2019 Hyundai Santa Fe

South KoreaGasolineFWDSUV

Photos

Specifications

Vehicle Details

Year
2019
Make
Hyundai
Model
Santa Fe
Body Style
SUV
Generation
TM
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic, 8-speed

Powertrain

Engine Name
2.0 Turbo Automatic
Engine Configuration
Inline
Power (hp)
243 hp
Power (kW)
179 kW
Torque
353 Nm (260 lb-ft)
Top speed
218 km/h (135 mph)
0–60 mph
7.3 seconds (estimated)
0–100 km/h
7.7 seconds
Displacement
1,998 cc

Dimensions

Length
4,770 mm (187.8 in)
Width
1,890 mm (74.4 in)
Height
1,705 mm (67.1 in)
Wheelbase
2,765 mm (108.9 in)
Curb weight
1,778 kg (3,920 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
1,450 - 3,500 rpm
Engine Configuration
Bore
86 mm (3.4 in)
Stroke
86 mm (3.4 in)
Compression Ratio
10 :1
Engine Configuration
Inline
Turbocharger
Yes

Transmission & Drivetrain

Transmission
Automatic, 8-speed

Fuel

General
Tank Volume
71 litres
Fuel Consumption NEDC
City
11.8 litres / 100 km
Highway
8.7 litres / 100 km
Combined
10.2 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,643 mm (64.7 in)
Track, Rear
1,652 mm (65.0 in)
Ground Clearance
185 mm (7.3 in)

Interior

Head Room, Front
1,046 mm (41.2 in)
Head Room, Rear
995 mm (39.2 in)
Leg Room, Front
1,120 mm (44.1 in)
Leg Room, Rear
1,040 mm (40.9 in)
Hip Room, Front
1,460 mm (57.5 in)
Hip Room, Rear
1,430 mm (56.3 in)
Shoulder Room, Front
1,500 mm (59.1 in)
Shoulder Room, Rear
1,480 mm (58.3 in)
Head Room (est.), Third Row
907 mm (35.7 in)
Leg Room (est.), Third Row
785 mm (30.9 in)

Weight

Gross Weight
2,190 kg (4,828 lb)
Cargo Capacity
412 kg (908 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)

Rims & Tires

Tightening Torque
107 - 127 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
  • AM
  • FM
Rear-view Mirror
Anti-glare
Automatic
Interior Storage › Storage Compartments
Glove Compartment
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Lights
Read Light
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
625 litres
Volume, Back Seat Collapsed
1,695 litres
Volume (third seat row)
547 litres
Volume (Opt. third seat row, Collapsed seat)
1,625 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Third/Fourth Seat Row
Third Seat Row
Optional

Safety & Security

Airbags

Other Airbags
Pedestrian Airbag
No
Door-mounted Airbags
No
Seat Belt Airbag
No
Seat Cushion
No
Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Center Airbag
Airbag cut-off Switch

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Lane Assist System
Yes
Speed Assist
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Autonomous Emergency Brake System (AEB)
Pedestrian
Yes
Cyclist
Yes
City
Yes
Inter-urban
Yes

Other Features

Active Bonnet
No

Safety Testing

General
Test Year
2018
Adult Occupant
94 %
Child Occupant
88 %
Vulnerable Road Users
67 %
Safety Assist
76 %
Overall
5/5 stars
Test Year
2018
ANCAP Safety Rating
5
Adult Occupant
Protection
94 %
Protection
35.9
Full Width
7.81
Frontal Offset
7.91
Side Impact
7.5
Pole
7.33
Whiplash Protection (Front)
1.25
Whiplash Protection (Rear)
0.09
AEB (City)
4
Child Occupant
Protection
89 %
Protection
42.2
Dynamic (Front)
15.15
Dynamic (Side)
8
Child Restraint Installation
12
On-Board Features
7
Pedestrian
Protection
67 %
Protection
32.2
Head Impact
15.1
Upper Leg Impact
4.96
Lower Leg Impact
5.34
AEB VRU (Pedestrian)
4.1
AEB VRU (Cyclist)
2.67
Safety Assist
Safety Assist
78 %
Safety Assist
10.1
Speed Assistance System
1.25
Seat Belt Reminders
2.9
Lane Support System
3.5
AEB (Interurban)
2.49
IIHS
Test Year
2019
Award
Top Safety Pick+
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Latch Ease of Use
Acceptable

Child Protection

Feature
Isofix
Integrated Child Seat

Other

Warranty

Manufacturer
5 years
Paintwork
5 years
Rust Damage
12 years

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Front of Hood
Yes

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment JD-Segment
Car.info Classification
Large SUV

Spare Parts BETA

Bulb Types
Low Beam
HB3
Main Beam
HB3
Fog Light, Front
H8
Fog Light, Rear
W2.1×9.5d (W16W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)
