2018 Volkswagen C-Trek

GermanyGasolineFWDCrossover

Photos

Specifications

Vehicle Details

Year
2018
Make
Volkswagen
Model
C-Trek
Body Style
Crossover
Generation
1st Generation (Type 15)
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic Dual-clutch
  • Manual, 5
  • 7-speed

Powertrain

Engine Name
230TSI
Engine Configuration
Inline
Power (hp)
131 hp
Power (kW)
96 kW
Torque
225 Nm (166 lb-ft)
Top speed
200 km/h (124 mph)
0–60 mph
8.9 seconds (estimated)
0–100 km/h
9.3 seconds
Displacement
1,395 cc

Dimensions

Length
4,559 mm (179.5 in)
Width
1,793 mm (70.6 in)
Height
1,487 mm (58.5 in)
Wheelbase
2,614 mm (102.9 in)
Curb weight
1,335 kg (2,943 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,000 rpm
Rev. at Max Torque
1,400 - 3,500 rpm
Engine Configuration
Bore
74.5 mm (2.9 in)
Stroke
80 mm (3.1 in)
Engine Configuration
Inline
Turbocharger
Single-turbo
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
  • Automatic Dual-clutch
  • Manual, 5
  • 7-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
Front
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Semi-dependent
Twist-Beam

Fuel

General
Tank Volume
55 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
Combined
5.6 – 5.8 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,518 mm (59.8 in)
Track, Rear
1,525 mm (60.0 in)
Turning Circle
11.1 m
Ground Clearance
132 mm (5.2 in)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon (Crossover)
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Volkswagen Group
A Platform (PQ34)

Interior

Steering Wheel

Power Steering
Electro-mechanical
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
589 litres
Volume, Back Seat Collapsed
1,507 litres

Seats

Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes
Second Seat Row › Headrests › Centre Seat
Height Adjustment
Yes
