2017 Jeep Compass

United StatesGasoline4WDSUV

Photos

Specifications

Vehicle Details

Year
2017
Make
Jeep
Model
Compass
Body Style
SUV
Generation
MP
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
4WD
Transmission
Automatic, 9-speed

Powertrain

Engine Name
200TS Automatic
Engine Configuration
Inline
Power (hp)
175 hp
Power (kW)
129 kW
Torque
228 Nm (168 lb-ft)
Top speed
190 km/h (118 mph)
Displacement
2,359 cc

Dimensions

Length
4,394 mm (173.0 in)
Width
1,819 mm (71.6 in)
Height
1,629 mm (64.1 in)
Wheelbase
2,636 mm (103.8 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,450 rpm
Rev. at Max Torque
3,900 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Engine Configuration
Inline
Synchronization
Timing Chain

Transmission & Drivetrain

Transmission
Automatic, 9-speed

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
60 litres
Fuel Consumption NEDC
Combined
8.6 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,547 mm (60.9 in)
Track, Rear
1,547 mm (60.9 in)
Turning Circle
11.07 m
Ground Clearance
198 mm (7.8 in)

Interior

Head Room, Front
995 - 981 mm (39.2 - 38.6 in)
Head Room, Rear
978 mm (38.5 in)
Leg Room, Front
1,046 mm (41.2 in)
Leg Room, Rear
973 mm (38.3 in)
Shoulder Room, Front
1,439 mm (56.7 in)
Shoulder Room, Rear
1,400 mm (55.1 in)

Weight

Max Roof Load
68 kg (150 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Fiat Platforms
Small Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
Heated
Yes
Turning Signal
Yes
Windscreen Wipers
Speed Sensing Intermittent
Yes
Intermittent Control
Yes
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered (Safety Lock)
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Safety Glass
Yes
Windows › Window Lifts, Features
Pinch Protection
  • Driver
  • Passenger
  • Rear
One-touch up/down
Driver
Windows › Tinted Windows
Windscreen, upper part
Optional
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Roof Railing
Yes
Antenna
Roof-integrated
Mud Flaps
Optional
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Fog Lights
Yes
Fog Lights
Rear
Yes
Special Features
Automatic Headlight Activation
Optional
Main Beam Assist
Optional
Come Home/Leaving Lights
Optional
Headlight Washers
Optional
Headlight Range Adjustment
Automatic (Dynamic | Semi-Static)

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Tightening Torque
135 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
  • Analogue
  • Digital
Tachometer
Analogue
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
  • AM
  • FM
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Yes
Connectivity › Radio
DAB
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Yes
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Armrest Hatch
Front
Back Pocket
Yes
Sunglass Compartment
Yes
Coin Holder
Yes
Card Holder
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
  • Front
  • Rear
Guide Light
  • Entry Guard
  • Bottom of the Doors
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front
Carpets
Optional
Ashtray
Front (Retractable)
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
Optional
Other Equipment › 12V Outlet
Trunk
Optional
Other Equipment › Carpets
Front
Optional
Rear
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion
Answer Phone
Yes
Multifunction Steering Wheel
Menu Navigation
Yes
Cruise Control
  • Speed Up/Down
  • Resume

Trunk

Rear Trunk
Yes
Release Button
Optional
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
438 litres

Design

Interior Decor Colour
Grey
Transmission Knob Material
Leather
Pedals
Standard

Seats

Colour & Material
Seat Colour
Black
Stitching Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Yes
Armrest
Middle
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Heated Seats
Optional
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Optional

Features

Comfort Features

Keyless Entry
Yes
Cruise Control
Yes
Cruise Control
Adaptive Cruise Control
Optional
Rear
Optional

Other Features

GPS
Optional
Start & Stop
Yes
Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Yes
First Aid Kit
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Optional
Lane Assist System
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Autonomous Emergency Brake System (AEB)
City
Yes
Inter-urban
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Light Sensor
Optional
Parking Sensors
Front
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2017
Adult Occupant
90 %
Child Occupant
83 %
Vulnerable Road Users
64 %
Safety Assist
59 %
Overall
5/5 stars
IIHS
Test Year
2017
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Latch Ease of Use
Poor

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
3 years
Rust Damage
7 years
Roadside Assistance
Yes

Identification

VIN Location
Left Side Casing of Window
Yes
Passenger Seat
in Front of

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV

Spare Parts BETA

Bulb Types
Low Beam
  • D3S (xenon)
  • D5S (xenon)
  • H11
  • HB3
Main Beam
HB3
Bi-Xenon
  • D3S
  • D5S
Datyime Running Light
PG20 (PSX24W)
Fog Light, Front
H11
Fog Light, Rear
W3×16d (W21W)
Rear/Brake Light
W3×16d (W21W)
Reversing Light
W3×16d (W21W)
Turn Indicators, Front
W3×16d (W21W)
Turn Indicators, Rear
W2.1×9.5d (WY16W)

ACRISS

Type
Crossover (G)
