2018 Aston Martin DB11 Volante

United KingdomGasolineRWDConvertible

Photos

Specifications

Vehicle Details

Year
2018
Make
Aston Martin
Model
DB11
Variant
Volante
Body Style
Convertible
Generation
1st Generation (AM5)
Seats
2
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 8-speed

Powertrain

Engine Name
4.0 V8 Touchtronic IV
Engine Configuration
V
Power (hp)
510 hp
Power (kW)
375 kW
Torque
675 Nm (498 lb-ft)
Top speed
300 km/h (186 mph)
0–60 mph
3.9 seconds (estimated)
0–100 km/h
4.1 seconds
Displacement
3,982 cc

Dimensions

Length
4,750 mm (187.0 in)
Width
1,950 mm (76.8 in)
Height
1,300 mm (51.2 in)
Wheelbase
2,805 mm (110.4 in)
Curb weight
1,870 kg (4,123 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
2,000 - 5,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-40
Engine Oil, Volume
10 litres
Engine Configuration
Bore
83 mm (3.3 in)
Stroke
92 mm (3.6 in)
Compression Ratio
10.5 :1
Engine Configuration
V-Engine
Turbocharger
Twin-turbo
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Fuel System
Electronic Fuel Injection
Camshaft Type
DOHC

Transmission & Drivetrain

Transmission
Automatic, 8-speed

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
  • Front (6)
  • Rear (4)
Brakes Material
Steel
Front Brakes
Diameter
400 mm (15.7 in)
Width
36 mm (1.4 in)
Cooling
Ventilated
Rear Brakes
Diameter
360 mm (14.2 in)
Width
32 mm (1.3 in)
Cooling
Ventilated

Suspensions

Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
78 litres
WLTP Consumption
Low (l/100km) (WLTP)
20.4 litres / 100 km
Medium (l/100km)
12.1 litres / 100 km
High (l/100km)
9.4 litres / 100 km
Extra High (l/100km)
9.9 litres / 100 km
Combined (l/100km)
11.6 litres / 100 km
Emission WLTP
CO₂, Combined
230 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,135 mm (84.1 in)
Track, Front
1,665 mm (65.6 in)
Track, Rear
1,645 mm (64.8 in)
Overhang, Front
945 mm (37.2 in)
Overhang, Rear
1,000 mm (39.4 in)
Turning Circle
12 m
Ground Clearance
122 mm (4.8 in)

Interior

Head Room, Front
980 mm (38.6 in)
Head Room, Rear
635 mm (25.0 in)
Leg Room, Front
1,145 mm (45.1 in)
Shoulder Room, Front
1,380 mm (54.3 in)
Shoulder Room, Rear
1,235 mm (48.6 in)

Weight

Gross Weight
2,290 kg (5,049 lb)
Cargo Capacity
420 kg (926 lb)
Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
  • Soft-top
  • Coupé-Cabriolet
Pillars
A
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Platform
Aston Martin Platform
VH Platform (IV)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
Automatic Anti-glare
  • Driver side
  • Passenger side
User Memory
Yes
Heated
Yes
Turning Signal
Yes
Mirror Shape, Driver side
Convex
Mirror Shape, Passenger side
Convex
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Rear
Other Equipment
Spoiler
Active
Antenna
Yes
Number of Exhaust Pipes
2

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
  • Main Beam Assist
  • Dynamic Cornering Lights
Cornering Lights
Yes
Fog Lights
Rear
Yes

Colour

Finish
Solid

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
128
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
75.1
Central Bore (CB), rear
75.1
Fastening Type
  • Lug Bolts
  • Lug Nuts
Tightening Torque
150 Nm
Rim Material
Alloy
Number of Spokes
10
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Digital
Tachometer
Digital
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
12"
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Micro Filter
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
5 pcs
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
  • DAB
Media Format
MP3
Bluetooth
  • Phone
  • Audio
WiFi
Yes
Connectivity › Media Inputs
AUX
Yes
USB
Yes
Connectivity › Media Inputs › USB
Number of Ports
1 pcs
Displays
Center Display
8"
Center Display Controls
Touchscreen
Equalizer
Yes
Rear-view Mirror
Anti-glare
Automatic
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Clock
Digital
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Electric
Sport
Yes
Material
Leather
Colour
Black
Steering Ratio
13 :1
Steering Mechanism
Rack and Pinion
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Yes
Mute Audio
Yes
Multifunction Steering Wheel
Menu Navigation
Yes
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down
  • Resume
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Automatic Open
  • From Inside Car
  • Key Button
Carpet
Optional
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
280 litres
Carpet
Rug
Optional

Design

Accent
Wood
Transmission Knob Material
Leather
Entry Guard Material
Aluminium
Colour
Grey

Seats

Colour & Material
Upholstery
  • Alcantara
  • Leather
Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Yes
Backrest Angle
Powered
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats
Number of Driver Seat Adjustments, Total
10
Number of Passenger Seat Adjustments, Total
10
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
Yes
Armrest
Middle (Heated)
Ventilated Seats
Optional
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Seat Height
Yes
Backrest Angle
Powered
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats › Power Seat, Driver
User Memory
3 slots
Front Seats › Power Seat, Passenger
User Memory
Yes
Front Seats › Heated Seats
Areas
  • Cushion
  • Backrest
Front Seats › Ventilated Seats
Driver
Optional
Passenger
Optional
Second Seat Row
Armrest
Yes
Number of Seats
2
Type of Seat
Adult

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Garage Remote Control
Optional
Cruise Control
Yes
Speed Limiter
Yes
Cameras
  • Front
  • Rear
Phone
Yes
Cameras
360° Camera
Yes

Other Features

GPS
Navigation
Start & Stop
Yes
Launch Control
Yes
Driving Mode Selection
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Dynamic Steering Response (DSR)
Yes
Dynamic Torque Vectoring (DTV)
Yes
Positive Torque Control (PTC)
Yes
Speed Assist
Yes
Parking Assist
Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Optional
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Anti-theft Alarm
Interior Monitoring
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: Optional
  • Rear: -

Other

Car Classification

American Classification
Convertible
British Classification
Convertible
Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

Awards

Golden Steering Wheel
The most beautiful car
2017
