2024 Toyota Hilux

JapanDiesel4WDPickup

Photos

Specifications

Vehicle Details

Year
2024
Make
Toyota
Model
Hilux
Body Style
Pickup
Generation
AN120/AN130 1st Facelift
Seats
5
Doors
4
Fuel
Diesel
Drivetrain
4WD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
2.8 4WD
Engine Configuration
Inline
Power (hp)
204 hp
Power (kW)
150 kW
Torque
500 Nm (369 lb-ft)
Top speed
175 km/h (109 mph)
0–60 mph
10.2 seconds (estimated)
0–100 km/h
10.7 seconds
Displacement
2,755 cc

Dimensions

Length
5,325 mm (209.6 in)
Width
1,855 mm (73.0 in)
Height
1,815 mm (71.5 in)
Wheelbase
3,085 mm (121.5 in)
Curb weight
2,206 kg (4,863 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Torque
1,600 - 2,800 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 5W-30
Semi-synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
7.5 litres
Engine Configuration
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Engine Cooling
Liquid Cooling
Service Intervals
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed

Fuel

General
Tank Volume
80 litres
Emission
Emission Standard
Euro 6d -ISC
Emission Class
D
WLTP Consumption
Combined (l/100km)
9.2 - 9.5 litres / 100 km
Fuel Consumption NEDC
City
7.9 - 8.3 litres / 100 km
Highway
6.5 - 6.8 litres / 100 km
Combined
7 - 7.3 litres / 100 km
Emission WLTP
CO₂, Combined
241 - 248 g/km
Emission NEDC
CO₂, Combined
185 - 194 g/km

Dimensions & Weight

Exterior

Track, Front
1,540 mm (60.6 in)
Track, Rear
1,550 mm (61.0 in)
Turning Circle
12.8 m
Ground Clearance
227 - 310 mm (8.9 - 12.2 in)

Interior

Head Room (est.), Rear
980 - 1,000 mm (38.6 - 39.4 in)
Leg Room (est.), Rear
880 - 900 mm (34.6 - 35.4 in)

Weight

Gross Weight
3,210 kg (7,077 lb)
Max Trailer Load, braked 12%
3,500 kg (7,716 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
780 - 1,004 kg (1,720 - 2,213 lb)
Max Roof Load
50 kg (110 lb)
Max Towbar Download
140 kg (309 lb)

Exterior

Chassis & Body

Chassis
Chassis
Pickup
Pillars
A-C
Body Material
Steel
Roof Material
Steel

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
  • Front
  • Rear
Tinted Windows
Optional
Windows › Window Lifts, Features
Pinch Protection
Optional
One-touch up/down
Optional
Windows › Window Lifts, Features › Pinch Protection
Driver
Optional
Passenger
Optional
Windows › Window Lifts, Features › One-touch up/down
Driver
Optional
Passenger
Optional
Windows › Tinted Windows
Windscreen, upper part
Optional
Second Row
Optional
Rear Window
Optional
Other Equipment
Spoiler
Front
Antenna
Whip
Side Steps
Stationary

Lights

Fog Lights
Yes
Special Features
Come Home/Leaving Lights
Fog Lights
Rear
LED
Special Features
Headlight Washers
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
6 pcs
Bolt Distance
139.7
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
106.1
Central Bore (CB), rear
106.1
Fastening Type
Lug Nuts
Tightening Torque
105 Nm
Rim Type
Disc Wheel
Spare Wheel
Full-size (Steel)

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Square
Climate Control
Air Condition
Yes
Micro Filter
Yes
Pollen Filter
Yes
Controls
  • Buttons
  • Rotary Dials
Connectivity
Radio
  • AM
  • FM
Media Format
CD
Bluetooth
Phone
Connectivity › Radio
DAB
Optional
Connectivity › Media Inputs
AUX
Front
USB
Yes
Connectivity › Media Inputs › USB
Placement
Front
Displays
Center Display
Yes
Displays › Center Display
Type
Colour
Touchscreen
Optional
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
  • Cooled
  • Lockable (Manual)
Back Pocket
Yes
Sunglass Compartment
Yes
Card Holder
Yes
Under Seats
Rear
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Lights
Read Light
  • Front
  • Rear
Guide Light
Yes
Ambient Light
Optional
Other Equipment
12V Outlet
Front
230V Outlet
Optional
Other Equipment › 230V Outlet
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down (Buttons)
  • Resume
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Buttons

Trunk

Rear Trunk
Yes

Design

Pedals
Standard

Seats

Front Seats › Adjustments, Driver
Seat Height
Optional
Backrest Angle
Yes
Front Seats
Power Seat, Driver
Optional
Heated Seats
  • Driver
  • Passenger
Armrest
Optional
Front Seats › Heated Seats
Areas
Cushion
Second Seat Row
Collapsible
Manual
Second Seat Row › Collapsible
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Optional

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Adaptive Cruise Control
Cameras
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats

Assist Systems

Lane Assist System
Yes
Hill Start Assist (HSA)
Yes
Hill Descent Control (HDC)
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Four-channel
Electronic Brake Assist (BA/EBA)
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Pedestrian
Yes
Cyclist
Yes

Sensors

Parking Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Yes
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2016
Adult Occupant
85 %
Child Occupant
82 %
Vulnerable Road Users
73 %
Safety Assist
25 %
Overall
3/5 stars
ASEAN NCAP
Test Year
2020
Overall
5/5 stars
Adult Occupant, Points
45.74
Child Occupant, Points
22.47
Safety Assist, Points
15.21

Airbags

Feature
Frontal Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Mid-Size Pickup Truck
British Classification
Pick-up
Australian Classification
Ute
European Segment
J-Segment JD-Segment
Car.info Classification
Pickup
