2022 Ford Ranger Raptor

United StatesGasoline4WDPickup

Photos

Specifications

Vehicle Details

Year
2022
Make
Ford
Model
Ranger
Variant
Raptor
Body Style
Pickup
Generation
RA
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
4WD
Transmission
Automatic, 10-speed

Powertrain

Engine Name
ptor SelectShift
Engine Configuration
V
Power (hp)
292 hp
Power (kW)
215 kW
Torque
491 Nm (362 lb-ft)
Top speed
180 km/h (112 mph)
0–60 mph
7.5 seconds (estimated)
0–100 km/h
7.9 seconds
Displacement
2,953 cc

Dimensions

Length
5,282 mm (208.0 in)
Width
2,026 mm (79.8 in)
Height
1,873 mm (73.7 in)
Wheelbase
3,220 mm (126.8 in)
Curb weight
2,478 kg (5,463 lb)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
0W-30
Engine Oil, Volume
6.6 litres
Engine Configuration
Engine Configuration
V-Engine
Turbocharger
Yes
Synchronization
Timing Chain
Service Intervals
Oil Change & Engine Filter
20,000 km / 2 years
Engine Coolant
10 years
Accessory Belt
240,000 km / 10 years

Transmission & Drivetrain

Transmission
Automatic, 10-speed

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes

Fuel

General
Tank Volume
80 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 6
WLTP Consumption
Combined (l/100km)
13.8 litres / 100 km
Emission WLTP
CO₂, Combined
315 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,202 mm (86.7 in)
Track, Front
1,710 mm (67.3 in)
Track, Rear
1,710 mm (67.3 in)
Overhang, Front
865 mm (34.1 in)
Overhang, Rear
1,225 mm (48.2 in)
Turning Circle
12.9 m
Ground Clearance
271 mm (10.7 in)

Interior

Head Room, Front
1,022 mm (40.2 in)
Head Room, Rear
975 mm (38.4 in)
Leg Room, Front
1,058 mm (41.7 in)
Leg Room, Rear
902 mm (35.5 in)
Hip Room, Front
1,419 mm (55.9 in)
Hip Room, Rear
1,374 mm (54.1 in)
Shoulder Room, Front
1,450 mm (57.1 in)
Shoulder Room, Rear
1,440 mm (56.7 in)

Weight

Gross Weight
3,130 kg (6,900 lb)
Max Trailer Load, braked 12%
2,500 kg (5,512 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
656 kg (1,446 lb)

LCV Specific

Pickup Box Dimensions
Box Length, Floor
1575 mm (62.0 in)
Box Width
1560 mm (61.4 in)

Exterior

Chassis & Body

Chassis
Chassis
Pickup
Pillars
A-C
Chassis Construction
Body-on-Frame
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
Windscreen Wipers
Speed Sensing Intermittent
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
  • Front
  • Rear
Tinted Windows
  • Front
  • Second Row
  • Rear Window
Safety Glass
Yes
Windows › Window Lifts, Features
Pinch Protection
Driver
One-touch up/down
  • Driver
  • Passenger
  • Rear
Windows › Safety Glass
Front
  • Laminated
  • Tempered
Other Equipment
Tow Hitch
Tow Hitch
Tow Hook
  • Front
  • Rear
Antenna
Whip
Mud Flaps
  • Front
  • Rear
Side Steps
Stationary

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
  • Automatic Headlight Activation
  • Main Beam Assist
Fog Lights
Front
LED
Rear
LED
Special Features
Headlight Range Adjustment
Automatic

Colour

Accent
Black
Door Handles
Same as Car

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Number of Bolts
6 pcs
Bolt Distance
139.7
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
93.1
Central Bore (CB), rear
93.1
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Rim Material
Alloy
Number of Spokes
6
Rim Colour
Black
Rim Type
Disc Wheel
Spare Wheel
Full-size (Alloy)
Tire Pressure Monitoring System (TPMS)
Direct
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Digital
Tachometer
Digital
Fuel Gauge
Digital
Coolant Temperature
Digital
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Cockpit
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
  • Buttons
  • Rotary Dials
Climate Control › Air Condition
Refrigerant
HF01234yf
Connectivity
Radio
  • AM
  • FM
  • DAB
Bluetooth
Phone
Connectivity › Media Inputs
AUX
Front
USB
  • USB-A
  • USB-C
Connectivity › Media Inputs › USB
Placement
Front
Number of Ports
3 pcs
Displays
Center Display
12"
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
8 pcs
Tweeters
2 pcs
Speaker Brand
Bang & Olufsen
Rear-view Mirror
Adjustments
Electrical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Lockable (Manual)
Armrest Hatch
Front
Back Pocket
Yes
Sunglass Compartment
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
3
Interior Storage › Cup Holders › Front
Placement
  • Middle Console
  • Left of Steering Wheel
Lights
Read Light
  • Front
  • Rear
Ambient Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
12V Outlet
  • Rear
  • Trunk
Carpets
  • Front
  • Rear
Other Equipment › Carpets
Material
Textile
Colour
Black

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Sport
Yes
Number of Spokes
4
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Menu Navigation
Buttons
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down (Buttons)
  • Resume
Media
Yes
Mode Selection
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Buttons

Trunk

Rear Trunk
Yes
Cargo Hooks
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
Fold Down Sill
Rear Trunk
Depth
1,575 mm (62.0 in)
Width
1,560 mm (61.4 in)
Width, Between Wheel Arches
1,136 mm (44.7 in)
Sill Height
906 mm (35.7 in)

Design

Transmission Knob Material
Leather

Seats

Colour & Material
Upholstery
Leather
Seat Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Powered
Headrest, Height
Powered
Headrest, Tilt
Powered
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Powered
Headrest, Height
Powered
Headrest, Tilt
Powered
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
  • Driver
  • Passenger
Front Seats › Heated Seats
Areas
Cushion
Second Seat Row
Armrest
Yes
Number of Seats
3
Type of Seat
Adult
Headrests, Centre Seat, Foldable: Type
Manual
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes
Second Seat Row › Headrests › Centre Seat
Height Adjustment
Yes

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Cruise Control
Yes
Speed Limiter
Yes
Parking Heater
Optional
Cameras
  • Front
  • Rear
Wireless Phone Charger
Front
Parking Heater
Cabin Heater
Optional
Parking Heater › Cabin Heater
Remote
Optional
Timer
Optional
Cameras
360° Camera
Yes
View Location
Center Display

Other Features

GPS
Navigation
Start & Stop
Yes
Driving Mode Selection
  • Comfort
  • Off-road
  • Rock Crawl/Mountain
  • Snow
Horn
Dual Note

Accessories

Warning Triangle
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Parking Assist
Yes
Sign Assist
Yes
Trailer Assist
Yes
Trailer Stability Assist (TSA)
Yes
Traffic Light Recognition
Yes
Emergency Stop Signal (ESS)
Yes
Electronic Stability Control (ESC)
Roll Stability Control (RSC)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Differential Lock
Electronic

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Yes
Obstacle Detection Sensor
Yes
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Anti-theft Alarm
Yes
Central Locking
Remote
Child Safety Locks
Manual

Safety Testing

General
Test Year
2022
Adult Occupant
84 %
Child Occupant
90 %
Vulnerable Road Users
74 %
Safety Assist
84 %
Overall
5/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Mid-Size Pickup Truck
British Classification
Pick-up
Australian Classification
Ute
European Segment
J-Segment JD-Segment
Car.info Classification
Pickup
