2023 Ford Ranger

United StatesDiesel4WDPickup

Photos

Specifications

Vehicle Details

Year
2023
Make
Ford
Model
Ranger
Body Style
Pickup
Generation
PX 2nd Facelift
Seats
5
Doors
4
Fuel
Diesel
Drivetrain
4WD
Transmission
  • Automatic
  • Manual, 10
  • 6-speed

Powertrain

Engine Name
2.0 EcoBlue Bi-Turbo 4x4
Engine Configuration
Inline
Power (hp)
213 hp
Power (kW)
157 kW
Torque
500 Nm (369 lb-ft)
Top speed
180 km/h (112 mph)
0–60 mph
8.6 seconds (estimated)
0–100 km/h
9 seconds
Displacement
1,997 cc

Dimensions

Length
5,282 mm (208.0 in)
Width
1,977 mm (77.8 in)
Height
1,815 mm (71.5 in)
Wheelbase
3,220 mm (126.8 in)
Curb weight
2,214 kg (4,881 lb)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
0W-30
Engine Oil, Volume
7.1 litres
Engine Configuration
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Belt
Service Intervals
Timing Interval
160,000 km / 6 years
Oil Change & Engine Filter
20,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 10
  • 6-speed

Brakes

Front Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
80 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 6c
Fuel Consumption NEDC
Combined
7.6 – 7.8 - 7.9 litres / 100 km
Emission NEDC
CO₂, Combined
199 - 207 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,163 mm (85.2 in)
Track, Front
1,560 mm (61.4 in)
Track, Rear
1,560 mm (61.4 in)
Overhang, Front
909 mm (35.8 in)
Overhang, Rear
1,224 mm (48.2 in)
Turning Circle
12.8 m
Ground Clearance
201 - 256 mm (7.9 - 10.1 in)

Interior

Head Room, Front
1,022 mm (40.2 in)
Head Room, Rear
975 mm (38.4 in)
Leg Room, Front
1,058 mm (41.7 in)
Leg Room, Rear
902 mm (35.5 in)
Hip Room, Front
1,417 mm (55.8 in)
Hip Room, Rear
1,417 mm (55.8 in)
Shoulder Room, Front
1,440 mm (56.7 in)
Shoulder Room, Rear
1,437 mm (56.6 in)

Weight

Gross Weight
3,270 kg (7,209 lb)
Max Trailer Load, braked 12%
3,500 kg (7,716 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
1024 – 1044 - 1036 – 1056 kg (2,284 – 2,328 lb)

Exterior

Chassis & Body

Chassis
Chassis
Pickup
Pillars
A-C
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
6 pcs
Bolt Distance
139.7
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
93.1
Central Bore (CB), rear
93.1
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
135 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Connectivity
Radio
  • AM
  • FM
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Lights
Read Light
Front
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
4
Colour
Black
Multifunction Steering Wheel
Menu Navigation
Yes
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Second Seat Row
Number of Seats
3
Type of Seat
Adult

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Brake Systems

Anti-lock Braking System (ABS)
Four-channel

Safety Testing

General
Test Year
2012
Adult Occupant
96 %
Child Occupant
86 %
Vulnerable Road Users
81 %
Safety Assist
71 %
Overall
5/5 stars

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Mid-Size Pickup Truck
British Classification
Pick-up
Australian Classification
Ute
European Segment
J-Segment JD-Segment
Car.info Classification
Pickup
