2020 Kia Stonic

South KoreaGasolineFWDCrossover

Photos

Specifications

Vehicle Details

Year
2020
Make
Kia
Model
Stonic
Body Style
Crossover
Generation
YB
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 6
  • 7-speed

Powertrain

Engine Name
1.0 T-GDI
Engine Configuration
Inline
Power (hp)
120 hp
Power (kW)
88 kW
Torque
172 Nm (127 lb-ft)
Top speed
185 km/h (115 mph)
0–60 mph
9.8 seconds (estimated)
0–100 km/h
10.3 seconds
Displacement
998 cc

Dimensions

Length
4,140 mm (163.0 in)
Width
1,760 mm (69.3 in)
Height
1,520 mm (59.8 in)
Wheelbase
2,580 mm (101.6 in)
Curb weight
1,185 kg (2,612 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
1,500 - 4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
5W-30
Engine Configuration
Bore
71 mm (2.8 in)
Stroke
84 mm (3.3 in)
Compression Ratio
10 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Service Intervals
Air Filter
60,000 km / 4 years
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
210,000 km / 10 years
Interior Filter
30,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6
  • 7-speed

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
45 litres
Emission
Emission Standard
Euro 6d -TEMP
Emission Class
  • B
  • C
WLTP Consumption
Combined (l/100km)
6 – 6.1 litres / 100 km
Fuel Consumption NEDC
City
5.9 – 6 litres / 100 km
Highway
4.5 – 4.9 litres / 100 km
Combined
5 – 5.2 litres / 100 km
Emission WLTP
CO₂, Combined
137 – 138 g/km
Emission NEDC
CO₂, Combined
115 – 120 g/km

Dimensions & Weight

Exterior

Track, Front
1,532 mm (60.3 in)
Track, Rear
1,539 mm (60.6 in)
Overhang, Front
830 mm (32.7 in)
Overhang, Rear
730 mm (28.7 in)
Turning Circle
10.4 m
Ground Clearance
183 mm (7.2 in)

Interior

Head Room, Front
996 mm (39.2 in)
Head Room, Rear
975 mm (38.4 in)
Leg Room, Front
1,070 mm (42.1 in)
Leg Room, Rear
850 mm (33.5 in)
Shoulder Room, Front
1,375 mm (54.1 in)
Shoulder Room, Rear
1,355 mm (53.3 in)

Weight

Gross Weight
1640 – 1670 kg (3,616 – 3,682 lb)
Max Trailer Load, braked 12%
1,110 kg (2,447 lb)
Max Trailer Load, unbraked
450 kg (992 lb)
Cargo Capacity
450 – 455 kg (992 – 1,003 lb)
Max Roof Load
70 kg (154 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon (Crossover)
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Hyundai-Kia Platforms
Small Automobile Platform (GB)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Turning Signal
Optional
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Mud Flaps
Optional
Electric
Optional
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Optional
Special Features
Main Beam Assist
Optional
Headlight Range Adjustment
Manual

Rims & Tires

Tightening Torque
107 - 127 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Number of Climate Zones
1
Air Condition
Yes
Outside Temperature Indicator
Optional
Connectivity
Radio
  • AM
  • FM
Media Format
  • MP3
  • WMA
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
Yes
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Rear-view Mirror
Anti-glare
Automatic
Interior Storage › Storage Compartments
Glove Compartment
Yes
Card Holder
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
Front
Other Equipment
Clock
Digital
12V Outlet
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Electric
Adjustments
Tilt
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
352 litres
Volume, Back Seat Collapsed
1,135 litres

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black
Transmission Knob Material
Plastic

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats
Heated Seats
Optional
Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Optional

Other Features

GPS
Optional
Start & Stop
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Optional
Speed Assist
Optional
Hill Start Assist (HSA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Optional
Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Blind Spot Detection (BLIS)
Optional
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Central Locking
Remote

Safety Testing

General
Test Year
2017
Adult Occupant
85 %
Child Occupant
84 %
Vulnerable Road Users
62 %
Safety Assist
25 %
Overall
3/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
7 years
12V Battery
2 years
Paintwork
150,000 km / 5 years
Rust Damage
150,000 km / 7 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
150,000 km / 7 years

Identification

VIN Location
Passenger Seat
in Front of

Car Classification

American Classification
Subcompact SUV
European Segment
J-Segment
Car.info Classification
Small SUV

Spare Parts BETA

Bulb Types
Low Beam
  • H4
  • HB3
Main Beam
  • H4
  • HB3
Datyime Running Light
BA15s (P21W)
Fog Light, Front
HB4
Fog Light, Rear
BA15s (P21W)
Cornering Light
H7
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Category
Compact (C)
Type
Monoscape (M)

Tests

Autotest
Body/Trunk
3.2
Interior
2.9
Comfort
3.2
Motor/Drivetrain
2.6
Driving Characteristics
2.7
Environment/EcoTest
2.9
Security
2.4
Judgment Technology/Environment
2.8
Judgment Technology/Environment
Satisfactory
Judgment Car Cost
1.5
Judgment Car Cost
Very Good
