2017 Hyundai ix20

South Korea Gasoline FWD Minivan

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2017
Make: Hyundai
Model: ix20
Body Style: Minivan

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2017
Make: Hyundai
Model: ix20
Body Style: Minivan

Generation

JC Facelift

Seats

5

Doors

5

Fuel

Gasoline

Drivetrain

FWD

Transmission

Automatic
Manual, 6-speed

Powertrain

Engine Name: 1.6 blue
Engine Configuration: Inline
Power (hp): 125 hp
Power (kW): 92 kW
Torque: 156 Nm (115 lb-ft)
Top speed: 184 km/h (114 mph)
0–60 mph: 10.4 seconds (estimated)
0–100 km/h: 10.9 seconds
Displacement

Dimensions

Length: 4,100 mm (161.4 in)
Width: 1,765 mm (69.5 in)
Height: 1,600 mm (63.0 in)
Wheelbase: 2,615 mm (103.0 in)
Curb weight: 1,255 kg (2,767 lb)

Engine & Performance

Engine

Engine Specification

Rev. at Max Power: 6,300 rpm
Rev. at Max Torque: 4,200 rpm

Engine Fluids

Synthetic Oil (viscosity): 0W-40
5W-20
5W-30
5W-40
Semi-synthetic Oil (viscosity): 5W-30
5W-40

Similar minivans

Suggested vehicles

View all

2017 Vauxhall Zafira

1,591 cc

Engine Oil, Volume

3.3 litres

Engine Configuration

Bore: 77 mm (3.0 in)
Stroke: 85.44 mm (3.4 in)
Compression Ratio: 10.5 :1
Engine Configuration: Inline
Synchronization: Timing Chain
Engine Placement: Front
Engine Mount: Transversally
Type of Combustion Engine: Piston
Fuel System

Service Intervals

Air Filter: 60,000 km / 4 years
Spark Plug: 60,000 km / 4 years
Brake Fluid: 30,000 km / 2 years
Oil Change & Engine Filter: 30,000 km / 1 years
Engine Coolant: 30,000 km / 2 years
Interior Filter: 30,000 km / 2 years

Transmission & Drivetrain

Transmission: Automatic
Manual, 6-speed

Brakes

Parking Brake

Manual: Lever

Front Brakes: Disc Brakes
Rear Brakes: Disc Brakes
Brakes Material: Steel

Front Brakes

Cooling: Ventilated

Suspensions

Spring, Front: Coil
Spring, Rear: Coil

Suspension, Front

Independent: Yes

Fuel

General

Tank Volume: 50 litres

Emission

Emission Standard: Euro 6
Emission Class: C
D

Fuel Consumption NEDC

City: 7.1 – 8 litres / 100 km
Highway: 5 – 5.2 litres / 100 km
Combined

Dimensions & Weight

Exterior

Track, Front: 1,560 mm (61.4 in)
Track, Rear: 1,560 mm (61.4 in)
Turning Circle: 10.4 m
Ground Clearance: 155 mm (6.1 in)

Interior

Exterior

Chassis & Body

Chassis

Chassis: MPV
Pillars: A-D + Extra Pillar(s)
Chassis Construction: Unibody

Doors

Front Doors: Conventional
Rear Doors: Conventional

Platform

Interior

Equipment

Instrument Cluster

Trip Computer: Yes
Speedometer: Analogue
Fuel Gauge: Digital

Instrument Cluster › Trip Computer

Display: Yes

Climate Control

Features

Comfort Features

Keyless Start: Optional
Cruise Control: Optional
Speed Limiter: Optional
Parking Heater: Optional
Parking Heater Preparation: Optional
Cameras: Optional

Parking Heater

Safety & Security

Seat Belt

Height Adjustable Retractor: Yes
Seat Belt Colour: Black

Feature

Driver

Passenger

Rear

Seat Belt Reminder

Driver

Other

Warranty

Manufacturer: 5 years
Paintwork: 5 years
Rust Damage: 12 years

Identification

VIN Location

Left Side Casing of Window: Yes
Right Side Casing of Window

Electronic (Multi-Point) Fuel Injection

Camshaft Type

DOHC

Engine Block

Aluminium

Engine Heads

Aluminium

Engine Cooling

Liquid Cooling

5.9 litres / 100 km

Emission NEDC

CO₂, Combined: 139 g/km

Head Room (est.), Front

1,020 mm (40.2 in)

Head Room (est.), Rear

980 mm (38.6 in)

Leg Room (est.), Rear

901 mm (35.5 in)

Weight

Gross Weight: 1,710 kg (3,770 lb)
Max Trailer Load, braked 12%: 1,300 kg (2,866 lb)
Max Trailer Load, unbraked: 550 kg (1,213 lb)
Cargo Capacity: 455 kg (1,003 lb)
Max Roof Load: 70 kg (154 lb)
Max Towbar Download: 75 kg (165 lb)

Hyundai-Kia Platforms: Small Automobile Platform (PB)

Equipment

Side Mirrors

Mirror Type: Conventional
Adjustments: Electrical
Turning Signal: Optional
House Colour: Same as Car

Windscreen Wipers

Rear Wiper: Yes
Windscreen Wipers: Connector type, Front: Push Button
Number of Windscreen Wipers, Front

Lights

Main Beam: Halogen
Low Beam: Halogen
Fog Lights: Yes

Fog Lights

Front: Yes

Fog Lights › Front

Cornering Lights: Yes

Colour

Finish: Solid

Rims & Tires

Number of Bolts: 5 pcs
Bolt Distance: 114.3
Nut/Bolt Dimensions: M12x1.5
Central Bore (CB), front: 67.1
Fastening Type: Lug Nuts
Tightening Torque: 88 - 107 Nm
Rim Type: Disc Wheel

Air Condition

Yes

Pollen Filter

Yes

Outside Temperature Indicator

Yes

Climate Control › Air Condition

Refrigerant: R1234yf
R134A

Connectivity

Radio: AM
FM
Media Format: CD
MP3
WMA
Media Inputs: USB
Bluetooth: Yes

Connectivity › Media Inputs

AUX: Yes

Displays

Center Display: Optional

Displays › Center Display

Touchscreen: Optional

Rear-view Mirror

Adjustments: Mechanical
Rear-view Mirror: Mirror Type: Standard

Interior Storage › Storage Compartments

Glove Compartment: Light
Lockable (Manual)
Armrest Hatch: Front
Back Pocket: Yes
Sunglass Compartment: Optional
Coin Holder: Yes
Card Holder: Yes
Under Seats: Optional
Door: Driver Side
Passenger Side
Rear

Interior Storage › Storage Compartments › Under Seats

Front: Optional

Interior Storage

Cup Holders: Yes

Interior Storage › Cup Holders

Front: 2
Rear: 2

Lights

Read Light: Front
Rear
Guide Light: Entry Guard

Other Equipment

Make-up Mirror: Driver Side
Passenger Side
Clock: Yes
12V Outlet: Front
Trunk
Carpets: Optional
Ashtray: Optional
Cigarette Lighter: Optional

Other Equipment › Make-up Mirror

Make-up Light: Optional

Other Equipment › Clock

Digital: Instrument Cluster

Other Equipment › 12V Outlet

Rear: Optional

Other Equipment › Carpets

Front: Optional
Rear: Optional

Other Equipment › Ashtray

Front: Optional

Steering Wheel

Multifunction Steering Wheel: Yes
Heated: Optional
Adjustments: Tilt
Telescope
Steering Mechanism: Rack and Pinion
Answer Phone: Yes
Channels: Yes
Volume: Yes
Mute Audio: Yes

Trunk

Rear Trunk: Yes

Rear Trunk

Volume: 440 litres
Volume, Back Seat Collapsed: 1,485 litres

Seats

Front Seats › Adjustments, Driver

Seat Depth: Yes
Backrest Angle: Yes
Headrest, Height: Yes

Front Seats › Adjustments, Passenger

Seat Depth: Yes
Backrest Angle: Yes
Headrest, Height: Yes

Front Seats

Cabin Heater

Optional

Parking Heater › Cabin Heater

Engine Heater: Optional
Remote: Optional

Cameras

Rear: Optional

Other Features

GPS: Optional
Horn: Dual Note

Accessories

Tool Kit and Jack: Yes
Tire Repair Kit: Optional
Compressor: Optional
Fire Extinguisher: Optional
Warning Triangle: Optional
First Aid Kit: Optional
Trunk Modules: Optional
Bicycle Holder: Optional

Yes

PassengerYes

Rear-

Belt Pretensioner

DriverYes

PassengerYes

Rear-

Belt Load Limiter

DriverYes

PassengerYes

Rear-

Height Adjustable Retractor

Manual: Yes

Type of Belt

Three-Point-Belt: Front Seats
Outer Rear Seats
Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC): Yes

Brake Systems

Power Brakes: Yes
Anti-lock Braking System (ABS): Four-channel
Traction Control System (TCS): Yes
Electronic Brake Assist (BA/EBA): Yes
Brake Pad Wear Indicator: Yes

Sensors

Parking Sensors: Optional
Light Sensor: Optional
Rain Sensors: Optional

Parking Sensors

Rear: Optional

Other Features

Immobiliser: Yes
Anti-theft Alarm: Optional
Central Locking: Remote
Child Safety Locks: Manual

Immobiliser

Electronic: Yes

Safety Testing

General

Test Year: 2011
Adult Occupant: 89 %
Child Occupant: 85 %
Vulnerable Road Users: 64 %
Safety Assist: 71 %
Overall: 5/5 stars

Airbags

Feature

Driver

Passenger

Rear

Frontal Airbag

DriverYes

PassengerYes

Rear-

Side Chest Airbag

Driver

Child Protection

Isofix: Passenger: -
Rear: Yes

Yes

Pillar

B-Pillar, Left

Passenger Seat

in Front of

Front of Hood

Yes

Car Classification

British Classification: Mini MPV
European Segment: M-Segment
Car.info Classification: Small MPV

Spare Parts BETA

Bulb Types

Low Beam: H7
Main Beam: H7
Fog Light, Front: H27W/1
Fog Light, Rear: BA15s (P21W)
Cornering Light: H7
Positioning-/Parking Lights, Front: W2.1×9.5d (W5W)
Rear/Brake Light: BAY15d (P21/5W)
Reversing Light

ix20

8.9

€67,000

MSRP · EUR

Body

2

Windows

Window Lifts, Front: Powered
Heated Windows: Rear
Heat-Insulating Windows: Front
First Row
Second Row
Rear
Tinted Windows: Optional

Windows › Tinted Windows

Second Row: Optional
Rear Window: Optional

Other Equipment

Sunroof: Optional
Normal Roof: Yes
Antenna: Whip
Electric: Optional

Heated Seats

Yes

Armrest

Middle

Second Seat Row

Collapsible: Manual
Number of Seats: 3
Height Adjustment: Yes

Second Seat Row › Collapsible

Split Fold Ratio: 60/40

Coat Hanger

Optional

Yes

PassengerYes

Rear-

Side Head Airbag

DriverYes

PassengerYes

RearYes

Curtain Airbag

DriverYes

PassengerYes

RearYes

Airbag cut-off Switch

Driver-

PassengerYes

Rear-

W2.1×9.5d (W16W)

Turn Indicators, Front

BA15s (P21W)

Turn Indicators, Side

W2.1×9.5d (W5W)

Turn Indicators, Rear

BA15s (P21W)

Read Light

W2.1×9.5d (W5W)

Trunk

W2.1×9.5d (W5W)

License Plate Light

W2.1×9.5d (W5W)

Minivan

Variant

ix20 Standard2011–2019

ix20 Minivan Generations2 of 2

Year

Powertrain

Horsepower

125 hp

Drivetrain

FWD

Fuel

Transmission
