2018 Suzuki Jimny

JapanGasolineAWDSUV

Photos

Specifications

Vehicle Details

Year
2018
Make
Suzuki
Model
Jimny
Body Style
SUV
Generation
GJ/HJ
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
AWD
Transmission
  • Automatic
  • Manual, 4
  • 5-speed

Powertrain

Engine Name
1.5 VVT DOHC 16v AllGrip
Engine Configuration
Inline
Power (hp)
102 hp
Power (kW)
75 kW
Torque
130 Nm (96 lb-ft)
Top speed
140 km/h (87 mph)
0–60 mph
12.2 seconds (estimated)
0–100 km/h
12.8 seconds
Displacement
1,462 cc

Dimensions

Length
3,645 mm (143.5 in)
Width
1,645 mm (64.8 in)
Height
1,705 mm (67.1 in)
Wheelbase
2,250 mm (88.6 in)
Curb weight
1,165 kg (2,568 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-16
  • 0W-20
  • 5W-30
Semi-synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
3.6 litres
Engine Configuration
Bore
74 mm (2.9 in)
Stroke
85 mm (3.3 in)
Compression Ratio
10 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Service Intervals
Oil Change & Engine Filter
20,000 km / 1 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 4
  • 5-speed

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Brakes Material
Steel

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Dependent
Beam Axle
Suspension, Rear
Dependent
Beam Axle

Fuel

General
Tank Volume
40 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 6d -ISC-FCM
Emission Class
F
WLTP Consumption
Low (l/100km) (WLTP)
8.1 – 9.8 litres / 100 km
Medium (l/100km)
6.7 – 7.6 litres / 100 km
High (l/100km)
6.8 – 7.7 litres / 100 km
Extra High (l/100km)
8.9 – 10 litres / 100 km
Combined (l/100km)
7.7 – 8.8 litres / 100 km
Fuel Consumption NEDC
City
7.7 – 8.4 litres / 100 km
Highway
6.2 – 6.9 litres / 100 km
Combined
6.8 – 7.5 litres / 100 km
Emission WLTP
CO₂, Combined
178 – 198 g/km
Emission NEDC
CO₂, Combined
154 – 170 g/km

Dimensions & Weight

Exterior

Track, Front
1,395 mm (54.9 in)
Track, Rear
1,405 mm (55.3 in)
Turning Circle
9.8 m
Ground Clearance
205 mm (8.1 in)

Interior

Head Room (est.), Rear
980 mm (38.6 in)
Leg Room (est.), Rear
700 mm (27.6 in)

Weight

Gross Weight
1,435 kg (3,164 lb)
Max Trailer Load, braked 12%
1,300 kg (2,866 lb)
Max Trailer Load, unbraked
350 kg (772 lb)
Cargo Capacity
250 – 270 kg (551 – 595 lb)
Max Roof Load
30 kg (66 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-C
Chassis Construction
Body-on-Frame (Ladder Frame)
Doors
Front Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Manual
House Colour
Black
Windscreen Wipers
Number of Wiper Speeds
2
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Yes
Antenna
Whip
Mud Flaps
Optional
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Rear Lights
Halogen
Daytime Running Light
LED
Special Features
  • Automatic Headlight Activation
  • Main Beam Assist
Special Features
Headlight Washers
Optional
Headlight Range Adjustment
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
139.7
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
108.1
Central Bore (CB), rear
108.1
Fastening Type
Lug Nuts
Tightening Torque
100 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Number of Climate Zones
1
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
  • Buttons
  • Rotary Dials
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
FM
Media Format
  • CD
  • MP3
  • WMA
App-Connect
Optional
Bluetooth
  • Phone
  • Audio
Connectivity › Media Inputs
USB
USB-A
Connectivity › App-Connect
Android Auto
Optional
Apple CarPlay
Optional
Displays
Center Display
7"
Displays › Center Display
Touchscreen
Optional
Rear-view Mirror
Anti-glare
Manual
Interior Storage › Storage Compartments
Glove Compartment
Yes
Card Holder
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › 12V Outlet
Rear
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
Tilt
Number of Spokes
3
Colour
Black
Steering Mechanism
Recirculating Ball
Multifunction Steering Wheel
Menu Navigation
Buttons
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down (Buttons)
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Buttons

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
377 litres
Volume, Back Seat Collapsed
830 litres
Depth
220 mm (8.7 in)
Depth, Back Seat Collapsed
948 mm (37.3 in)
Width
1,024 mm (40.3 in)
Width, Between Wheel Arches
1,010 mm (39.8 in)
Height
769 mm (30.3 in)
Sill Height
833 mm (32.8 in)

Seats

Colour & Material
Upholstery
Textile
Seat Colour
Grey
Front Seats › Adjustments, Driver
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Split Fold Ratio
50/50

Features

Comfort Features

Cruise Control
Yes
Speed Limiter
Yes

Other Features

GPS
Optional

Accessories

Trunk Modules
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Front Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Speed Assist
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Autonomous Emergency Brake System (AEB)
Pedestrian
Yes
Inter-urban
Yes

Sensors

Light Sensor
Yes
Rain Sensors
Optional

Safety Testing

General
Test Year
2018
Adult Occupant
73 %
Child Occupant
84 %
Vulnerable Road Users
52 %
Safety Assist
50 %
Overall
3/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
100,000 km / 3 years
Body Protection
3 years
Paintwork
3 years
Rust Damage
12 years

Identification

VIN Location
Engine Compartment, Bulkhead
  • Left
  • Right
Left Side Casing of Window
Yes
Longerun Frame
Behind Right Rear Wheel

Car Classification

American Classification
Mini SUV
British Classification
Mini 4x4
Australian Classification
Small SUV
European Segment
J-Segment JB-Segment
Car.info Classification
Small SUV

ACRISS

Category
Economy (E)
Type
Crossover (G)

Awards

World
Urban Car
2019

Tests

Autotest
Body/Trunk
3.5
Interior
3.2
Comfort
4
Motor/Drivetrain
3.5
Driving Characteristics
4.8
Environment/EcoTest
3.2
Security
2.8
Judgment Technology/Environment
3.5
Judgment Technology/Environment
Satisfactory
Judgment Car Cost
1.6
Judgment Car Cost
Good
