TransmissionAutomatic (Manumatic), 8-speed Displacement1,995 ccEngine Oil, Volume5.5 litresCar Battery
- Voltage
- 12 V
- Battery Capacity
- 70 Ah
Engine Configuration
- Bore
- 84 mm (3.3 in)
- Stroke
- 90 mm (3.5 in)
- Compression Ratio
- 16.5 :1
- Engine Configuration
- Inline
- Turbocharger
- Twin-scroll
- Synchronization
- Timing Chain
- Engine Placement
- Front
- Engine Mount
- Transversally
- Type of Combustion Engine
Service Intervals
- Air Filter
- 60,000 km / 4 years
- Fuel Filter
- 60,000 km / 4 years
- Brake Fluid
- 30,000 km / 2 years
- Oil Change & Engine Filter
- 30,000 km / 2 years
Fuel SystemElectronic Fuel Injection Engine CoolingLiquid Cooling 5th Gear1.24 :124 mm (0.9 in)Rear Brakes
- Diameter
- 280 mm (11.0 in)
- Width
- 10 mm (0.4 in)
- Cooling
- Ventilated
Emission › Emission Control › Selective Catalyst Reduction (SCR)
- Tank Volume (DEF)
- 20.5 litres
WLTP Consumption
- Low (l/100km) (WLTP)
- 6.5 - 7.1 litres / 100 km
- Medium (l/100km)
- 5 - 5.8 litres / 100 km
- High (l/100km)
- 4.4 - 5.6 litres / 100 km
- Extra High (l/100km)
- 4.7 - 5.5 litres / 100 km
- Combined (l/100km)
- 4.9 - 5.6 litres / 100 km
Fuel Consumption NEDC
- City
- 4.8 - 5 litres / 100 km
- Highway
- 3.8 - 4.5 litres / 100 km
- Combined
- 4.2 - 4.6 litres / 100 km
Emission WLTP
- CO₂, Combined
- 129 - 146 g/km
Emission NEDC
- CO₂, Combined
- 110 - 123 g/km
Ground Clearance152 mm (6.0 in) Side Mirrors
- Mirror Type
- Conventional
- Adjustments
- Electrical
- User Memory
- Optional
- Heated
- Yes
- Ground Light
- Optional
- Turning Signal
- Yes
- Mirror Shape, Driver side
- Aspheric
- Mirror Shape, Passenger side
- Aspheric
Side Mirrors › Adjustments
- Driver side
- Optional
- Passenger side
- Optional
Windscreen Wipers
- Speed Sensing Intermittent
- Yes
- Intermittent Control
- Yes
- Heated Water Tank
- Optional
- Windscreen Wipers: Connector type, Front
- Pinch Tab
- Number of Windscreen Wipers, Front
- 2
Windscreen Wipers › Heated Water Tank
Windows
- Window Lifts, Front
- Powered
- Window Lifts, Rear
- Powered (Safety Lock)
- Heated Windows
- Rear
- Heat-Insulating Windows
- Front
- First Row
- Second Row
- Rear
- Tinted Windows
- Optional
- Safety Glass
- Yes
Windows › Window Lifts, Features
Windows › Tinted Windows
- Windscreen, upper part
- Optional
- Second Row
- Optional
- Rear Window
- Optional
Windows › Safety Glass
- Front
- Laminated
- Side
- Tempered
- Rear
- Tempered
Other Equipment
- Sunroof
- Optional
- Normal Roof
- Yes
- Spoiler
- Fixed
- Antenna
- Shark Fin
Other Equipment › Sunroof
Other Equipment › Sunroof › Sun Blind
Instrument Cluster › Trip Computer
Instrument Cluster › Trip Computer › Display
Climate Control
- Climate Control
- Automatic
- Number of Climate Zones
- 2
- Air Condition
- Yes
- Micro Filter
- Yes
- Pollen Filter
- Yes
- Outside Temperature Indicator
- Yes
- Controls
- Buttons
Climate Control › Air Condition
Connectivity
- Media Inputs
- USB
- App-Connect
- Android Auto
- Apple CarPlay (Wireless)
- WiFi
- Optional
Displays
- Center Display
- Yes
- Center Display Controls
- Touchscreen
- Gesture Control
Displays › Center Display
Interior Storage › Storage Compartments
- Glove Compartment
- Cooled
- Light
- Lockable (Manual)
- Armrest Hatch
- Front
- Back Pocket
- Yes
- Sunglass Compartment
- Yes
- Coin Holder
- Yes
- Card Holder
- Yes
- Door
- Driver Side
- Passenger Side
- Rear
Interior Storage
- Cup Holders
- Yes
- Phone/Tablet Holder
- Optional
Interior Storage › Cup Holders
Interior Storage › Cup Holders › Front
Interior Storage › Cup Holders › Rear
Lights
- Guide Light
- Entry Guard
- Ambient Light
- Optional
- Selectable Light Colour
- Optional
Lights › Guide Light
- Footwell
- Optional
- Side Mirrors
- Optional
Other Equipment
- Make-up Mirror
- Driver Side
- Passenger Side
- Clock
- Yes
- 230V Outlet
- Optional
- Carpets
- Optional
- Ashtray
- Optional
- Cigarette Lighter
- Optional
Other Equipment › Make-up Mirror
Other Equipment › Clock
- Digital
- Center Display
- Instrument Cluster
Other Equipment › 230V Outlet
Other Equipment › Ashtray
Optional
Automatic Access HeightOptional Cruise Control
- Adaptive Cruise Control
- Optional
- Active Cruise Control
- Optional
Cameras › Front
- Sides
- Optional
- Rear
- Optional
Passenger
Height Adjustable Retractor
Type of Belt
- Three-Point-Belt
- Front Seats
- Outer Rear Seats
- Centre Rear Seat
Shoulder Room, Rear1,430 mm (56.3 in) 75 kg (165 lb)
Max Towbar Download75 kg (165 lb) Permitted Axle Load, front1,100 kg (2,425 lb) Permitted Axle Load, rear1,020 kg (2,249 lb) LED
Special Features
- Main Beam Assist
- Optional
- Adaptive Headlights
- Optional
- Dynamic Turn Signal
- Optional
- Dynamic Cornering Lights
- Optional
- Headlight Washers
- Optional
- Headlight Range Adjustment
- Automatic (Dynamic)
Steering MechanismRack and Pinion Multifunction Steering Wheel
- Menu Navigation
- Scrolling Wheel
- Cruise Control
- Activate/Deactivate
- Speed Up/Down (Scrolling Wheel)
- Resume
- Media
- Yes
Multifunction Steering Wheel › Media
- Voice Command
- Yes
- Answer Phone
- Yes
- Channels
- Yes
- Volume
- Buttons
- Mute Audio
- Yes
Manual
Front Seats › Adjustments, Passenger
- Seat Depth
- Yes
- Seat Height
- Yes
- Cushion Edge
- Optional
- Cushion Tilt
- Optional
- Backrest Angle
- Yes
- Lumbar Support
- Optional
- Headrest, Height
- Manual
- Headrest, Tilt
- Manual
Front Seats
- Power Seat, Driver
- Optional
- Power Seat, Passenger
- Optional
- Heated Seats
- Optional
- Armrest
- Middle
- Ventilated Seats
- Optional
- Type of Seat
- Sport Seats
- Comfort Seat (Driver | Passenger)
- Easy Entry
- Optional
Front Seats › Heated Seats
Front Seats › Heated Seats › Cushion
Front Seats › Ventilated Seats
- Driver
- Optional
- Passenger
- Optional
Second Seat Row
- Armrest
- Yes
- Collapsible
- Manual
- Number of Seats
- 3
- Type of Seat
- Adult
Second Seat Row › Collapsible
- Backrest Release
- From Trunk
- Split Fold Ratio
- 40/20/40
- Heated Seats
- Optional
Second Seat Row › Headrests
- Outer Seats
- Height Adjustment
- Centre Seat
- Yes
Trailer Stability Assist (TSA)Yes Emergency Stop Signal (ESS)Yes Brake Pad Wear IndicatorYes Differential LockElectronic Autonomous Emergency Brake System (AEB)
- Car-to-car
- Yes
- Pedestrian
- Yes
- Cyclist
- Yes
35.9 /38
Child Occupant
- Total Points
- 43 /49
- Safety Features
- 8 /13
- CRS Installation Check
- 11 /12
Vulnerable Road Users
- Total Points
- 36.5 /49
- AEB Vulnerable Road Users
- 10.7 /18
- AEB Pedestrian
- 5.5 /9
- AEB Pedestrian (assesment)
- Good
- AEB Cyclist
- 5.2 /9
- AEB Cyclist (assesment)
- Good
Safety Assist
- Speed Assistance (points)
- 2.5 /3
- Speed Assistance (assesment)
- Good
- Seat Belt Reminder (assesment)
- Good
- Lane Support (points)
- 1.8 /4
- Lane Support (assesment)
- Marginal
SedanPowertrain220d Gran Coupé Steptronic Drivetrain
FWD Transmission
Automatic (Manumatic), 8-speed 2023–2024
