2023 Hyundai Ioniq

South KoreaElectricAWDSedan

Photos

Specifications

Vehicle Details

Year
2023
Make
Hyundai
Model
Ioniq
Body Style
Sedan
Generation
1st Generation
Seats
5
Doors
4
Fuel
Electric
Drivetrain
AWD
Transmission
Automatic (Fixed)

Powertrain

Engine Name
77.4 kWh AWD Single Speed
Engine Configuration
Electric
Power (hp)
325 hp
Power (kW)
239 kW
Torque
605 Nm (446 lb-ft)
Top speed
185 km/h (115 mph)
0–60 mph
4.9 seconds (estimated)
0–100 km/h
5.1 seconds
Electric range
519 km (322 mi)
Battery
77.4 kWh

Dimensions

Length
4,855 mm (191.1 in)
Width
1,880 mm (74.0 in)
Height
1,495 mm (58.9 in)
Wheelbase
2,950 mm (116.1 in)
Curb weight
2,095 kg (4,619 lb)

Engine & Performance

Engine

Engine Configuration
Type of Electric Car
Electric
Electric Engine Power
239 kW
Electric Engine Horsepower (Metric)
325 hp
Torque
605 Nm (446 lb-ft)
Front Engines
Yes
Rear Engines
Yes
Battery Capacity, Gross
77.4 kWh
Battery Capacity, Net
74 kWh
Number of Batterycells
384
Type of Battery
Li-ion
AC Charge Type
  • Single-phase
  • Three-phase
Charging Plugs
Type 2 (CCS)
Vehicle to Load (V2L)
Yes
Engine Configuration › Front Engines
Power (kW)
71 kW
Horsepower
97 hp
Number of Engines
1
Engine Configuration › Rear Engines
Electric Power (kW)
168 kW
Horsepower
228 hp
Number of Engines
1
Engine Configuration › Charge AC
Charge Time
7.1 h / 425 min
Charge Power
11 kW
Charge Ampere
16 A
Engine Configuration › Charge DC
Charge Time, to 80%
16 min
Charge Power
233 kW
Engine Configuration › Vehicle to Load (V2L)
Vehicle to Home (V2H)
Yes
Max Discharge Power
3.6 kW
Service Intervals
Brake Fluid
30,000 km / 2 years
Interior Filter
30,000 km / 2 years

Energy & Range

Emission
Emission Class
A (+++)
WLTP Consumption
Energy consumption
15.1 - 16.9 kWh/100km
Electric Range
519 - 583 km (322 - 362 mi)
Electric Range, City
658 - 745 km (409 - 463 mi)
Fuel Consumption NEDC
Combined
0 litres / 100 km
Emission WLTP
CO₂, Combined
0 g/km
Emission NEDC
CO₂, Combined
0 g/km

Dimensions & Weight

Exterior

Track, Front
1,635 mm (64.4 in)
Track, Rear
1,644 mm (64.7 in)
Overhang, Front
850 mm (33.5 in)
Overhang, Rear
1,055 mm (41.5 in)
Turning Circle
11.8 m
Ground Clearance
141 mm (5.6 in)

Interior

Head Room, Front
983 mm (38.7 in)
Head Room, Rear
1,020 mm (40.2 in)
Leg Room, Front
1,074 mm (42.3 in)
Leg Room, Rear
995 mm (39.2 in)
Shoulder Room, Front
1,473 mm (58.0 in)
Shoulder Room, Rear
1,455 mm (57.3 in)

Weight

Gross Weight
2,520 kg (5,556 lb)
Max Trailer Load, braked 12%
1,500 kg (3,307 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
407 - 425 kg (897 - 937 lb)
Max Roof Load
80 kg (176 lb)
Max Towbar Download
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan

Equipment

Other Equipment
Normal Roof
Yes

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Central Bore (CB), rear
67.1
Fastening Type
Lug Nuts
Tightening Torque
107 - 127 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Digital
Tachometer
Digital
Fuel Gauge
Digital
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R1234yf
Connectivity
Radio
  • AM
  • FM
Displays
Center Display
Yes
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes

Trunk

Total Trunk Volume
446 litres
Rear Trunk
Yes
Front Trunk
Yes
Rear Trunk
Volume
401 litres
Front Trunk
Volume
45 litres

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Dynamic Steering Response (DSR)
Yes
Dynamic Torque Vectoring (DTV)
Yes
Forward Collision Warning (FCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Yes
Safe Exit Warning (SEW)
Yes
Lane Assist System
Yes
Speed Assist
Yes
Hill Start Assist (HSA)
Yes
Parking Assist
Yes
Sign Assist
Optional
Emergency Stop Signal (ESS)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes
Emergency Lane Keeping (ELK)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Cornering Brake Control (CBC)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes
Cyclist
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Optional
Door Open Warning
Yes
Driver Alertness Warning (DAW)
Yes
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Child Safety Locks
Electrical
Speed Sensitive
Yes
Immobiliser
Electronic
Yes
Anti-theft Alarm
Interior Monitoring
Yes

Safety Testing

General
Test Year
2022
Adult Occupant
97 %
Child Occupant
87 %
Vulnerable Road Users
66 %
Safety Assist
90 %
Overall
5/5 stars
Adult Occupant
Total Points
37 /38
Frontal Impact
15.5 /16
Lateral Impact
15.9 /16
Rear Impact
3.5 /4
Rescue and Extrication
2 /2
Child Occupant
Total Points
43 /49
Crash Test Performance
  • 16
  • 8 /16
Safety Features
7 /13
CRS Installation Check
12 /12
Vulnerable Road Users
Total Points
36 /49
Pedestrian
  • 10
  • 5
  • 5.7
AEB Vulnerable Road Users
15.3 /18
AEB Pedestrian
7 /9
AEB Pedestrian (assesment)
Good
AEB Cyclist
8.3 /9
AEB Cyclist (assesment)
Good
Safety Assist
Speed Assistance (points)
2.8 /3
Speed Assistance (assesment)
Good
Occupant Status Monitoring (points)
2.7 /3
Occupant Status Monitoring (assesment)
Good
Seat Belt Reminder (points)
1.7 /2
Seat Belt Reminder (assesment)
Adequate
Driver Monitoring (points)
1
Driver Monitoring (assesment)
Good
Lane Support (points)
3.5 /4
Lane Support (assesment)
Good
Emergency Lane Keeping (assesment)
Good
Lane Keep Assist (assesment)
Good
Human Machine Interface (assesment)
Good
AEB Car-to-Car (points)
5.5 /6
AEB Car-to-Car (assesment)
Good

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag
Center Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

EV Battery
160,000 km / 8 years

Car Classification

American Classification
Mid-Size Car
British Classification
Large Family Car
Australian Classification
Medium Car
European Segment
D-Segment
Car.info Classification
Large Family Car
