2023 KGM Korando

South KoreaGasolineFWDSUV

Photos

Specifications

Vehicle Details

Year
2023
Make
KGM
Model
Korando
Body Style
SUV
Generation
C300
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
1.5 T-GDI
Engine Configuration
Inline
Power (hp)
163 hp
Power (kW)
120 kW
Torque
260 Nm (192 lb-ft)
Top speed
189 km/h (117 mph)
0–60 mph
10.3 seconds (estimated)
0–100 km/h
10.84 seconds
Displacement
1,497 cc

Dimensions

Length
4,450 mm (175.2 in)
Height
1,629 mm (64.1 in)
Wheelbase
2,675 mm (105.3 in)
Curb weight
1,517 kg (3,344 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,000 - 5,500 rpm
Rev. at Max Torque
1,500 - 4,000 rpm
Engine Configuration
Bore
76 mm (3.0 in)
Stroke
82.5 mm (3.2 in)
Compression Ratio
9.5 :1
Engine Configuration
Inline

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed

Fuel

General
Tank Volume
50 litres
Emission
Emission Standard
Euro 6d
Emission Class
E
WLTP Consumption
Low (l/100km) (WLTP)
7.6 – 8.3 litres / 100 km
Medium (l/100km)
6 – 6.3 litres / 100 km
High (l/100km)
5.5 – 5.7 litres / 100 km
Extra High (l/100km)
6.8 – 7 litres / 100 km
Combined (l/100km)
6.4 – 6.6 litres / 100 km
Emission WLTP
CO₂, Combined
171 – 182 - 175 – 182 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
1,870 mm (73.6 in)
Track, Front
1,590 mm (62.6 in)
Track, Rear
1,610 mm (63.4 in)
Overhang, Front
922 mm (36.3 in)
Overhang, Rear
868 mm (34.2 in)
Turning Circle
10.7 m
Ground Clearance
169 mm (6.7 in)

Weight

Gross Weight
2010 – 2040 kg (4,431 – 4,497 lb)
Max Trailer Load, braked 12%
1,500 kg (3,307 lb)
Max Trailer Load, unbraked
500 – 750 kg (1,102 – 1,653 lb)
Cargo Capacity
493 – 496 kg (1,087 – 1,093 lb)
Max Roof Load
75 kg (165 lb)
Max Towbar Download
85 kg (187 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
112
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
66.6
Central Bore (CB), rear
66.6
Fastening Type
Lug Bolts
Rim Type
Disc Wheel

Interior

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
551 litres
Volume, Back Seat Collapsed
1,248 litres

Other

Car Classification

American Classification
Compact SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV
