2022 Toyota 86 GR86

JapanGasolineRWDCoupe

Photos

Specifications

Vehicle Details

Year
2022
Make
Toyota
Model
86
Variant
GR86
Body Style
Coupe
Generation
ZN8
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
GR86 2.4 H4
Engine Configuration
Flat
Power (hp)
235 hp
Power (kW)
173 kW
Torque
249 Nm (184 lb-ft)
Top speed
215 km/h (134 mph)
0–60 mph
6.1 seconds
0–100 km/h
6.2 seconds
Displacement
2,387 cc

Dimensions

Length
4,265 mm (167.9 in)
Width
1,775 mm (69.9 in)
Height
1,310 mm (51.6 in)
Wheelbase
2,575 mm (101.4 in)
Curb weight
1,275 kg (2,811 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
7,000 rpm
Rev. at Max Torque
3,700 rpm
Engine Configuration
Bore
94 mm (3.7 in)
Stroke
86 mm (3.4 in)
Compression Ratio
12.5 :1
Engine Configuration
Flat
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed
Gear Ratio
1st Gear
3.54 – 3.63 :1
2nd Gear
2.06 – 2.19 :1
3rd Gear
1.4 – 1.54 :1
4th Gear
1 – 1.21 :1
5th Gear
0.71 – 1 :1
6th Gear
0.58 – 0.77 :1
Reverse
3.17 – 3.44 :1

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Leather
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
294 mm (11.6 in)
Cooling
Ventilated
Rear Brakes
Diameter
290 mm (11.4 in)
Cooling
Solid

Suspensions

Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link
Anti-roll Bar
  • Front
  • Rear

Fuel

WLTP Consumption
Low (l/100km) (WLTP)
14.9 litres / 100 km
Medium (l/100km)
8.3 litres / 100 km
High (l/100km)
7.5 litres / 100 km
Extra High (l/100km)
8.5 litres / 100 km
Combined (l/100km)
8.8 litres / 100 km
Fuel Consumption EPA
City
20 – 21 MPG
Highway
27 – 31 MPG
Combined
22 – 25 MPG

Performance

Drag Coefficient
0.28

Dimensions & Weight

Exterior

Track, Front
1,520 mm (59.8 in)
Track, Rear
1,550 mm (61.0 in)
Turning Circle
10.8 m
Ground Clearance
130 mm (5.1 in)

Interior

Head Room, Front
940 mm (37.0 in)
Head Room, Rear
851 mm (33.5 in)
Leg Room, Front
1,054 mm (41.5 in)
Leg Room, Rear
760 mm (29.9 in)
Hip Room, Front
1,349 mm (53.1 in)
Hip Room, Rear
1,151 mm (45.3 in)
Shoulder Room, Front
1,361 mm (53.6 in)
Shoulder Room, Rear
1,313 mm (51.7 in)

Weight

Gross Weight
1670 – 1700 kg (3,682 – 3,748 lb)
Cargo Capacity
395 – 407 kg (871 – 897 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-C
Doors
Front Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
House Colour
Black
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Other Equipment
Normal Roof
Yes
Antenna
Shark Fin

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Special Features
Automatic Headlight Activation

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
56.1
Central Bore (CB), rear
56.1
Fastening Type
Lug Nuts
Tightening Torque
120 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Digital
Tachometer
Digital
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
7"
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
  • XM
App-Connect
Apple CarPlay
WiFi
Yes
Connectivity › Media Inputs
AUX
Front
USB
Yes
Connectivity › Media Inputs › USB
Placement
Front
Number of Ports
2 pcs
Displays
Center Display
8"
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
6 - 8 pcs
Rear-view Mirror
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Material
Leather
Colour
Black
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Volume
Buttons

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
177 litres
Depth
700 mm (27.6 in)
Width
1,370 mm (53.9 in)
Width, Between Wheel Arches
1,080 mm (42.5 in)

Design

Interior Decor Material
Plastic
Transmission Knob Material
Leather

Seats

Front Seats
Type of Seat
Sport Seats

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Cameras
Rear

Other Features

Driving Mode Selection
  • Normal
  • Sport
  • Track

Accessories

Tire Repair Kit
Yes

Safety & Security

Seat Belt

Emergency Locking Retractor
Yes
Automatic Locking Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Lane Assist System
Lane Keeping Assist (LKA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Light Sensor
Optional
Rain Sensors
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote (Panic Button)
Immobiliser
Electronic
Yes
Anti-theft Alarm
Back-up Horn
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

ACRISS

Category
Standard (S)
Type
Coupe (E)
