2024 Mazda CX-60

JapanGasolineAWDSUV

Photos

Specifications

Vehicle Details

Year
2024
Make
Mazda
Model
CX-60
Body Style
SUV
Generation
1st Generation
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic, 8-speed

Powertrain

Engine Name
2.5 SKYACTIV-G AWD Automatic
Engine Configuration
Inline
Power (hp)
188 hp
Power (kW)
138 kW
Torque
250 Nm (184 lb-ft)
Displacement
2,488 cc

Dimensions

Length
4,745 mm (186.8 in)
Width
1,890 mm (74.4 in)
Height
1,682 mm (66.2 in)
Wheelbase
2,870 mm (113.0 in)
Curb weight
1,720 kg (3,792 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
3,000 rpm
Engine Configuration
Bore
89 mm (3.5 in)
Stroke
100 mm (3.9 in)
Compression Ratio
13 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
60,000 km / 3 years
Spark Plug
120,000 km (74,565 mi)
Brake Fluid
40,000 km / 2 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
100,000 km / 5 years
Interior Filter
40,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic, 8-speed

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
328 mm (12.9 in)
Cooling
Ventilated
Rear Brakes
Diameter
328 mm (12.9 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
58 litres
Fuel Consumption NEDC
City
9.6 litres / 100 km
Highway
6.8 litres / 100 km
Combined
7.6 litres / 100 km

Dimensions & Weight

Exterior

Width, with Mirrors
2,134 mm (84.0 in)
Track, Front
1,640 mm (64.6 in)
Track, Rear
1,645 mm (64.8 in)
Turning Circle
10.8 m
Ground Clearance
170 - 175 mm (6.7 - 6.9 in)

Interior

Head Room, Front
1,004 mm (39.5 in)
Head Room, Rear
984 mm (38.7 in)
Leg Room, Front
1,058 mm (41.7 in)
Leg Room, Rear
990 mm (39.0 in)
Shoulder Room, Front
1,504 mm (59.2 in)
Shoulder Room, Rear
1,441 mm (56.7 in)

Weight

Max Trailer Load, braked 12%
2,500 kg (5,512 lb)
Max Trailer Load, braked 8%
2,500 kg (5,512 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Max Roof Load
75 kg (165 lb)
Max Towbar Download
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Protective Moldings
Yes
Chassis › Protective Moldings
Front
Bottom-Strip
Rear
Bottom-Strip
Sides
Bottom-Strip
Wheel Arches
Yes
Colour
Non-Painted
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-up

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical (Automatic Parking Fold)
Heated
Yes
Turning Signal
Yes
Side Mirrors › Folding
Driver side
Optional
Windscreen Wipers
Speed Sensing Intermittent
Yes
Intermittent Control
Yes
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered (Safety Lock)
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Safety Glass
Yes
Windows › Window Lifts, Features
Pinch Protection
  • Driver
  • Passenger
  • Rear
One-touch up/down
  • Driver
  • Passenger
Windows › Heated Windows
Front
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Roof Railing
Optional
Antenna
Yes
Mud Flaps
Optional
Other Equipment › Sunroof
Sun Blind
Optional
Other Equipment › Sunroof › Sun Blind
Tinted Glass
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
  • Automatic Headlight Activation
  • Main Beam Assist
  • Adaptive Headlights
  • Come Home/Leaving Lights
  • Headlight Washers
Fog Lights
Rear
LED
Special Features
Dynamic Cornering Lights
Optional
Headlight Range Adjustment
Automatic (Dynamic)

Colour

Door Handles
Same as Car

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Central Bore (CB), rear
67.1
Fastening Type
Lug Nuts
Tightening Torque
108 - 147 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Speedometer
Digital
Tachometer
Digital
Fuel Gauge
Digital
Coolant Temperature
Digital
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
Buttons
Climate Control › Air Condition
Refrigerant
R1234yf
Refrigerant, Capacity
760 g
Connectivity
Radio
  • AM
  • FM
  • DAB+
App-Connect
  • Android Auto
  • Apple CarPlay (Wired | Wireless)
Bluetooth
  • Phone
  • Audio
Connectivity › Media Format
Memory Card Reader
SD
Connectivity › Media Inputs
AUX
Front
USB
USB-C
Connectivity › Media Inputs › USB
Placement
  • Front
  • Rear
Displays
Center Display
Yes
Center Display Controls
  • Touchscreen
  • Buttons
  • Rotary Dial
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
8 - 12 pcs
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Back Pocket
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
Front
Guide Light
Entry Guard
Ambient Light
Optional
Lights › Guide Light
Footwell
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
Carpets
Optional
Other Equipment › Clock
Digital
Center Display
Other Equipment › Carpets
Front
Optional
Rear
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Electric
Number of Spokes
3
Material
Leather
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Menu Navigation
Yes
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down (Buttons)
  • Resume
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Answer Phone
Yes
Volume
Buttons
Mute Audio
Yes
Adjustments
Tilt
Yes
Telescope
Yes

Trunk

Rear Trunk
Yes
Automatic Open
Optional
Automatic Close
Optional
Barrier Net/Grid
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
570 litres
Volume, Back Seat Collapsed
1,726 litres
Depth
975 mm (38.4 in)
Depth, Back Seat Collapsed
1,918 mm (75.5 in)
Width
1,330 mm (52.4 in)
Width, Between Wheel Arches
1,130 mm (44.5 in)
Opening Width
1,060 mm (41.7 in)
Height
817 mm (32.2 in)
Height, to Trunk Cover
499 mm (19.6 in)
Automatic Open
Button on Trunk Door
Optional

Design

Transmission Knob Material
Leather
Pedals
Standard

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Cushion Tilt
Optional
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
  • Manual
  • Powered
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Armrest
Middle
Ventilated Seats
Optional
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Heated Seats › Cushion
Backrest
Optional
Front Seats › Ventilated Seats
Driver
Optional
Passenger
Optional
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
40/20/40
Heated Seats
Optional
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes
Second Seat Row › Headrests › Centre Seat
Height Adjustment
Yes

Features

Comfort Features

Keyless Entry
Yes
Cruise Control
Yes
Speed Limiter
Yes
Cameras
Rear
Cruise Control
Adaptive Cruise Control
Optional
Cameras
View Location
Center Display

Other Features

GPS
Navigation
Start & Stop
Yes
Driving Mode Selection
  • Normal
  • Off-road
  • Sport
Smartphone App
Yes
Horn
Dual Note
GPS
Map-update
SD-Card

Accessories

Tire Repair Kit
Yes
Compressor
Yes
Trunk Modules
Optional
Bicycle Holder
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Front Cross-Traffic Alert (FCTA)
Yes
Safe Exit Warning (SEW)
Yes
Lane Assist System
Yes
Hill Start Assist (HSA)
Yes
Hill Descent Control (HDC)
Yes
Sign Assist
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes
Cyclist
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Yes
Driver Alertness Warning (DAW)
Yes
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Electrical
Emergency Call
Yes
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2022
Adult Occupant
88 %
Child Occupant
91 %
Vulnerable Road Users
89 %
Safety Assist
76 %
Overall
5/5 stars
Adult Occupant
Total Points
33.8 /38
Frontal Impact
12.9 /16
Lateral Impact
16 /16
Rear Impact
3.9 /4
Rescue and Extrication
1 /2
Child Occupant
Total Points
45 /49
Crash Test Performance
  • 16
  • 8 /16
Safety Features
9 /13
CRS Installation Check
12 /12
Vulnerable Road Users
Total Points
48.2 /49
Pedestrian
  • 20.5
  • 6
  • 6
AEB Vulnerable Road Users
15.7 /18
AEB Pedestrian
7 /9
AEB Pedestrian (assesment)
Good
AEB Cyclist
8.7 /9
AEB Cyclist (assesment)
Good
Safety Assist
Speed Assistance (points)
2.5 /3
Speed Assistance (assesment)
Good
Occupant Status Monitoring (points)
2 /3
Occupant Status Monitoring (assesment)
Adequate
Seat Belt Reminder (points)
1 /2
Seat Belt Reminder (assesment)
Marginal
Driver Monitoring (points)
1
Driver Monitoring (assesment)
Good
Lane Support (points)
2.3 /4
Lane Support (assesment)
Adequate
Emergency Lane Keeping (assesment)
Marginal
Lane Keep Assist (assesment)
Good
Human Machine Interface (assesment)
Good
AEB Car-to-Car (points)
5.5 /6
AEB Car-to-Car (assesment)
Good

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Center Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
  • J-Segment JC-Segment
  • JD-Segment
Car.info Classification
Large SUV

Similar suvs

Suggested vehicles
