2025 Cadillac CT5

United StatesGasolineRWDSedan

Photos

Specifications

Vehicle Details

Year
2025
Make
Cadillac
Model
CT5
Body Style
Sedan
Generation
1st Generation Facelift
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
  • Automatic Electrohydraulic
  • Manual, 10
  • 6-speed

Powertrain

Engine Name
-V Blackwing
Engine Configuration
V
Power (hp)
677 hp
Power (kW)
498 kW
Torque
893 Nm (659 lb-ft)
Displacement
6,162 cc

Dimensions

Length
4,977 mm (195.9 in)
Width
1,883 mm (74.1 in)
Height
1,437 mm (56.6 in)
Wheelbase
2,947 mm (116.0 in)
Curb weight
1,870 kg (4,123 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,500 rpm
Rev. at Max Torque
3,600 rpm
Engine Fluids
Engine Oil, Volume
8.5 litres
Engine Coolant, Volume
13.1 litres
Engine Configuration
Bore
103.25 mm (4.1 in)
Stroke
92 mm (3.6 in)
Compression Ratio
10 :1
Engine Configuration
V-Engine
Supercharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
Cam-in-block (Pushrod)
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
  • Automatic Electrohydraulic
  • Manual, 10
  • 6-speed
Gear Selector
  • Stick
  • Joystick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
2.29 – 4.7 :1
2nd Gear
1.61 – 2.99 :1
3rd Gear
1.21 – 2.15 :1
4th Gear
1 – 1.8 :1
5th Gear
0.82 – 1.52 :1
6th Gear
0.54 – 1.28 :1
7th Gear
1 :1
8th Gear
0.85 :1
9th Gear
0.69 :1
10th Gear
0.64 :1
Final Drive
2.85 – 3.73 :1
Reverse
3.11 – 4.87 :1

Fuel

General
Tank Volume
66 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Adaptive Cylinder Management
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
  • Front (6)
  • Rear (4)
Brakes Material
Carbon Ceramic
Front Brakes
Diameter
398 mm (15.7 in)
Width
36 mm (1.4 in)
Cooling
Ventilated
Rear Brakes
Diameter
373.5 mm (14.7 in)
Width
28 mm (1.1 in)
Cooling
Ventilated

Suspensions

Suspension, Front
Independent
MacPherson Strut
Spring, Rear
Coil
Strut Bar
Front
Anti-roll Bar
  • Front
  • Rear
Suspension, Rear
Independent
Multi-link

Dimensions & Weight

Exterior

Width, with Mirrors
2,039 mm (80.3 in)
Width, with Mirrors (folded)
1,846 mm (72.7 in)
Track, Front
1,622 mm (63.9 in)
Track, Rear
1,595 mm (62.8 in)
Turning Circle
12.9 m

Interior

Head Room, Front
990 - 991 mm (39.0 - 39.0 in)
Head Room, Rear
930 mm (36.6 in)
Leg Room, Front
1,077 - 1,078 mm (42.4 - 42.4 in)
Leg Room, Rear
941 - 963 mm (37.0 - 37.9 in)
Hip Room, Front
1,364 mm (53.7 in)
Hip Room, Rear
1,364 mm (53.7 in)
Shoulder Room, Front
1,440 mm (56.7 in)
Shoulder Room, Rear
1,415 mm (55.7 in)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Alpha Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
120
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
66.9
Central Bore (CB), rear
66.9
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
190 Nm
Rim Material
  • Alloy
  • Aluminium
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Yes
Instrument Cluster › Trip Computer
Display
Yes

Steering Wheel

Heated
Yes
Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
337 litres

Seats

Front Seats
Heated Seats
  • Driver
  • Passenger
Massage
  • Driver
  • Passenger
Ventilated Seats
  • Driver
  • Passenger

Features

Comfort Features

Cameras
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Seat Belt Colour
Black
Feature
Belt Pretensioner
Belt Load Limiter

Assist Systems

Forward Collision Warning (FCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Yes
Parking Assist
Yes
Sign Assist
Yes

Brake Systems

Anti-lock Braking System (ABS)
Four-channel

Sensors

Blind Spot Detection (BLIS)
Yes
Pedestrian/Bicycle Detection
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Knee Airbag
Curtain Airbag
