segment
Car.info Classification
Pickup

Spare Parts BETA

Bulb Types
Low Beam
H4
Main Beam
H4
Fog Light, Front
H16
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
WX3×16d (WY21W)
Turn Indicators, Rear
BA15s (P21W)
License Plate Light
W2.1×9.5d (W5W)
