2017 Aston Martin Vanquish

United KingdomGasolineRWDCoupe

Photos

Specifications

Vehicle Details

Year
2017
Make
Aston Martin
Model
Vanquish
Body Style
Coupe
Generation
2nd Generation (VH3)
Seats
2
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 8-speed

Powertrain

Engine Name
S Touchtronic III
Engine Configuration
V
Power (hp)
603 hp
Power (kW)
444 kW
Torque
630 Nm (465 lb-ft)
Top speed
323 km/h (201 mph)
0–60 mph
3.6 seconds (estimated)
0–100 km/h
3.8 seconds
Displacement
5,935 cc

Dimensions

Length
4,730 mm (186.2 in)
Width
1,912 mm (75.3 in)
Height
1,294 mm (50.9 in)
Wheelbase
2,740 mm (107.9 in)
Curb weight
1,739 kg (3,834 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
7,000 rpm
Rev. at Max Torque
5,500 rpm
Engine Configuration
Bore
89 mm (3.5 in)
Stroke
79.5 mm (3.1 in)
Compression Ratio
11 :1
Engine Configuration
V-Engine

Transmission & Drivetrain

Transmission
Automatic, 8-speed

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
  • Front (6)
  • Rear (4)
Front Brakes
Diameter
398 mm (15.7 in)
Cooling
Ventilated
Rear Brakes
Diameter
360 mm (14.2 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Double Wishbone

Fuel

General
Tank Volume
80 litres
Emission NEDC
CO₂, Combined
302 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,067 mm (81.4 in)
Track, Front
1,586 mm (62.4 in)
Track, Rear
1,589 mm (62.6 in)
Overhang, Front
970 mm (38.2 in)
Overhang, Rear
1,020 mm (40.2 in)
Ground Clearance
116 - 117 mm (4.6 - 4.6 in)

Weight

Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-B
Chassis Construction
Unibody
Platform
Aston Martin Platform
VH Platform (IV)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
User Memory
Yes
Heated
Yes
Windows
Heated Windows
Rear
Other Equipment
Normal Roof
Yes

Lights

Main Beam
Xenon
Low Beam
Xenon
Rear Lights
LED
Daytime Running Light
LED

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
128
Nut/Bolt Dimensions
M14x2
Central Bore (CB), front
75.1
Fastening Type
Lug Nuts
Tightening Torque
180 Nm
Rim Material
Alloy
Number of Spokes
10
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Micro Filter
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Lights
Read Light
Front
Guide Light
Yes
Connectivity
Radio
  • AM
  • FM
  • DAB
Media Format
  • MP3
  • WMA
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Audio
Connectivity › Media Format
CD
Yes
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Yes
Center Display Controls
Touchscreen
Speakers
Speaker Brand
Bang & Olufsen

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Sport
Optional
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
368 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Yes
Backrest Angle
Powered
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Backrest Angle
Powered
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
Yes
Front Seats › Power Seat, Driver
User Memory
Yes
Colour & Material
Upholstery
  • Alcantara
  • Leather
Seat Colour
Black
Stitching Colour
Black

Features

Comfort Features

Cruise Control
Yes
Cameras
Rear

Other Features

GPS
Navigation

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner

Assist Systems

Electronic Stability Control (ESC)
Yes
Dynamic Steering Response (DSR)
Yes
Parking Assist
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag

Other

Car Classification

American Classification
Grand Tourer
British Classification
Grand Tourer
Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car
