2020 Aston Martin DBS Volante

United KingdomGasolineRWDConvertible

Photos

Specifications

Vehicle Details

Year
2020
Make
Aston Martin
Model
DBS
Variant
Volante
Body Style
Convertible
Generation
3rd Generation (AM7)
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 8-speed

Powertrain

Engine Name
5.2 V12 Touchtronic IV
Engine Configuration
V
Power (hp)
725 hp
Power (kW)
533 kW
Torque
900 Nm (664 lb-ft)
Top speed
340 km/h (211 mph)
0–60 mph
3.4 seconds (estimated)
0–100 km/h
3.6 seconds
Displacement
5,204 cc

Dimensions

Length
4,715 mm (185.6 in)
Width
1,970 mm (77.6 in)
Height
1,295 mm (51.0 in)
Wheelbase
2,805 mm (110.4 in)
Curb weight
1,945 kg (4,288 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,500 rpm
Rev. at Max Torque
1,800 - 5,000 rpm
Engine Configuration
Bore
89 mm (3.5 in)
Stroke
69.7 mm (2.7 in)
Compression Ratio
9.3 :1
Engine Configuration
V-Engine
Turbocharger
Twin-turbo
Engine Placement
Front-Mid
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
Automatic, 8-speed
Gear Ratio
Final Drive
2.93 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Carbon Ceramic
Front Brakes
Diameter
410 mm (16.1 in)
Cooling
Ventilated
Rear Brakes
Diameter
360 mm (14.2 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
75 - 80 litres
WLTP Consumption
Low (l/100km) (WLTP)
23.2 litres / 100 km
Medium (l/100km)
13.5 litres / 100 km
High (l/100km)
11.3 litres / 100 km
Extra High (l/100km)
11.7 litres / 100 km
Combined (l/100km)
13.5 litres / 100 km
Emission WLTP
CO₂, Combined
295 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,145 mm (84.4 in)
Track, Front
1,665 mm (65.6 in)
Track, Rear
1,645 mm (64.8 in)
Overhang, Front
915 mm (36.0 in)
Overhang, Rear
995 mm (39.2 in)
Approach Angle
9.5 °
Departure Angle
13 °
Turning Circle
12.4 m
Ground Clearance
90 - 120 mm (3.5 - 4.7 in)

Interior

Head Room, Front
980 mm (38.6 in)
Head Room, Rear
635 mm (25.0 in)
Leg Room, Front
1,145 mm (45.1 in)
Shoulder Room, Front
1,380 mm (54.3 in)
Shoulder Room, Rear
1,235 mm (48.6 in)

Weight

Gross Weight
2,365 kg (5,214 lb)
Cargo Capacity
420 kg (926 lb)
Max Roof Load
0 kg (0 lb)
Weight Distribution, front
51 %
Weight Distribution, rear
49 %

Exterior

Chassis & Body

Chassis
Chassis
Cabriolet Soft-top
Body Material
Aluminium
Doors
Front Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical (Automatic Parking Fold)
User Memory
Yes
Heated
Yes
Automatic Tilt Down
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
128
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
75.1
Central Bore (CB), rear
75.1
Fastening Type
Lug Bolts
Tightening Torque
150 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Connectivity
Radio
  • AM
  • FM
  • DAB
Bluetooth
  • Phone
  • Audio
Displays
Center Display
8"
Displays › Center Display
Type
Colour
Climate Control
Climate Control
Automatic
Air Condition
Yes
Climate Control › Air Condition
Refrigerant
R134A
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Other Equipment
Carpets
Yes

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
User Memory
Sport
Yes
Steering Ratio
13.09 :1
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Mode Selection
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
255 litres

Seats

Colour & Material
Upholstery
  • Alcantara
  • Leather
Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Seat Height
Powered
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
  • Driver
  • Passenger
Front Seats › Power Seat, Driver
User Memory
Yes
Front Seats › Power Seat, Passenger
User Memory
Yes
Second Seat Row
Number of Seats
2
Type of Seat
Adult

Features

Comfort Features

Keyless Entry
Yes
Garage Remote Control
Optional
Cameras
Yes
Cameras
360° Camera
Yes

Other Features

GPS
Navigation

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Dynamic Torque Vectoring (DTV)
Yes
Positive Torque Control (PTC)
Yes
Parking Assist
Yes

Brake Systems

Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Airbag cut-off Switch

Other

Car Classification

American Classification
Convertible
British Classification
Convertible
Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car
