2026 Cadillac Escalade

United StatesGasoline4WDSUV

Photos

Specifications

Vehicle Details

Year
2026
Make
Cadillac
Model
Escalade
Body Style
SUV
Generation
5th Generation Facelift
Seats
7
Doors
5
Fuel
Gasoline
Drivetrain
4WD
Transmission
Automatic, 10-speed

Powertrain

Engine Name
-V Hydra-Matic
Engine Configuration
V
Power (hp)
691 hp
Power (kW)
508 kW
Torque
885 Nm (653 lb-ft)
Displacement
6,162 cc

Dimensions

Length
5,410 mm (213.0 in)
Width
2,158 mm (85.0 in)
Height
1,938 mm (76.3 in)
Wheelbase
3,071 mm (120.9 in)
Curb weight
2,885 kg (6,360 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,500 rpm
Rev. at Max Torque
3,600 rpm
Engine Configuration
Bore
103.25 mm (4.1 in)
Stroke
92 mm (3.6 in)
Compression Ratio
10 :1
Engine Configuration
V-Engine
Supercharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
Cam-in-block (Pushrod)
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
Automatic, 10-speed
Gear Selector
Stalk
Gear Selector Location
Steering Column

Fuel

General
Tank Volume
91 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brake Caliper Pistons
  • Front
  • Rear
Brakes Material
Cast Iron
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Electronic Damper Control (EDC)
Yes
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Dimensions & Weight

Exterior

Track, Front
1,737 mm (68.4 in)
Track, Rear
1,730 mm (68.1 in)
Turning Circle
12.1 m

Interior

Head Room, Front
1,025 mm (40.4 in)
Head Room, Rear
952 mm (37.5 in)
Head Room, Third Row
970 mm (38.2 in)
Leg Room, Front
1,131 mm (44.5 in)
Leg Room, Rear
1,060 mm (41.7 in)
Leg Room, Third Row
886 mm (34.9 in)
Hip Room, Front
1,567 mm (61.7 in)
Hip Room, Rear
1,549 mm (61.0 in)
Hip Room, Third Row
1,255 mm (49.4 in)
Shoulder Room, Front
1,664 mm (65.5 in)
Shoulder Room, Rear
1,630 mm (64.2 in)
Shoulder Room, Third Row
1,592 mm (62.7 in)

Weight

Cargo Capacity
589 kg (1,299 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Body-on-Frame
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
GMT Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Speed Sensing Intermittent
Yes
Intermittent Control
Yes
Rear Wiper
Yes
Rear Washer System
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Rear
Powered (Safety Lock)
Heated Windows
Rear
Tinted Windows
  • Second Row
  • Rear Window
Safety Glass
Yes
Other Equipment
Sunroof
Panoramic
Roof Railing
Yes
Antenna
Shark Fin
Other Equipment › Sunroof
Material
Glass
Shading
Sun Blind
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)
Colour
Black

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Special Features
Adaptive Headlights

Colour

Finish
Metallic

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
6 pcs
Bolt Distance
139.7
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
78.1
Central Bore (CB), rear
78.1
Fastening Type
Lug Nuts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
190 Nm
Rim Material
Alloy

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Yes
Speedometer
Digital
Tachometer
Digital
Fuel Gauge
Digital
Coolant Temperature
Digital
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Cockpit
Climate Control
Climate Control
Automatic
Number of Climate Zones
3
Air Condition
Yes
Micro Filter
Yes
Outside Temperature Indicator
Yes
Controls
Touchscreen
Climate Control › Air Condition
Refrigerant
R1234yf
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
  • Cooled
  • Light
  • Lockable (Manual)
Armrest Hatch
  • Front
  • Back
Back Pocket
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
  • Front
  • Rear
Guide Light
  • Entry Guard
  • Footwell (Front | Rear)
  • Door Handles
Ambient Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Trunk
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Number of Spokes
2
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Menu Navigation
Yes
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down
  • Resume
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Yes
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
722 litres
Volume, Back Seat Collapsed
3,426 litres
Volume (Opt. third seat row, Collapsed seat)
2,064 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Front Seats
Armrest
Middle
Third/Fourth Seat Row
Third Seat Row
Yes

Features

Comfort Features

Keyless Entry
Yes
Cruise Control
Adaptive Cruise Control
Cameras
  • Front
  • Rear
Cameras
View Location
Center Display

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Electronic Stability Control (ESC)
Roll Stability Control (RSC)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Anti-lock Braking System (ABS)
Four-channel
Electronic Brakeforce Distribution (EBD)
Yes

Sensors

Door Open Warning
Yes
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Central Locking
Remote
Type of Keys
Remote Keys
Immobiliser
Electronic
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Full-Size SUV
British Classification
Large 4x4
Australian Classification
Upper Large SUV
European Segment
J-Segment JD-Segment
Car.info Classification
Large SUV
