2023 Alpina 5 Series B5 GT

GermanyGasolineAWDWagon

Photos

Specifications

Vehicle Details

Year
2023
Make
Alpina
Model
5 Series
Variant
B5 GT
Body Style
Wagon
Generation
G30 LCI
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic (Manumatic), 8-speed

Powertrain

Engine Name
B5 GT Touring Switch-Tronic
Engine Configuration
V
Power (hp)
634 hp
Power (kW)
466 kW
Torque
850 Nm (627 lb-ft)
Top speed
328 km/h (204 mph)
0–60 mph
3.2 seconds (estimated)
0–100 km/h
3.4 seconds
Displacement
4,395 cc

Dimensions

Length
4,978 mm (196.0 in)
Width
1,868 mm (73.5 in)
Height
1,466 mm (57.7 in)
Wheelbase
2,975 mm (117.1 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 - 6,500 rpm
Rev. at Max Torque
3,500 - 5,000 rpm
Engine Configuration
Bore
89 mm (3.5 in)
Stroke
88.3 mm (3.5 in)
Engine Configuration
V-Engine

Transmission & Drivetrain

Transmission
Automatic (Manumatic), 8-speed

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
395 mm (15.6 in)
Width
36 mm (1.4 in)
Cooling
Ventilated
Rear Brakes
Diameter
398 mm (15.7 in)
Width
28 mm (1.1 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
Yes
Active/Adaptive Suspension
Yes

Fuel

Emission
Emission Standard
Euro 6d -ISC-FCM
Emission Class
F
WLTP Consumption
Combined (l/100km)
12 litres / 100 km
Fuel Consumption NEDC
City
15.9 litres / 100 km
Highway
8.5 litres / 100 km
Combined
11.2 litres / 100 km
Emission WLTP
CO₂, Combined
272 g/km
Emission NEDC
CO₂, Combined
256 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,126 mm (83.7 in)
Track, Front
1,611 mm (63.4 in)
Track, Rear
1,596 mm (62.8 in)
Ground Clearance
119 mm (4.7 in)

Weight

Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Soft Close
Yes
Door Handles
Pull-out

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
Automatic Anti-glare
Driver side
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Other Equipment
Sunroof
Inbuilt
Roof Railing
Yes
Spoiler
Front
Number of Exhaust Pipes
2
Other Equipment › Sunroof
Material
Glass
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)
Colour
Black

Lights

Main Beam
  • LED
  • Laser
Low Beam
  • LED
  • Laser
Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
Headlight Wipers
Fog Lights
Front
LED
Special Features
Automatic Headlight Activation
Optional
Main Beam Assist
Optional
Adaptive Headlights
Optional
Headlight Range Adjustment
Automatic (Dynamic)

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
112
Nut/Bolt Dimensions
M14x1.25
Central Bore (CB), front
66.6
Central Bore (CB), rear
66.6
Fastening Type
Lug Bolts
Tightening Torque
140 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Speedometer
Digital
Tachometer
Digital
Fuel Gauge
Digital
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
12.3"
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Cockpit
Climate Control
Climate Control
Automatic
Number of Climate Zones
4
Air Condition
Yes
Micro Filter
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
Touchscreen
Back Seat Controls
Rotary Dials
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
  • DAB+
TV Receiver
Yes
App-Connect
Optional
Bluetooth
Yes
Cellular Network
Yes
Connectivity › TV Receiver
Supported Formats
Digital
Connectivity › Media Inputs
USB
  • USB-A
  • USB-C
Connectivity › App-Connect
Apple CarPlay
Optional
Displays
Center Display
10.25"
Center Display Controls
  • Touchscreen
  • Touchpad
Entertainment Screens
Yes
Displays › Center Display
Type
Colour
Displays › Entertainment Screens
Back of Headrest
14"
Speakers
Total Number of Speakers
12 pcs
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable
Armrest Hatch
Front
Lights
Read Light
  • Front
  • Rear
Guide Light
  • Entry Guard
  • Door Handles (Exterior)
Ambient Light
Yes
Selectable Light Colour
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
12V Outlet
  • Front
  • Rear
  • Trunk
Carpets
  • Front
  • Rear
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Carpets
Material
Textile

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Electric
Adjustments
Tilt
Sport
Yes
Number of Spokes
3
Material
Leather
Colour
Black
Multifunction Steering Wheel
Media
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
560 litres

Design

Interior Decor Material
Wood
Accent
Wood
Colour
Silver

Seats

Colour & Material
Upholstery
Leather
Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Yes
Headrest, Height
Powered
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Yes
Headrest, Height
Powered
Headrest, Tilt
Manual
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
  • Driver
  • Passenger
Ventilated Seats
  • Driver
  • Passenger
Front Seats › Power Seat, Driver
User Memory
Yes
Front Seats › Power Seat, Passenger
User Memory
Yes
Front Seats › Heated Seats
Areas
  • Cushion
  • Backrest
Second Seat Row
Collapsible
Manual
Adjustments
  • Seat Depth
  • Cushion Tilt
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
40/20/40
Second Seat Row › Headrests
Outer Seats
Yes

Features

Comfort Features

Cruise Control
Yes
Speed Limiter
Optional
Parking Heater
Optional
Wireless Phone Charger
Yes
Parking Heater
Engine Heater
Optional

Accessories

Warning Triangle
Yes
First Aid Kit
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Speed Assist
Optional
Parking Assist
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Cornering Brake Control (CBC)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Differential Lock
Electronic
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Driver Alertness Warning (DAW)
Yes
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Emergency Call
Yes
Anti-theft Alarm
Interior Monitoring
Yes
Back-up Horn
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Other

Car Classification

British Classification
Executive Car
Australian Classification
Large Car
European Segment
E-Segment
Car.info Classification
Executive Car
