2025 Mazda CX-5

JapanMild Hybrid GasolineFWDSUV

Photos

Specifications

Vehicle Details

Year
2025
Make
Mazda
Model
CX-5
Body Style
SUV
Generation
KF 2nd Facelift
Seats
5
Doors
5
Fuel
Mild Hybrid Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
2.0 SKYACTIV-G
Engine Configuration
Inline
Power (hp)
165 hp
Power (kW)
121 kW
Torque
213 Nm (157 lb-ft)
Top speed
201 km/h (125 mph)
0–60 mph
9.0 seconds (estimated)
0–100 km/h
9.5 seconds
Displacement
1,998 cc

Dimensions

Length
4,575 mm (180.1 in)
Width
1,845 mm (72.6 in)
Height
1,680 mm (66.1 in)
Wheelbase
2,700 mm (106.3 in)
Curb weight
1,545 kg (3,406 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-20
  • 5W-30
Semi-synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
4.2 litres
Engine Configuration
Compression Ratio
13 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Mild-Hybrid
Yes
Service Intervals
Air Filter
60,000 km / 3 years
Spark Plug
120,000 km (74,565 mi)
Brake Fluid
40,000 km / 2 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
100,000 km / 5 years
Transmission, Fluid
180,000 km (111,847 mi)
Interior Filter
40,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
  • Front
  • Rear
Front Brakes
Diameter
297 mm (11.7 in)
Cooling
Ventilated
Rear Brakes
Diameter
303 mm (11.9 in)
Cooling
Solid

Suspensions

Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Yes

Fuel

General
Tank Volume
56 litres
Emission
Emission Standard
Euro 6d
WLTP Consumption
Low (l/100km) (WLTP)
8 – 8.6 litres / 100 km
Medium (l/100km)
6.3 – 6.6 litres / 100 km
High (l/100km)
5.6 – 5.9 litres / 100 km
Extra High (l/100km)
6.8 – 7.3 litres / 100 km
Combined (l/100km)
6.5 – 6.9 litres / 100 km
Emission WLTP
CO₂, Combined
146 – 156 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,115 mm (83.3 in)
Track, Front
1,595 mm (62.8 in)
Track, Rear
1,595 mm (62.8 in)
Overhang, Front
965 mm (38.0 in)
Overhang, Rear
910 mm (35.8 in)
Turning Circle
11 m
Ground Clearance
192 - 200 mm (7.6 - 7.9 in)

Interior

Head Room, Front
999 - 1,007 mm (39.3 - 39.6 in)
Head Room, Rear
991 mm (39.0 in)
Leg Room, Front
1,040 mm (40.9 in)
Leg Room, Rear
1,007 mm (39.6 in)
Shoulder Room, Front
1,450 mm (57.1 in)
Shoulder Room, Rear
1,390 mm (54.7 in)

Weight

Max Trailer Load, braked 12%
1,800 kg (3,968 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
Heated
Yes
Turning Signal
Yes
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
  • Front
  • Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
  • Second Row
  • Rear Window
Other Equipment
Normal Roof
Yes
Roof Railing
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Central Bore (CB), rear
67.1
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
108 - 147 Nm
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
  • Buttons
  • Rotary Dials
Climate Control › Air Condition
Refrigerant
  • R1234yf
  • R134A
Connectivity
Radio
  • AM
  • FM
  • DAB
Bluetooth
Phone
Connectivity › Media Inputs
AUX
Front
USB
Yes
Connectivity › Media Inputs › USB
Placement
Front
Displays
Center Display
Yes
Displays › Center Display
Type
Colour
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Back Pocket
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
  • Make-up Light
Clock
Digital
12V Outlet
Front
Carpets
  • Front
  • Rear

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Material
Leather
Colour
Black
Multifunction Steering Wheel
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down (Buttons)
  • Resume
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Volume
Buttons
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Automatic Open
Yes
Automatic Close
Yes
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
522 litres
Volume, Back Seat Collapsed
1,638 litres
Depth
950 mm (37.4 in)
Width
1,445 mm (56.9 in)
Width, Between Wheel Arches
1,049 mm (41.3 in)

Design

Transmission Knob Material
Leather

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats
Heated Seats
  • Driver
  • Passenger
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes
Second Seat Row › Headrests › Centre Seat
Height Adjustment
Yes
Second Seat Row
Number of Seats
3
Type of Seat
Adult

Features

Comfort Features

Cruise Control
Yes
Cameras
Rear

Other Features

Start & Stop
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes
Lane Keeping Assist (LKA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Brake Energy Regeneration
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Blind Spot Detection (BLIS)
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Central Locking
Remote
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2017
Adult Occupant
95 %
Child Occupant
80 %
Vulnerable Road Users
78 %
Safety Assist
59 %
Overall
5/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV
