2024 Ford Transit E-Transit Courier

United StatesElectricFWDLCV

Photos

Specifications

Vehicle DetailsPowertrainDimensionsEngine & PerformanceDimensions & WeightExteriorInteriorFeaturesSafety & SecurityOther

Vehicle Details

Year
2024
Make
Ford
Model
Transit
Variant
E-Transit Courier
Body Style
LCV
Generation
2nd Generation
Seats
2
Doors
4
Fuel
Electric
Drivetrain
FWD
Transmission
Automatic (Fixed)

Powertrain

Engine Name
E-Transit Courier Single Speed
Engine Configuration
Electric
Power (hp)
136 hp
Power (kW)
100 kW
Electric range
292 km (181 mi)

Dimensions

Length
4,337 mm (170.7 in)
Width
1,800 mm (70.9 in)
Height
1,827 mm (71.9 in)
Wheelbase
2,692 mm (106.0 in)

Engine & Performance

Engine

Engine Configuration
Type of Electric Car
Electric
AC Charge Type
  • Single-phase
  • Three-phase

Energy & Range

WLTP Consumption
Energy consumption
17.1 kWh/100km
Electric Range
292 - 293 km (181 - 182 mi)
Emission WLTP
CO₂, Combined
0 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,076 mm (81.7 in)
Overhang, Front
832 - 838 mm (32.8 - 33.0 in)
Overhang, Rear
813 - 814 mm (32.0 - 32.0 in)
Turning Circle
10.7 m

LCV Specific

Side Door › Side Door Height

Exterior

Chassis & Body

Chassis
Chassis
LCV (Panel Van)
Doors
Front Doors
Conventional
Rear Doors
Sliding (Right)

Equipment

Side Mirrors

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Number of Climate Zones
1
Air Condition
Yes

Features

Comfort Features

Keyless Start
Optional
Cruise Control
Yes
Speed Limiter
Yes
Parking Heater
Yes
Cameras
Optional
Wireless Phone Charger
Optional
Cruise Control

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Driver
Passenger
Rear
Seat Belt Reminder
Driver

Other

Car Classification

American Classification
Cargo Van
British Classification
Van
Australian Classification
Van
European Segment
M-Segment
Car.info Classification
Cargo Van
Ford emblem
H1
1,069 mm (42.1 in)
Side Door › Side Door Width
L1
528 mm (20.8 in)
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Mirror Shape, Driver side
Aspheric
Mirror Shape, Passenger side
Aspheric
Windows
Window Lifts, Front
Powered
Heated Windows
Front
Windows › Window Lifts, Features
One-touch up/down
Optional
Windows › Window Lifts, Features › One-touch up/down
Driver
Optional
Passenger
Optional
Windows › Heated Windows
Rear
Optional
Other Equipment
Tow Hook
Optional
Roof Railing
Optional
Mud Flaps
Optional
Other Equipment › Tow Hook
Rear
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Special Features
Automatic Headlight Activation
Fog Lights
Front
Halogen

Colour

Non-painted
Bumper (Rear)

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Rim Type
Disc Wheel
Controls
Buttons
Connectivity › Media Inputs
USB
USB-A
Connectivity › Media Inputs › USB
Placement
Front
Number of Ports
2 pcs
Connectivity
App-Connect
  • Android Auto
  • Apple CarPlay
Bluetooth
  • Phone
  • Audio
Displays
Center Display
8"
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
4 pcs
Interior Storage › Storage Compartments
Armrest Hatch
Front
Lights
Read Light
Front
Other Equipment
Make-up Mirror
Driver Side
12V Outlet
Front
Carpets
Front
Other Equipment › 12V Outlet
Trunk
Optional
Other Equipment › Carpets
Material
Rubber
Colour
Black

Steering Wheel

Heated
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Number of Spokes
2

Trunk

Rear Trunk
Yes
Carpet
Optional
Light
Yes
Rear Trunk
Depth
1,802 mm (70.9 in)
Width
1,535 mm (60.4 in)
Width, Between Wheel Arches
1,220 mm (48.0 in)
Opening Width

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Lumbar Support
Manual
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Adaptive Cruise Control
Optional
Parking Heater
Type
Cabin Heater
Cameras
Rear
Optional
Wireless Phone Charger
Front
Optional

Other Features

GPS
Optional
Start & Stop
Yes
Horn
Single Note

Accessories

Tire Repair Kit
Yes
Yes
PassengerYes
Rear-
Belt Pretensioner
DriverYes
PassengerYes
Rear-
Belt Load Limiter
DriverYes
PassengerYes
Rear-
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Rear Collision Warning (RCW)
Yes
Front Cross-Traffic Alert (FCTA)
Optional
Rear Cross-Traffic Alert (RCTA)
Optional
Lane Assist System
Optional
Speed Assist
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional
Driver Alertness Warning (DAW)
Yes
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Side
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Emergency Call
Yes
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2024
Adult Occupant
62 %
Child Occupant
80 %
Vulnerable Road Users
81 %
Safety Assist
54 %
Overall
3/5 stars

Airbags

Feature
Driver
Passenger
Rear
Frontal Airbag
DriverYes
PassengerYes
Rear-
Side Chest Airbag
Driver
Transit
8.9

€67,000

MSRP · EUR

Body
1,235 mm (48.6 in)
Height
1,253 mm (49.3 in)
Sill Height
583 mm (23.0 in)
Carpet
Rubber
Optional
Manual
Headrest, Height
Manual
Front Seats
Armrest
Driver
Parking Assist
Optional
Sign Assist
Optional
Trailer Assist
Optional
Trailer Stability Assist (TSA)
Optional
Emergency Assist
Optional
Emergency Stop Signal (ESS)
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes
Cyclist
Yes
City
Yes
Yes
PassengerYes
Rear-
Side Head Airbag
DriverYes
PassengerYes
Rear-
Side Pelvis Airbag
DriverYes
PassengerYes
Rear-
Curtain Airbag
DriverYes
PassengerYes
Rear-
Center Airbag
DriverYes
Passenger-
Rear-
Airbag cut-off Switch
Driver-
PassengerYes
Rear-
LCV
Variant
Generation
2nd Generation
Year
Powertrain
E-Transit Courier Single Speed
Horsepower
136 hp
Drivetrain
FWD
Fuel
Electric
Transmission
Automatic (Fixed)
