2018 Mazda CX-3

JapanGasolineAWDHatchback

Photos

Specifications

Vehicle Details

Year
2018
Make
Mazda
Model
CX-3
Body Style
Hatchback
Generation
DK Facelift
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
2.0 SKYACTIV-G AWD
Engine Configuration
Inline
Power (hp)
150 hp
Power (kW)
110 kW
Torque
204 Nm (150 lb-ft)
Top speed
195 km/h (121 mph)
0–60 mph
8.4 seconds (estimated)
0–100 km/h
8.8 seconds
Displacement
1,998 cc

Dimensions

Length
4,275 mm (168.3 in)
Width
1,765 mm (69.5 in)
Height
1,535 mm (60.4 in)
Wheelbase
2,570 mm (101.2 in)
Curb weight
1,331 kg (2,934 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
2,800 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-20
  • 5W-30
Engine Configuration
Bore
83.5 mm (3.3 in)
Stroke
91.2 mm (3.6 in)
Compression Ratio
14 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Service Intervals
Air Filter
60,000 km / 3 years
Spark Plug
120,000 km (74,565 mi)
Brake Fluid
40,000 km / 2 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
100,000 km / 5 years
Transmission, Fluid
180,000 km (111,847 mi)
Interior Filter
40,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed
Gear Ratio
1st Gear
3.36 – 3.55 :1
2nd Gear
1.95 – 2.02 :1
3rd Gear
1.3 – 1.45 :1
4th Gear
1 – 1.03 :1
5th Gear
0.71 – 0.84 :1
6th Gear
0.6 – 0.68 :1
Final Drive
4.33 – 4.39 :1
Reverse
3.39 – 3.89 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
Front
Front Brakes
Diameter
295 mm (11.6 in)
Width
25 mm (1.0 in)
Cooling
Ventilated
Rear Brakes
Diameter
281 mm (11.1 in)
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
44 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 6d -TEMP
Emission Class
  • D
  • E
WLTP Consumption
Combined (l/100km)
7.4 – 8.1 litres / 100 km
Fuel Consumption NEDC
City
7.7 – 8.5 litres / 100 km
Highway
6.1 litres / 100 km
Combined
6.7 – 7 litres / 100 km
Emission WLTP
CO₂, Combined
166 – 181 g/km
Emission NEDC
CO₂, Combined
152 – 160 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,049 mm (80.7 in)
Track, Front
1,525 mm (60.0 in)
Track, Rear
1,520 mm (59.8 in)
Overhang, Front
910 mm (35.8 in)
Overhang, Rear
795 mm (31.3 in)
Turning Circle
11.4 m
Ground Clearance
155 mm (6.1 in)

Interior

Head Room, Front
976 mm (38.4 in)
Head Room, Rear
944 mm (37.2 in)
Leg Room, Front
1,058 mm (41.7 in)
Leg Room, Rear
888 mm (35.0 in)
Hip Room, Front
1,329 mm (52.3 in)
Hip Room, Rear
1,245 mm (49.0 in)
Shoulder Room, Front
1,360 mm (53.5 in)
Shoulder Room, Rear
1,281 mm (50.4 in)

Weight

Gross Weight
1773 – 1808 kg (3,909 – 3,986 lb)
Max Trailer Load, braked 12%
1,200 kg (2,646 lb)
Max Trailer Load, braked 8%
1,200 kg (2,646 lb)
Max Trailer Load, unbraked
665 – 680 kg (1,466 – 1,499 lb)
Cargo Capacity
388 – 393 - 442 – 445 kg (974 – 981 lb)
Max Roof Load
50 kg (110 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback (Crossover)
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Other Equipment
Normal Roof
Yes
Spoiler
Fixed
Antenna
Shark Fin

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Central Bore (CB), rear
67.1
Fastening Type
Lug Nuts
Tightening Torque
108 - 147 Nm
Rim Material
Alloy
Number of Spokes
5
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Digital
Tachometer
Analogue
Fuel Gauge
Digital
Oil Temperature
Digital
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Micro Filter
Yes
Outside Temperature Indicator
Yes
Controls
Faders
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
  • AM
  • FM
Media Inputs
USB
Bluetooth
Phone
Connectivity › Radio
CD
Optional
MP3
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Yes
Displays › Center Display
Type
Colour
Interior Storage › Storage Compartments
Glove Compartment
Lockable
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Other Equipment › Clock
Digital
Center Display

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Channels
Yes
Volume
Buttons
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
350 litres
Volume, Back Seat Collapsed
1,260 litres
Depth
800 mm (31.5 in)
Depth, Back Seat Collapsed
1,440 mm (56.7 in)
Width
1,000 mm (39.4 in)
Width, Between Wheel Arches
1,000 mm (39.4 in)
Opening Width
969 mm (38.1 in)
Height, to Trunk Cover
575 mm (22.6 in)

Seats

Front Seats › Adjustments, Driver
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats › Adjustments, Passenger
Backrest Angle
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes
Second Seat Row › Collapsible
Split Fold Ratio
60/40

Features

Other Features

Start & Stop
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Speed Assist
Optional
Hill Start Assist (HSA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Light Sensor
Optional
Rain Sensors
Optional

Other Features

Immobiliser
Yes
Central Locking
Remote

Safety Testing

General
Test Year
2015
Adult Occupant
85 %
Child Occupant
79 %
Vulnerable Road Users
84 %
Safety Assist
64 %
Overall
4/5 stars
IIHS
Test Year
2016
Award
Top Safety Pick
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
100,000 km / 3 years
Paintwork
3 years
Rust Damage
12 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
1 years

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
in Front of

Car Classification

American Classification
Subcompact SUV
European Segment
J-Segment JB-Segment
Car.info Classification
Small SUV

Spare Parts BETA

Bulb Types
Low Beam
H11
Main Beam
HB3
Datyime Running Light
HB3
Positioning-/Parking Lights, Front Side
W2.1×9.5d (W5W)
Positioning-/Parking Lights, Rear Side
W2.1×9.5d (W5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Rear
WX3×16d (WY21W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Category
Intermediate (I)
Type
Monoscape (M)
