2020 Ford S-Max

United StatesDieselFWDMinivan

Photos

Specifications

Vehicle Details

Year
2020
Make
Ford
Model
S-Max
Body Style
Minivan
Generation
CJ Facelift
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
FWD
Transmission
Automatic, 8-speed

Powertrain

Engine Name
2.0 EcoBlue Bi-Turbo SelectShift
Engine Configuration
Inline
Power (hp)
240 hp
Power (kW)
177 kW
Torque
500 Nm (369 lb-ft)
Top speed
220 km/h (137 mph)
0–60 mph
8.2 seconds (estimated)
0–100 km/h
8.6 seconds
Displacement
1,996 cc

Dimensions

Length
4,796 mm (188.8 in)
Width
1,916 mm (75.4 in)
Height
1,655 mm (65.2 in)
Wheelbase
2,850 mm (112.2 in)
Curb weight
1,951 kg (4,301 lb)

Engine & Performance

Engine

Engine Configuration
Bore
85 mm (3.3 in)
Stroke
88 mm (3.5 in)
Compression Ratio
16 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Belt

Transmission & Drivetrain

Transmission
Automatic, 8-speed

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
70 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 6d -TEMP-EVAP-ISC
Fuel Consumption NEDC
City
7.1 - 7.2 litres / 100 km
Highway
5.2 - 5.3 litres / 100 km
Combined
5.9 - 6 litres / 100 km
Emission NEDC
CO₂, Combined
154 - 156 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,137 mm (84.1 in)
Track, Front
1,606 mm (63.2 in)
Track, Rear
1,606 mm (63.2 in)
Turning Circle
11.6 m
Ground Clearance
140 - 143 mm (5.5 - 5.6 in)

Interior

Head Room, Front
996 - 1,022 mm (39.2 - 40.2 in)
Head Room, Rear
953 - 971 mm (37.5 - 38.2 in)
Leg Room, Front
1,081 mm (42.6 in)
Leg Room, Rear
1,046 mm (41.2 in)
Hip Room, Front
1,431 mm (56.3 in)
Hip Room, Rear
1,470 mm (57.9 in)
Shoulder Room, Front
1,531 mm (60.3 in)
Shoulder Room, Rear
1,535 mm (60.4 in)

Weight

Gross Weight
2,600 kg (5,732 lb)
Max Trailer Load, braked 12%
2,000 kg (4,409 lb)
Max Trailer Load, braked 8%
2,000 kg (4,409 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
649 kg (1,431 lb)
Max Roof Load
75 kg (165 lb)
Max Towbar Download
90 kg (198 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Heated Windows
Front
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Normal Roof
Yes
Antenna
Shark Fin

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Number of Bolts
5 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
63.4
Central Bore (CB), rear
63.4
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
220 Nm
Rim Material
Alloy
Rim Type
Disc Wheel
Tire Pressure Monitoring System (TPMS)
Direct
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Fuel Gauge
Digital
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
4 pcs
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
Media Inputs
USB
Bluetooth
Phone
Displays
Center Display
Yes
Displays › Center Display
Type
Colour
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable
Armrest Hatch
Front
Back Pocket
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Interior Storage › Cup Holders › Rear
Placement
Foldable Table
Lights
Read Light
  • Front
  • Rear
Other Equipment
Make-up Mirror
Driver Side
Clock
Analogue
12V Outlet
Front
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Colour
Black
Multifunction Steering Wheel
Menu Navigation
Yes
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
965 litres
Volume, Back Seat Collapsed
2,020 litres
Volume (third seat row)
285 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Third/Fourth Seat Row
Third Seat Row
Optional

Features

Accessories

Warning Triangle
Yes
First Aid Kit
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional

Brake Systems

Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote

Safety Testing

General
Test Year
2015
Adult Occupant
87 %
Child Occupant
87 %
Vulnerable Road Users
79 %
Safety Assist
71 %
Overall
5/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Minivan
British Classification
Large MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Large MPV

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
H15
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Cornering Light
H1
Positioning-/Parking Lights, Front Side
W2.1×9.5d (W5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Side
W2.1×9.5d (WY5W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Type
Passenger Van (V)
