2022 Volvo S90

SwedenPlug In Hybrid GasolineAWDSedan

Photos

Specifications

Vehicle Details

Year
2022
Make
Volvo
Model
S90
Body Style
Sedan
Generation
2nd Generation Facelift (PS)
Seats
5
Doors
4
Fuel
Plug In Hybrid Gasoline
Drivetrain
AWD
Transmission
Automatic (Manumatic), 8-speed

Powertrain

Engine Name
Recharge T8 AWD Geartronic
Engine Configuration
Inline
Power (hp)
392 hp
Power (kW)
288 kW
Torque
400 Nm (295 lb-ft)
Top speed
180 km/h (112 mph)
0–60 mph
4.9 seconds (estimated)
0–100 km/h
5.1 seconds
Electric range
47 km (29 mi)
Battery
11.6 kWh
Displacement
1,969 cc

Dimensions

Length
4,969 mm (195.6 in)
Width
1,879 mm (74.0 in)
Height
1,440 mm (56.7 in)
Wheelbase
2,941 mm (115.8 in)
Curb weight
2,094 kg (4,616 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
2,220 - 4,800 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-20
Engine Oil, Volume
6.1 litres
Configuration Combustion
Bore
82 mm (3.2 in)
Stroke
93.2 mm (3.7 in)
Compression Ratio
10.3 :1
Engine Configuration
Inline
Supercharger
Yes
Turbocharger
Yes
Configuration Electric
Type of Electric Car
Plug-in Hybrid
Electric Engine Power
65 kW
Electric Engine Horsepower (Metric)
88 hp
Torque
400 Nm (295 lb-ft)
Rear Engines
Yes
Battery Capacity, Gross
11.6 kWh
Type of Battery
Li-ion
AC Charge Type
Single-phase
Charging Plugs
Type 2
Configuration Electric › Rear Engines
Electric Power (kW)
65 kW
RPM at Max Power
7,000 rpm
Number of Engines
1
Service Intervals
Oil Change & Engine Filter
30,000 km / 1 years
Interior Filter
30,000 km / 1 years

Transmission & Drivetrain

Transmission
Automatic (Manumatic), 8-speed

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
  • Front
  • Rear
Front Brakes
Diameter
296 - 345 mm (11.7 - 13.6 in)
Cooling
Ventilated
Rear Brakes
Diameter
302 - 320 mm (11.9 - 12.6 in)
Cooling
Ventilated

Fuel

General
Tank Volume
60 litres
Lockable Fuel Cap
Yes
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 6d
Emission Class
A+
WLTP Consumption
Weighted, Combined
1.9 - 2.7 litres / 100 km
Electric Range
47 - 57 km (29 - 35 mi)
Fuel Consumption NEDC
Combined
1.7 litres / 100 km
Combined
15.4 kWh/100km
Electric Range
51 km (32 mi)
Emission WLTP
CO₂, Weighted, Combined
42 - 61 g/km
Emission NEDC
CO₂, Combined
38 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,019 mm (79.5 in)
Track, Front
1,617 - 1,628 mm (63.7 - 64.1 in)
Track, Rear
1,618 - 1,629 mm (63.7 - 64.1 in)
Overhang, Front
879 mm (34.6 in)
Overhang, Rear
1,149 mm (45.2 in)
Turning Circle
11.8 m
Ground Clearance
148 - 150 mm (5.8 - 5.9 in)

Interior

Head Room, Front
1,027 mm (40.4 in)
Head Room, Rear
961 mm (37.8 in)
Leg Room, Front
1,071 mm (42.2 in)
Leg Room, Rear
911 mm (35.9 in)
Hip Room, Front
1,432 mm (56.4 in)
Hip Room, Rear
1,416 mm (55.7 in)
Shoulder Room, Front
1,460 mm (57.5 in)
Shoulder Room, Rear
1,420 mm (55.9 in)

Weight

Gross Weight
2,590 kg (5,710 lb)
Max Trailer Load, braked 12%
2,100 kg (4,630 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
496 kg (1,093 lb)
Max Roof Load
100 kg (220 lb)
Max Towbar Download
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan

Equipment

Windscreen Wipers
Speed Sensing Intermittent
Yes
Intermittent Control
Yes
Windscreen Wipers: Connector type, Front
Push Button
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered (Safety Lock)
Heated Windows
  • Front
  • Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Noise Reducing Windows
Optional
Tinted Windows
Optional
Safety Glass
Yes
Windows › Window Lifts, Features
Pinch Protection
Yes
Windows › Noise Reducing Windows
Front
Optional
First Row
Optional
Second Row
Optional
Windows › Tinted Windows
Windscreen, upper part
Optional
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Normal Roof
Yes
Other Equipment › Sunroof
Sun Blind
Optional
Other Equipment › Sunroof › Sun Blind
Tinted Glass
Optional

Lights

Special Features
Headlight Washers

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
63.4
Central Bore (CB), rear
63.4
Fastening Type
Lug Bolts
Tightening Torque
140 Nm
Rim Material
Alloy

Interior

Equipment

Climate Control
Climate Control
Automatic
Air Condition
Yes
Micro Filter
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
4 pcs
Controls
Touchscreen
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Interior Storage › Storage Compartments
Glove Compartment
  • Cooled
  • Light
  • Lockable (Manual)
Armrest Hatch
Front
Back Pocket
Yes
Sunglass Compartment
Yes
Coin Holder
Yes
Card Holder
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Phone/Tablet Holder
Optional
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
  • Front
  • Rear
Guide Light
Entry Guard
Ambient Light
Optional
Selectable Light Colour
Optional
Lights › Guide Light
Footwell
Optional
Side Mirrors
Optional
Door Handles
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
  • Front
  • Trunk
230V Outlet
Optional
Carpets
Optional
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster
Other Equipment › 230V Outlet
Rear
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Electric
Number of Spokes
3
Material
Leather
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Menu Navigation
Buttons
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down (Buttons)
  • Resume
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Buttons
Mute Audio
Yes
Adjustments
Tilt
Yes
Telescope
Yes

Trunk

Rear Trunk
Yes
Automatic Open
  • From Inside Car
  • Key Button
Rear Trunk
Volume
431 litres
Depth
1,149 mm (45.2 in)
Width
1,620 mm (63.8 in)
Opening Width
1,014 mm (39.9 in)
Sill Height
672 mm (26.5 in)

Features

Other Features

Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Yes
First Aid Kit
Yes
Trunk Modules
Optional
Bicycle Holder
Optional
Coat Hanger
Optional
Ski/Snowboard-bag
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Parking Assist
Yes
Lane Assist System
Lane Keeping Assist (LKA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Yes
Light Sensor
Yes
Rain Sensors
Yes

Safety Testing

General
Test Year
2017
Adult Occupant
95 %
Child Occupant
80 %
Vulnerable Road Users
76 %
Safety Assist
93 %
Overall
5/5 stars
Adult Occupant
Total Points
36.2 /38
Frontal Impact
15.1 /16
Lateral Impact
15.4 /16
Rear Impact
2.8 /4
Child Occupant
Total Points
39.3 /49
Crash Test Performance
  • 14.3
  • 8 /16
Safety Features
5 /13
CRS Installation Check
12 /12
Vulnerable Road Users
Total Points
32.3 /49
Pedestrian
  • 19.8
  • 0.5
  • 6
AEB Pedestrian
6 /9
Safety Assist
Speed Assistance (points)
2.5 /3
Lane Support (points)
2.7 /4
IIHS
Test Year
2020
Small Overlap Front: Driver Side
Good
Small Overlap Front: Passenger Side
Good
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Front Crash Prevention: Vehicle-to-vehicle
Superior
Front Crash Prevention: Vehicle-to-pedestrian
Advanced
Headlight
Marginal
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Feature
Isofix
Integrated Child Seat

Other

Warranty

Manufacturer
100,000 km / 2 years
Paintwork
3 years
Rust Damage
12 years
EV Battery
160,000 km / 8 years

Car Classification

American Classification
Mid-Size Luxury Car
British Classification
Executive Car
Australian Classification
Large Car
European Segment
E-Segment
Car.info Classification
Executive Car

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
H9
Datyime Running Light
W3×16q (W21/5W)
Fog Light, Rear
BAY9s (H21W)
Positioning-/Parking Lights, Front
W3×16q (W21/5W)

Production

Statistics › Production Number (Year)
2016
7,383
2017
46,602
2018
57,142
