2026 Mazda CX-5

JapanMild Hybrid GasolineFWDSUV

Photos

Specifications

Vehicle Details

Year
2026
Make
Mazda
Model
CX-5
Body Style
SUV
Generation
KI
Seats
5
Doors
5
Fuel
Mild Hybrid Gasoline
Drivetrain
FWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
2.5 e-SKYACTIV-G M Hybrid Automatic
Engine Configuration
Inline
Power (hp)
141 hp
Power (kW)
104 kW
Torque
238 Nm (176 lb-ft)
Top speed
187 km/h (116 mph)
0–60 mph
10.0 seconds (estimated)
0–100 km/h
10.5 seconds
Displacement
2,488 cc

Dimensions

Length
4,690 mm (184.6 in)
Width
1,860 mm (73.2 in)
Height
1,695 mm (66.7 in)
Wheelbase
2,815 mm (110.8 in)
Curb weight
1,654 kg (3,646 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,500 - 5,000 rpm
Rev. at Max Torque
3,500 - 3,750 rpm
Engine Configuration
Bore
89 mm (3.5 in)
Stroke
100 mm (3.9 in)
Compression Ratio
13 :1
Engine Configuration
Inline
Mild-Hybrid
Yes

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Brakes

Parking Brake
Electric
Auto Hold
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
297 mm (11.7 in)
Cooling
Ventilated
Rear Brakes
Diameter
303 mm (11.9 in)
Cooling
Solid

Fuel

General
Tank Volume
56 litres
Emission
Emission Standard
Euro 6 Euro 6e (-bis)
Emission Class
F
WLTP Consumption
Combined (l/100km)
7 litres / 100 km
Emission WLTP
CO₂, Combined
157 - 159 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,077 mm (81.8 in)
Track, Front
1,605 mm (63.2 in)
Track, Rear
1,625 mm (64.0 in)
Turning Circle
12 m
Ground Clearance
205 mm (8.1 in)

Interior

Head Room, Front
996 - 1,007 mm (39.2 - 39.6 in)
Head Room, Rear
992 - 1,020 mm (39.1 - 40.2 in)
Leg Room, Front
1,058 mm (41.7 in)
Leg Room, Rear
1,012 mm (39.8 in)
Shoulder Room, Front
1,462 mm (57.6 in)
Shoulder Room, Rear
1,412 mm (55.6 in)

Weight

Gross Weight
2,230 kg (4,916 lb)
Max Trailer Load, braked 12%
2,000 kg (4,409 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
576 kg (1,270 lb)
Max Roof Load
85 kg (187 lb)
Max Towbar Download
90 kg (198 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
User Memory
Optional
Heated
Optional
Turning Signal
Yes
House Colour
Black
Side Mirrors › Adjustments
Driver side
Optional
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Roof Railing
Optional
Spoiler
Fixed

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Special Features
Come Home/Leaving Lights

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Direct

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Speedometer
Digital
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
10.25"
Instrument Cluster › Trip Computer › Display
Type
Colour
Shape
Cockpit
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
  • DAB+
App-Connect
  • Android Auto
  • Apple CarPlay (Wireless)
Bluetooth
  • Phone
  • Audio
Connectivity › Media Inputs
USB
USB-C
Connectivity › Media Inputs › USB
Placement
Front
Rear
Optional
Number of Ports
2 - 4 pcs
Displays
Center Display
12.9 - 15.6"
Center Display Controls
Touchscreen
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
8 - 12 pcs
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Sunglass Compartment
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Interior Storage › Cup Holders › Rear
Placement
Armrest
Lights
Read Light
Front
Ambient Light
Optional
Selectable Light Colour
Optional
Lights › Read Light
Rear
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
  • Front
  • Trunk
Other Equipment › Clock
Digital
  • Center Display
  • Instrument Cluster

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Optional
Power Steering
Yes
Number of Spokes
3
Material
Leather
Multifunction Steering Wheel
Menu Navigation
Buttons
Cruise Control
  • Activate/Deactivate
  • Speed Up/Down (Buttons)
  • Resume
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Buttons
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Cover
Yes
Light
Yes
Rear Trunk
Volume
583 litres
Volume, Back Seat Collapsed
2,019 litres

Design

Interior Decor Colour
Black

Seats

Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Optional
Heated Seats
  • Driver
  • Passenger
Armrest
Middle
Second Seat Row
Armrest
Yes
Collapsible
Yes
Second Seat Row › Collapsible
Split Fold Ratio
40/20/40

Features

Comfort Features

Keyless Entry
Yes
Cameras
Rear
Cameras
View Location
Center Display

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes
Lane Assist System
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Autonomous Emergency Brake System (AEB)
Yes
Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Autonomous Emergency Brake System (AEB)
Car-to-car
Yes
Reverse
Yes
Pedestrian
Yes
Cyclist
Yes

Sensors

Parking Sensors
  • Front
  • Rear
Pedestrian/Bicycle Detection
Yes
Driver Alertness Warning (DAW)
Yes
Light Sensor
Yes
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Central Locking
Remote
Child Safety Locks
Manual
Active Bonnet
No
Type of Keys
Remote Keys
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2025
Adult Occupant
90 %
Child Occupant
89 %
Vulnerable Road Users
93 %
Safety Assist
83 %
Overall
5/5 stars
Adult Occupant
Total Points
36.1 /38
Frontal Impact
13.6 /16
Lateral Impact
15.9 /16
Rear Impact
4 /4
Rescue and Extrication
2.7 /2
Child Occupant
Total Points
44 /49
Crash Test Performance
  • 16
  • 8 /16
Safety Features
8 /13
CRS Installation Check
12 /12
Vulnerable Road Users
Total Points
58.6 /49
Pedestrian
  • 13.9
  • 4.5
  • 9
AEB Pedestrian
9 /9
AEB Pedestrian (assesment)
Good
AEB Cyclist
8 /9
AEB Cyclist (assesment)
Good
Safety Assist
Speed Assistance (points)
2 /3
Speed Assistance (assesment)
Adequate
Occupant Status Monitoring (points)
1.6 /3
Occupant Status Monitoring (assesment)
Adequate
Seat Belt Reminder (points)
1 /2
Seat Belt Reminder (assesment)
Good
Driver Monitoring (points)
0.6
Driver Monitoring (assesment)
Marginal
Lane Support (points)
3 /4
Lane Support (assesment)
Good
Emergency Lane Keeping (assesment)
Good
Lane Keep Assist (assesment)
Good
Human Machine Interface (assesment)
Good
AEB Car-to-Car (points)
8.5 /6
AEB Car-to-Car (assesment)
Good

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Center Airbag
Airbag cut-off Switch

Child Protection

Feature
Isofix
Integrated Child Seat

Other

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment
Car.info Classification
Medium SUV
