2022 Hyundai Elantra N

South KoreaGasolineFWDSedan

Photos

Specifications

Vehicle Details

Year
2022
Make
Hyundai
Model
Elantra
Variant
N
Body Style
Sedan
Generation
CN7
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic Dual-clutch
  • Manual, 6
  • 8-speed

Powertrain

Engine Name
N
Engine Configuration
Flat
Power (hp)
280 hp
Power (kW)
206 kW
Torque
392 Nm (289 lb-ft)
Displacement
1,998 cc

Dimensions

Length
4,676 mm (184.1 in)
Width
1,826 mm (71.9 in)
Height
1,415 mm (55.7 in)
Wheelbase
2,720 mm (107.1 in)
Curb weight
1,445 kg (3,186 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 - 6,000 rpm
Rev. at Max Torque
2,100 - 4,700 rpm
Engine Configuration
Bore
86 mm (3.4 in)
Stroke
86 mm (3.4 in)
Compression Ratio
9.5 :1
Engine Configuration
Flat
Turbocharger
Yes

Transmission & Drivetrain

Transmission
  • Automatic Dual-clutch
  • Manual, 6
  • 8-speed

Fuel

General
Tank Volume
47 litres
General › Fuel Cap Position
Rear
Left

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Suspension, Front
Independent
Yes

Dimensions & Weight

Exterior

Overhang, Front
894 mm (35.2 in)
Overhang, Rear
1,059 mm (41.7 in)
Turning Circle
10.8 m
Ground Clearance
150 mm (5.9 in)

Interior

Head Room, Front
1,031 mm (40.6 in)
Head Room, Rear
947 mm (37.3 in)
Leg Room, Front
1,074 mm (42.3 in)
Leg Room, Rear
965 mm (38.0 in)
Shoulder Room, Front
1,435 mm (56.5 in)
Shoulder Room, Rear
1,412 mm (55.6 in)

Weight

Gross Weight
1860 – 1895 kg (4,101 – 4,178 lb)
Max Trailer Load, braked 12%
1,100 kg (2,425 lb)
Max Trailer Load, unbraked
610 kg (1,345 lb)
Cargo Capacity
400 – 435 - 415 – 435 kg (915 – 959 lb)
Max Roof Load
75 kg (165 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
House Colour
Same as Car
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Other Equipment
Normal Roof
Yes

Lights

Daytime Running Light
LED
Special Features
  • Automatic Headlight Activation
  • Main Beam Assist

Colour

Finish
Solid

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Central Bore (CB), rear
67.1
Fastening Type
Lug Nuts
Tightening Torque
107 - 127 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
Media Inputs
USB
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
  • Phone
  • Audio
Connectivity › Radio
XM
Optional
Displays
Center Display
8"
Displays › Center Display
Type
Colour
Rear-view Mirror
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Lights
Read Light
Front
Other Equipment
Clock
Digital

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Volume
Yes

Trunk

Rear Trunk
Yes
Automatic Open
Optional
Automatic Close
Optional
Light
Yes
Rear Trunk
Volume
396 litres

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black

Seats

Front Seats › Adjustments, Driver
Backrest Angle
Yes
Front Seats › Adjustments, Passenger
Backrest Angle
Yes
Second Seat Row
Number of Seats
3
Type of Seat
Adult

Features

Comfort Features

Cameras
Rear

Other Features

Driving Mode Selection
  • Normal
  • Sport

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Seat Belt Colour
Black
Feature
Belt Pretensioner
Belt Load Limiter

Assist Systems

Forward Collision Warning (FCW)
Yes
Rear Collision Warning (RCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Yes
Lane Assist System
Yes
Lane Assist System
Lane Keeping Assist (LKA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Autonomous Emergency Brake System (AEB)
Pedestrian
Yes

Sensors

Blind Spot Detection (BLIS)
Yes
Driver Alertness Warning (DAW)
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes
IIHS
Test Year
2021
Award
Top Safety Pick
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Latch Ease of Use
Acceptable

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car
