2019 Fiat 500X

Italy Diesel AWD Crossover

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2019
Make: Fiat
Model: 500X
Body Style: Crossover

Photos

Specifications

Vehicle Details Powertrain Dimensions Engine & Performance Dimensions & Weight Exterior Interior Features Safety & Security Other

Vehicle Details

Year: 2019
Make: Fiat
Model: 500X
Body Style: Crossover

Generation

334 1st Facelift

Seats

5

Doors

5

Fuel

Diesel

Drivetrain

AWD

Transmission

Automatic, 9-speed

Powertrain

Engine Name: 2.0 Multijet 4x4 Automatic
Engine Configuration: Inline
Power (hp): 150 hp
Power (kW): 110 kW
Torque: 350 Nm (258 lb-ft)
Top speed: 183 km/h (114 mph)
0–60 mph: 9.6 seconds (estimated)
0–100 km/h: 10.1 seconds

Dimensions

Length: 4,265 mm (167.9 in)
Width: 1,796 mm (70.7 in)
Height: 1,620 mm (63.8 in)
Wheelbase: 2,570 mm (101.2 in)
Curb weight: 1,615 kg (3,560 lb)

Engine & Performance

Engine

Engine Specification

Rev. at Max Power: 4,000 rpm
Rev. at Max Torque: 1,500 rpm

Engine Configuration

Bore: 83 mm (3.3 in)
Stroke: 90.4 mm (3.6 in)
Compression Ratio

Similar crossovers

Suggested vehicles

View all

2019 Ford Territory

Displacement

1,956 cc

16.5 :1

Engine Configuration

Inline

Service Intervals

Fuel Filter: 40,000 km (24,855 mi)
Brake Fluid: 2 years
Oil Change & Engine Filter: 15,000 km / 1 years
Transmission, Fluid: 4 years
Interior Filter: 30,000 km / 1 years

Transmission & Drivetrain

Transmission: Automatic, 9-speed

Suspensions

Suspension, Front

Independent: MacPherson Strut

Suspension, Rear

Independent: MacPherson Strut

Fuel

General

Tank Volume: 48 litres

Emission

Emission Standard: Euro 6d

Fuel Consumption NEDC

City: 7.6 litres / 100 km
Highway: 5.7 litres / 100 km
Combined: 6.4 litres / 100 km

Emission NEDC

Dimensions & Weight

Exterior

Width, with Mirrors: 2,025 mm (79.7 in)
Track, Front: 1,545 mm (60.8 in)
Track, Rear: 1,545 mm (60.8 in)
Turning Circle: 11.5 m
Ground Clearance: 157 mm (6.2 in)

Exterior

Chassis & Body

Chassis

Chassis: Station Wagon (Crossover)
Pillars: A-C
Chassis Construction: Unibody

Doors

Front Doors: Conventional
Rear Doors: Conventional

Platform

Interior

Equipment

Instrument Cluster

Trip Computer: Yes
Speedometer: Analogue
Tachometer: Analogue

Instrument Cluster › Trip Computer

Display: Yes

Connectivity

Features

Other Features

Start & Stop: Yes

Safety & Security

Airbags

Other Airbags

Pedestrian Airbag: No
Door-mounted Airbags: No
Seat Belt Airbag: No
Seat Cushion: No

Feature

Driver

Passenger

Other

Warranty

Manufacturer: 3 years
Paintwork: 3 years
Rust Damage: 8 years

Car Classification

American Classification: Subcompact SUV
European Segment: J-Segment JB-Segment

CO₂, Combined

168 g/km

Interior

Head Room (est.), Rear: 980 - 1,000 mm (38.6 - 39.4 in)
Leg Room (est.), Rear: 820 - 860 mm (32.3 - 33.9 in)

Weight

Gross Weight: 2,050 kg (4,519 lb)
Max Trailer Load, braked 12%: 1,200 kg (2,646 lb)
Max Trailer Load, unbraked: 600 kg (1,323 lb)
Cargo Capacity: 435 kg (959 lb)
Max Roof Load: 50 kg (110 lb)

Fiat Platforms: Small Platform

Equipment

Side Mirrors

Mirror Type: Conventional
Adjustments: Electrical

Windscreen Wipers

Rear Wiper: Yes

Windows

Window Lifts, Front: Powered
Window Lifts, Rear: Powered
Heated Windows

Colour

Finish: Solid

Rims & Tires

Tightening Torque: 120 Nm
Rim Type: Disc Wheel

Radio

AM
FM

Displays

Center Display: Yes

Rear-view Mirror

Anti-glare: Automatic

Interior Storage › Storage Compartments

Glove Compartment: Yes

Interior Storage

Cup Holders: Yes

Interior Storage › Cup Holders

Front: Yes

Interior Storage › Cup Holders › Front

Placement: Middle Console

Lights

Read Light: Front

Other Equipment

12V Outlet: Front

Steering Wheel

Multifunction Steering Wheel: Yes
Power Steering: Electric
Adjustments: Tilt
Colour: Black
Channels: Yes
Volume: Yes
Mute Audio: Yes

Trunk

Rear Trunk: Yes
Flat Surface: Yes
Light: Yes

Rear Trunk

Volume: 350 litres
Volume, Back Seat Collapsed: 1,000 litres

Seats

Front Seats › Adjustments, Driver

Seat Depth: Yes
Backrest Angle: Yes
Headrest, Height: Yes

Front Seats › Adjustments, Passenger

Seat Depth: Yes
Backrest Angle: Yes
Headrest, Height: Yes

Second Seat Row

Rear

Frontal Airbag

DriverYes

PassengerYes

Rear-

Side Chest Airbag

DriverYes

PassengerYes

Rear-

Seat Belt

Type of Belt

Three-Point-Belt: Yes

Seat Belt Colour: Black

Feature

Driver

Passenger

Rear

Seat Belt Reminder

DriverYes

Assist Systems

Electronic Stability Control (ESC): Yes
Lane Assist System: Optional
Speed Assist: Yes

Brake Systems

Autonomous Emergency Brake System (AEB): Optional
Anti-lock Braking System (ABS): Four-channel
Traction Control System (TCS): Yes
Electronic Brakeforce Distribution (EBD): Yes
Electronic Brake Assist (BA/EBA): Yes

Sensors

Parking Sensors: Rear
Blind Spot Detection (BLIS): Optional
Light Sensor: Optional
Rain Sensors: Optional

Other Features

Active Bonnet: No

Safety Testing

General

Test Year: 2015
Adult Occupant: 86 %
Child Occupant: 85 %
Vulnerable Road Users: 74 %
Safety Assist: 64 %
Overall: 4/5 stars
Test Year: 2016
Overall Score

Child Protection

Feature

Passenger

Rear

Isofix

PassengerNo

RearYes

Integrated Child Seat

PassengerNo

Car.info Classification

Small SUV

ACRISS

Type: Crossover (G)

500X

8.9

€67,000

MSRP · EUR

Body

Rear

Heat-Insulating Windows

Front
First Row
Second Row
Rear

Tinted Windows

Optional

Windows › Tinted Windows

Second Row: Optional
Rear Window: Optional

Other Equipment

Normal Roof: Yes
Roof Railing: Optional
Spoiler: Fixed

Number of Seats

3

Type of Seat

Adult

Side Head Airbag

DriverYes

PassengerYes

RearYes

Side Pelvis Airbag

DriverNo

PassengerNo

RearNo

Knee Airbag

DriverNo

PassengerNo

RearNo

Curtain Airbag

DriverNo

PassengerNo

RearNo

Center Airbag

DriverNo

PassengerNo

RearNo

Airbag cut-off Switch

Driver-

PassengerYes

Rear-

Passenger

Yes

RearYes

Belt Pretensioner

DriverYes

PassengerYes

RearYes

Belt Load Limiter

DriverYes

PassengerYes

RearYes

36.12

ANCAP Safety Rating

5

Adult Occupant

Frontal Offset: 15.12
Side Impact: 16
Pole: 2
Whiplash Protection (Assessment): Good

Pedestrian

Protection (Assessment): Acceptable

Safety Assist

Seat Belt Reminders: 3

IIHS

Test Year: 2020
Roof Strength: Good
Headlight: Poor

RearNo

Crossover

Variant

500X Standard2015–2024

500X Crossover Generations2 of 3

Year

Powertrain

Horsepower

150 hp

Drivetrain

AWD

Fuel

Diesel

Transmission

Automatic, 9-speed
