2019 Hyundai Ioniq

South KoreaHybrid GasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2019
Make
Hyundai
Model
Ioniq
Body Style
Hatchback
Generation
AE
Seats
5
Doors
5
Fuel
Hybrid Gasoline
Drivetrain
FWD
Transmission
Automatic (Dual-clutch), 6-speed

Powertrain

Engine Name
Hybrid DCT
Engine Configuration
Inline
Power (hp)
141 hp
Power (kW)
104 kW
Torque
147 Nm (108 lb-ft)
Top speed
185 km/h (115 mph)
0–60 mph
10.3 seconds (estimated)
0–100 km/h
10.8 seconds
Battery
1.56 kWh
Displacement
1,580 cc

Dimensions

Length
4,470 mm (176.0 in)
Width
1,820 mm (71.7 in)
Height
1,450 mm (57.1 in)
Wheelbase
2,700 mm (106.3 in)
Curb weight
1,445 kg (3,186 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,700 rpm
Rev. at Max Torque
4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 5W-30
Semi-synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
3.8 litres
Configuration Combustion
Bore
78 mm (3.1 in)
Stroke
97 mm (3.8 in)
Compression Ratio
13 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Configuration Electric
Type of Electric Car
Hybrid
Electric Engine Power
32 kW
Electric Engine Horsepower (Metric)
44 hp
Torque
147 Nm (108 lb-ft)
Front Engines
Yes
Battery Capacity, Gross
1.56 kWh
Type of Battery
Li-ion
Configuration Electric › Front Engines
Power (kW)
32 kW
Horsepower
44 hp
Number of Engines
1
Service Intervals
Air Filter
45,000 km / 3 years
Spark Plug
165,000 km (102,526 mi)
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
30,000 km / 2 years
Interior Filter
30,000 km / 2 years
Accessory Belt
105,000 km / 4 years

Transmission & Drivetrain

Transmission
Automatic (Dual-clutch), 6-speed

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
45 litres
Emission
Emission Standard
Euro 6
Emission Class
A+
Emission WLTP
CO₂, Combined
102 - 105 g/km
Emission NEDC
CO₂, Combined
79 - 92 g/km
Fuel Consumption NEDC
City
3.8 litres / 100 km
Highway
4.5 litres / 100 km
Combined
4.2 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,555 mm (61.2 in)
Track, Rear
1,564 mm (61.6 in)
Turning Circle
10.6 m
Ground Clearance
140 mm (5.5 in)

Interior

Head Room, Front
1,024 mm (40.3 in)
Head Room, Rear
950 mm (37.4 in)
Leg Room, Front
1,136 mm (44.7 in)
Leg Room, Rear
906 mm (35.7 in)
Hip Room, Front
1,366 mm (53.8 in)
Hip Room, Rear
1,344 mm (52.9 in)
Shoulder Room, Front
1,425 mm (56.1 in)
Shoulder Room, Rear
1,396 mm (55.0 in)

Weight

Gross Weight
1,870 kg (4,123 lb)
Cargo Capacity
425 kg (937 lb)
Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Hyundai-Kia Platforms
J Platform (Eco-Car)

Equipment

Side Mirrors
Turning Signal
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Other Equipment
Sunroof
Optional
Normal Roof
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Tightening Torque
108 - 127 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
Yes
Media Inputs
USB
App-Connect
  • Yes
  • Optional
Bluetooth
Yes
Connectivity › Media Inputs
AUX
Yes
Connectivity › App-Connect
Android Auto
Optional
Apple CarPlay
Optional
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
563 litres
Volume, Back Seat Collapsed
1,518 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Seat Height
Optional
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats
Heated Seats
Optional
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Heated Seats › Cushion
Backrest
Optional
Second Seat Row
Collapsible
Yes
Second Seat Row › Collapsible
Heated Seats
Optional

Features

Comfort Features

Keyless Start
Yes
Cruise Control
Adaptive Cruise Control
Parking Heater
Optional
Parking Heater
Cabin Heater
Optional
Parking Heater › Cabin Heater
Engine Heater
Optional
Remote
Optional
Timer
Optional

Other Features

GPS
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Autonomous Emergency Brake System (AEB)
Pedestrian
Yes
City
Yes
Inter-urban
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Test Year
2016
Adult Occupant
91 %
Child Occupant
80 %
Vulnerable Road Users
70 %
Safety Assist
82 %
Overall
5/5 stars
Test Year
2016
ANCAP Safety Rating
5
ASEAN NCAP
Test Year
2018
Overall
5/5 stars
Adult Occupant, Points
46.34
Child Occupant, Points
21.48
Safety Assist, Points
24.17
Adult Occupant
Protection
91 %
Protection
34.9
Full Width
6.16
Frontal Offset
7.45
Side Impact
8
Pole
8
Whiplash Protection (Front)
2.31
AEB (City)
3
Child Occupant
Protection
80 %
Protection
39.4
Pedestrian
Protection
70 %
Protection
29.8
Safety Assist
Safety Assist
82 %
Safety Assist
9.9
Speed Assistance System
1.5
Seat Belt Reminders
3
Lane Support System
2.7
AEB (Interurban)
2.7
IIHS
Test Year
2017
Award
Top Safety Pick
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car

ACRISS

Category
Intermediate (I)
Type
4-5 Doors (D)
