2019 Ford Edge

United StatesGasolineAWDSUV

Photos

Specifications

Vehicle Details

Year
2019
Make
Ford
Model
Edge
Body Style
SUV
Generation
2nd Generation Facelift
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic, 8-speed

Powertrain

Engine Name
2.0 EcoBoost AWD SelectShift
Engine Configuration
Inline
Power (hp)
254 hp
Power (kW)
186 kW
Torque
350 Nm (258 lb-ft)
Top speed
192 km/h (119 mph)
0–60 mph
9.0 seconds (estimated)
0–100 km/h
9.5 seconds
Displacement
1,999 cc

Dimensions

Length
4,834 mm (190.3 in)
Width
1,928 mm (75.9 in)
Height
1,732 mm (68.2 in)
Wheelbase
2,848 mm (112.1 in)
Curb weight
2,030 kg (4,475 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
1,750 - 4,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
  • 15W-40
  • 20W-40
Engine Configuration
Engine Configuration
Inline
Turbocharger
Yes
Service Intervals
Air Filter
48,000 km (29,826 mi)
Fuel Filter
160,000 km (99,419 mi)
Spark Plug
160,000 km (99,419 mi)
Brake Fluid
3 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
160,000 km / 6 years
Interior Filter
15,000 km / 1 years

Transmission & Drivetrain

Transmission
Automatic, 8-speed

Fuel

General
Tank Volume
69 litres
Fuel Consumption NEDC
Combined
9.4 litres / 100 km

Dimensions & Weight

Exterior

Width, with Mirrors
2,184 mm (86.0 in)
Track, Front
1,655 mm (65.2 in)
Track, Rear
1,664 mm (65.5 in)
Turning Circle
11.9 m
Ground Clearance
186 mm (7.3 in)

Interior

Head Room, Front
1,020 mm (40.2 in)
Head Room, Rear
1,023 mm (40.3 in)
Leg Room, Front
1,081 mm (42.6 in)
Leg Room, Rear
1,030 mm (40.6 in)
Hip Room, Front
1,420 mm (55.9 in)
Hip Room, Rear
1,461 mm (57.5 in)
Shoulder Room, Front
1,531 mm (60.3 in)
Shoulder Room, Rear
1,536 mm (60.5 in)

Weight

Max Roof Load
45 kg (99 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Ford Motor Company
CD4 Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Roof Railing
Optional
Spoiler
Fixed
Antenna
Shark Fin
Number of Exhaust Pipes
2

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Number of Bolts
5 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
63.4
Central Bore (CB), rear
63.4
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
220 Nm
Rim Material
Alloy
Rim Type
Disc Wheel
Tire Pressure Monitoring System (TPMS)
Direct
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Lights
Read Light
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Colour
Black
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
602 litres
Volume, Back Seat Collapsed
1,688 litres
Width, Between Wheel Arches
1,150 mm (45.3 in)

Seats

Colour & Material
Seat Colour
Black
Stitching Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Features

Accessories

Warning Triangle
Yes
First Aid Kit
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Parking Assist
Optional

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes
City
Yes
Inter-urban
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Light Sensor
Yes
Rain Sensors
Yes

Safety Testing

General
Test Year
2016
Adult Occupant
85 %
Child Occupant
76 %
Vulnerable Road Users
67 %
Safety Assist
89 %
Overall
5/5 stars
IIHS
Test Year
2016
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Headlight
Poor
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
2 years
Body Protection
3 years
Paintwork
2 years
Rust Damage
12 years

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
  • B-Pillar, Left
  • B-Pillar, Right
Passenger Seat
in Front of

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment JD-Segment
Car.info Classification
Large SUV

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
H15
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Cornering Light
H11
Positioning-/Parking Lights, Front Side
W2.1×9.5d (W5W)
Rear/Brake Light
  • BAY15d (P21/5W)
  • W2.1×9.5d (W16W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Side
W2.1×9.5d (WY5W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)
