2019 Volkswagen Teramont

GermanyGasolineAWDSUV

Photos

Specifications

Vehicle Details

Year
2019
Make
Volkswagen
Model
Teramont
Body Style
SUV
Generation
1st Generation (Type CA)
Seats
7
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic (Manumatic), 8-speed

Powertrain

Engine Name
3.6 V6 FSI 4Motion TipTronic
Engine Configuration
V
Power (hp)
249 hp
Power (kW)
183 kW
Torque
360 Nm (266 lb-ft)
Top speed
190 km/h (118 mph)
0–60 mph
8.5 seconds (estimated)
0–100 km/h
8.9 seconds
Displacement
3,598 cc

Dimensions

Length
5,036 mm (198.3 in)
Width
1,989 mm (78.3 in)
Height
1,769 mm (69.6 in)
Wheelbase
2,979 mm (117.3 in)
Curb weight
2,105 kg (4,641 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,000 rpm
Rev. at Max Torque
3,500 rpm
Engine Configuration
Bore
89 mm (3.5 in)
Stroke
96.4 mm (3.8 in)
Compression Ratio
11.4 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
Automatic (Manumatic), 8-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
5.59 :1
2nd Gear
3.14 :1
3rd Gear
1.95 :1
4th Gear
1.43 :1
5th Gear
1.21 :1
6th Gear
1 :1
7th Gear
0.81 :1
8th Gear
0.67 :1
Final Drive
3.6 :1
Reverse
3.99 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
335 mm (13.2 in)
Width
30 mm (1.2 in)
Cooling
Ventilated
Rear Brakes
Diameter
310 mm (12.2 in)
Width
23 mm (0.9 in)
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
Front
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
70 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 5
Emission Control
  • Catalyst
  • Particle Filter
  • Evaporative Control System
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
City
14.4 litres / 100 km
Highway
8.4 litres / 100 km
Combined
10.6 litres / 100 km
Emission NEDC
CO₂, Combined
247 g/km

Performance

Drag Coefficient
0.34

Dimensions & Weight

Exterior

Track, Front
1,708 mm (67.2 in)
Track, Rear
1,723 mm (67.8 in)
Approach Angle
20.4 °
Breakover Angle
17.5
Departure Angle
22.4 °
Turning Circle
12.4 m
Ground Clearance
203 mm (8.0 in)

Interior

Head Room, Front
1,048 mm (41.3 in)
Head Room, Rear
1,027 mm (40.4 in)
Head Room, Third Row
972 mm (38.3 in)
Leg Room, Front
1,055 mm (41.5 in)
Leg Room, Rear
955 mm (37.6 in)
Leg Room, Third Row
856 mm (33.7 in)
Hip Room, Front
1,479 mm (58.2 in)
Hip Room, Rear
1,474 mm (58.0 in)
Hip Room, Third Row
1,145 mm (45.1 in)
Shoulder Room, Front
1,563 mm (61.5 in)
Shoulder Room, Rear
1,544 mm (60.8 in)
Shoulder Room, Third Row
1,395 mm (54.9 in)

Weight

Gross Weight
2,700 kg (5,952 lb)
Cargo Capacity
670 kg (1,477 lb)
Permitted Axle Load, front
1,320 kg (2,910 lb)
Permitted Axle Load, rear
1,400 kg (3,086 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Volkswagen Group
MQB Platform

Interior

Steering Wheel

Power Steering
Electro-mechanical
Steering Ratio
16.3 :1
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
583 litres
Volume, Back Seat Collapsed
2,741 litres
Volume (Opt. third seat row, Collapsed seat)
1,572 litres

Seats

Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult
Third/Fourth Seat Row
Third Seat Row
Yes
Third/Fourth Seat Row › Third Seat Row
Collapsible
Yes
Number of Seats
2
Type of Seat
Adult
Seat Angle
Front Facing
