2020 Hyundai Sonata

South KoreaGasolineFWDSedan

Photos

Specifications

Vehicle DetailsPowertrainDimensionsEngine & PerformanceDimensions & WeightExteriorInteriorFeaturesSafety & SecurityOther

Vehicle Details

Year
2020
Make
Hyundai
Model
Sonata
Body Style
Sedan
Generation
LF Facelift
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic (Dual-clutch), 7-speed

Powertrain

Engine Name
1.6 GDI DCT
Engine Configuration
Inline
Power (hp)
181 hp
Power (kW)
133 kW
Torque
264 Nm (195 lb-ft)
Top speed
210 km/h (130 mph)
0–60 mph
8.9 seconds (estimated)
0–100 km/h
9.3 seconds
Displacement

Dimensions

Length
4,854 mm (191.1 in)
Width
1,864 mm (73.4 in)
Height
1,476 mm (58.1 in)
Wheelbase
2,804 mm (110.4 in)
Curb weight
1,460 kg (3,219 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
1,500 - 4,500 rpm
Engine Configuration
Bore
77 mm (3.0 in)
Stroke
85.4 mm (3.4 in)
Compression Ratio
1,591 cc
10 :1
Engine Configuration
Inline
Turbocharger
Twin-scroll

Transmission & Drivetrain

Transmission
Automatic (Dual-clutch), 7-speed

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes

Fuel

General
Tank Volume
70 litres
General › Fuel Cap Position
Rear
Left
Fuel Consumption NEDC
City
8.4 litres / 100 km
Highway
6.4 litres / 100 km
Combined
7.6 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,613 mm (63.5 in)
Track, Rear
1,621 mm (63.8 in)
Ground Clearance
135 mm (5.3 in)

Interior

Head Room, Front
1,026 mm (40.4 in)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Instrument Cluster › Trip Computer

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Yes
Cameras
Rear
Wireless Phone Charger
Optional
Cruise Control
Adaptive Cruise Control

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Driver
Passenger
Rear
Seat Belt Reminder

Other

Car Classification

American Classification
Mid-Size Car
British Classification
Large Family Car
Australian Classification
Medium Car
European Segment
D-Segment
Car.info Classification
Large Family Car
Hyundai emblem
Head Room, Rear
965 mm (38.0 in)
Leg Room, Front
1,156 mm (45.5 in)
Leg Room, Rear
904 mm (35.6 in)
Hip Room, Front
1,405 mm (55.3 in)
Hip Room, Rear
1,425 mm (56.1 in)
Shoulder Room, Front
1,471 mm (57.9 in)
Shoulder Room, Rear
1,435 mm (56.5 in)

Weight

Gross Weight
1,960 kg (4,321 lb)
Cargo Capacity
500 kg (1,102 lb)
Max Roof Load
75 kg (165 lb)
Hyundai-Kia Platforms
Y Platform (Y7)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
User Memory
Optional
Heated
Optional
Turning Signal
Optional
House Colour
Same as Car
Windows
Window Lifts, Front

Lights

Special Features
Automatic Headlight Activation
Special Features
Main Beam Assist
Optional

Colour

Finish
Solid

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Tightening Torque
107 - 127 Nm
Rim Material
Alloy
Rim Colour
Silver
Rim Type
Disc Wheel
Display
4.2"
Instrument Cluster › Trip Computer › Display
Shape
Square
Climate Control
Number of Climate Zones
2
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
Rotary Dials
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
  • AM
  • FM
Media Format
MP3
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Phone
Connectivity › Radio
XM
Optional
HD Radio
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
7 - 8"
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
  • Front
  • Rear
Other Equipment
Clock
Digital

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel

Trunk

Rear Trunk
Yes
Automatic Open
Optional
Flat Surface
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
518 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Yes
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Optional

Other Features

Start & Stop
Optional
DriverYes
PassengerYes
Rear-
Belt Pretensioner
DriverYes
PassengerYes
Rear-

Assist Systems

Electronic Stability Control (ESC)
Yes
Rear Cross-Traffic Alert (RCTA)
Yes
Lane Assist System
Optional

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Yes
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Central Locking
Yes

Safety Testing

General
Test Year
2015
Overall Score
33.84
Adult Occupant
Frontal Offset
12.84
Side Impact
16
Pole
2
Whiplash Protection (Assessment)
Good
Pedestrian

Airbags

Feature
Driver
Passenger
Rear
Frontal Airbag
DriverYes
PassengerYes
Rear-
Side Chest Airbag
Driver
Sonata
8.9

€67,000

MSRP · EUR

Body
Powered
Window Lifts, Rear
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Antenna
Shark Fin
Menu Navigation
Scrolling Wheel
Cruise Control
Speed Up/Down (Scrolling Wheel)
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Scrolling Wheel
Mute Audio
Yes
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Front Seats
Power Seat, Driver
Optional
Heated Seats
Optional
Armrest
Middle
Ventilated Seats
Optional
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Ventilated Seats
Driver
Optional
Passenger
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Split Fold Ratio
60/40
Protection (Assessment)
Acceptable
Safety Assist
Seat Belt Reminders
3
IIHS
Test Year
2016
Award
Top Safety Pick+
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Yes
PassengerYes
Rear-
Side Head Airbag
DriverYes
PassengerYes
Rear-
Knee Airbag
DriverYes
Passenger-
Rear-
Sedan
Variant
Sonata Sedan Generations12 of 14
Year
Powertrain
1.6 GDI DCT
Horsepower
181 hp
Drivetrain
FWD
Fuel
Gasoline
Transmission
Automatic (Dual-clutch), 7-speed
Superior
Headlight
  • Good
  • Poor
