2021 Hyundai i10

South KoreaGasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2021
Make
Hyundai
Model
i10
Body Style
Hatchback
Generation
LA
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.0 T-GDI Manual
Engine Configuration
Inline
Power (hp)
100 hp
Power (kW)
74 kW
Torque
172 Nm (127 lb-ft)
Top speed
185 km/h (115 mph)
0–60 mph
10.0 seconds (estimated)
0–100 km/h
10.5 seconds
Displacement
998 cc

Dimensions

Length
3,670 mm (144.5 in)
Width
1,680 mm (66.1 in)
Height
1,480 mm (58.3 in)
Wheelbase
2,425 mm (95.5 in)
Curb weight
1,099 kg (2,423 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,500 rpm
Rev. at Max Torque
1,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-20
Engine Oil, Volume
3.5 litres
Engine Configuration
Bore
71 mm (2.8 in)
Stroke
84 mm (3.3 in)
Compression Ratio
10 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Chain
Service Intervals
Air Filter
30,000 km / 2 years
Spark Plug
75,000 km / 5 years
Brake Fluid
35,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
30,000 km / 2 years
Interior Filter
15,000 km / 1 years

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Rear Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Semi-dependent
Twist-Beam

Fuel

General
Tank Volume
36 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 6d
Emission Class
B
WLTP Consumption
Combined (l/100km)
5.4 litres / 100 km
Fuel Consumption NEDC
City
5.8 litres / 100 km
Highway
4.2 litres / 100 km
Combined
4.8 litres / 100 km
Emission WLTP
CO₂, Combined
123 g/km
Emission NEDC
CO₂, Combined
105 g/km

Dimensions & Weight

Exterior

Track, Front
1,467 mm (57.8 in)
Track, Rear
1,472 - 1,480 mm (58.0 - 58.3 in)
Turning Circle
9.8 m
Ground Clearance
150 mm (5.9 in)

Interior

Head Room, Front
996 mm (39.2 in)
Head Room, Rear
956 mm (37.6 in)
Leg Room, Front
1,070 mm (42.1 in)
Leg Room, Rear
865 mm (34.1 in)
Shoulder Room, Front
1,326 mm (52.2 in)
Shoulder Room, Rear
1,328 mm (52.3 in)

Weight

Gross Weight
1,470 kg (3,241 lb)
Cargo Capacity
350 - 371 kg (772 - 818 lb)
Max Roof Load
60 kg (132 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windscreen Wipers: Connector type, Front
Hook
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Rear Window
Optional
Other Equipment
Normal Roof
Yes
Antenna
Roof-integrated
Mud Flaps
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Rear Lights
Halogen
Special Features
Main Beam Assist
Special Features
Headlight Range Adjustment
Manual

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Indirect
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Central Bore (CB), rear
54.1
Fastening Type
Lug Nuts
Tightening Torque
107 - 127 Nm
Rim Colour
Silver
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Instrument Cluster › Trip Computer
Display
3.5"
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
Rotary Dials
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
Displays
Center Display: Size
8"
Rear-view Mirror
Anti-glare
Manual
Interior Storage › Storage Compartments
Glove Compartment
Yes
Door
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
Yes
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Other Equipment
Clock
Yes
12V Outlet
Front
Carpets
Optional
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster

Steering Wheel

Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Cargo Hooks
Optional
Flat Surface
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
252 litres
Volume, Back Seat Collapsed
1,050 litres

Design

Interior Decor Colour
Black
Colour
Black
Colour
Grey
Optional

Seats

Colour & Material
Upholstery
Textile
Front Seats › Adjustments, Driver
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Headrest, Tilt
Manual
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes
Second Seat Row › Collapsible
Split Fold Ratio
60/40

Features

Comfort Features

Cruise Control
Yes
Speed Limiter
Yes
Cameras
Optional
Wireless Phone Connection with Antenna
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional
Start & Stop
Yes

Accessories

Tool Kit and Jack
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Emergency Stop Signal (ESS)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes
Speed Assist
Dead Reckoning
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes

Sensors

Parking Sensors
Rear
Driver Alertness Warning (DAW)
Yes
Light Sensor
Optional
Rain Sensors
Optional

Other Features

Immobiliser
Yes
Child Safety Locks
Manual
Emergency Call
Yes
Active Headrests
Yes

Safety Testing

General
Test Year
2020
Adult Occupant
69 %
Child Occupant
75 %
Vulnerable Road Users
52 %
Safety Assist
59 %
Overall
3/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
City Car
Australian Classification
Microcar
European Segment
A-Segment
Car.info Classification
Mini Car

Spare Parts BETA

Bulb Types
Low Beam
HB3
Main Beam
HB3
Fog Light, Front
HB4
Fog Light, Rear
BA15s (P21W)
Rear/Brake Light
  • BA15s (P21W)
  • BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)

ACRISS

Type
4-5 Doors (D)
