2018 Vauxhall Zafira

United KingdomGasolineFWDMinivan

Photos

Specifications

Vehicle Details

Year
2018
Make
Vauxhall
Model
Zafira
Body Style
Minivan
Generation
C Facelift
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
Tourer 1.4 Turbo
Engine Configuration
Inline
Power (hp)
140 hp
Power (kW)
103 kW
Torque
200 Nm (148 lb-ft)
Top speed
197 km/h (122 mph)
0–60 mph
9.9 seconds
0–100 km/h
10.8 seconds
Displacement
1,364 cc

Dimensions

Length
4,666 mm (183.7 in)
Width
1,884 mm (74.2 in)
Height
1,685 mm (66.3 in)
Wheelbase
2,760 mm (108.7 in)
Curb weight
1,655 kg (3,649 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,900 - 6,000 rpm
Rev. at Max Torque
1,850 - 4,900 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
Engine Configuration
Bore
72.5 mm (2.9 in)
Stroke
82.6 mm (3.3 in)
Compression Ratio
9.5 :1
Engine Configuration
Inline
Turbocharger
Yes

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
Front
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut

Fuel

General
Tank Volume
58 litres
Lockable Fuel Cap
Yes
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 6
Fuel Consumption NEDC
City
8.5 – 9.3 litres / 100 km
Highway
5.6 – 5.7 litres / 100 km
Combined
6.8 – 6.9 litres / 100 km
Emission NEDC
CO₂, Combined
156 – 160 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,100 mm (82.7 in)
Track, Front
1,584 mm (62.4 in)
Track, Rear
1,588 mm (62.5 in)
Overhang, Front
999 mm (39.3 in)
Overhang, Rear
907 mm (35.7 in)
Turning Circle
11.4 m

Weight

Gross Weight
2310 – 2340 kg (5,093 – 5,159 lb)
Max Trailer Load, braked 12%
1300 – 1550 kg (2,866 – 3,417 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
655 – 685 kg (1,444 – 1,510 lb)
Max Roof Load
100 kg (220 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Roof Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
User Memory
Optional
Heated
Yes
Turning Signal
Yes
Side Mirrors › Adjustments
Driver side
Optional
Windscreen Wipers
Intermittent Control
Yes
Heated Water Tank
Optional
Rear Wiper
Yes
Rear Washer System
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered (Safety Lock)
Heated Windows
Rear
Tinted Windows
Optional
Safety Glass
Yes
Windows › Window Lifts, Features
Pinch Protection
  • Driver
  • Passenger
One-touch up/down
  • Driver
  • Passenger
  • Rear
Windows › Heated Windows
Front
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Roof Railing
Optional
Antenna
Shark Fin
Mud Flaps
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Rims & Tires

Tightening Torque
140 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Outside Temperature Indicator
Yes
Controls
  • Buttons
  • Faders
Climate Control › Air Condition
Refrigerant
R1234yf
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable (Manual)
Armrest Hatch
Front
Back Pocket
Yes
Sunglass Compartment
Yes
Under Seats
Front
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
  • Front
  • Rear
Guide Light
Entry Guard
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
  • Front
  • Rear
  • Trunk
Carpets
Optional
Cigarette Lighter
Optional
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster
Other Equipment › Carpets
Front
Optional
Rear
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electro-mechanical
Adjustments
  • Tilt
  • Telescope
Number of Spokes
4
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Cruise Control
Yes
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Yes

Trunk

Rear Trunk
Yes
Cover
Yes
Carpet
Optional
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
710 litres
Volume, Back Seat Collapsed
1,860 litres
Volume (third seat row)
152 litres
Depth
950 mm (37.4 in)
Depth, Back Seat Collapsed
1,842 mm (72.5 in)
Width
1,057 mm (41.6 in)
Opening Width
1,045 mm (41.1 in)
Height
900 mm (35.4 in)
Sill Height
654 mm (25.7 in)
Carpet
Rubber
Optional

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
  • From Trunk
  • On Top of Backrest
Split Fold Ratio
35/30/35
Heated Seats
Optional
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Manual
Second Seat Row › Headrests › Centre Seat
Height Adjustment
Yes
Third/Fourth Seat Row
Third Seat Row
Optional

Safety & Security

Safety Testing

General
Test Year
2011
Adult Occupant
94 %
Child Occupant
83 %
Vulnerable Road Users
53 %
Safety Assist
86 %
Overall
5/5 stars

Other

Car Classification

American Classification
Minivan
British Classification
Large MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Large MPV
