2026 Volkswagen T-Cross

GermanyGasolineFWDSUV

Photos

Specifications

Vehicle Details

Year
2026
Make
Volkswagen
Model
T-Cross
Body Style
SUV
Generation
1st Generation Facelift (Type D3)
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic Dual-clutch
  • Manual, 6
  • 7-speed

Powertrain

Engine Name
1.0 TSI OPF
Engine Configuration
Inline
Power (hp)
116 hp
Power (kW)
85 kW
Torque
200 Nm (148 lb-ft)
Top speed
192 km/h (119 mph)
0–60 mph
9.5 seconds (estimated)
0–100 km/h
10 seconds
Displacement
999 cc

Dimensions

Length
4,127 mm (162.5 in)
Width
1,760 mm (69.3 in)
Height
1,584 mm (62.4 in)
Wheelbase
2,551 mm (100.4 in)
Curb weight
1,270 kg (2,800 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
2,000 - 3,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-20
  • 5W-30
Semi-synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
4 litres
Engine Configuration
Bore
74.5 mm (2.9 in)
Stroke
76.4 mm (3.0 in)
Engine Configuration
Inline
Turbocharger
Single-turbo
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
90,000 km / 6 years
Spark Plug
60,000 km / 4 years
Brake Fluid
3 years
Oil Change & Engine Filter
15,000 km / 1 years

Transmission & Drivetrain

Transmission
  • Automatic Dual-clutch
  • Manual, 6
  • 7-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
276 mm (10.9 in)
Width
24 mm (0.9 in)
Cooling
Ventilated
Rear Brakes
Diameter
230 - 232 mm (9.1 - 9.1 in)
Width
9 mm (0.4 in)

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
Front
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Semi-dependent
Twist-Beam

Fuel

General
Tank Volume
40 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 6d -TEMP-EVAP-ISC
Emission Control
  • Catalyst
  • Particle Filter
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
WLTP Consumption
Low (l/100km) (WLTP)
7 – 7.1 litres / 100 km
Medium (l/100km)
5.4 – 5.6 litres / 100 km
High (l/100km)
4.8 – 5 litres / 100 km
Extra High (l/100km)
5.8 – 6.1 litres / 100 km
Combined (l/100km)
5.6 – 5.8 litres / 100 km
Emission WLTP
CO₂, Combined
127 – 131 - 127 – 133 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
1,977 mm (77.8 in)
Track, Front
1,526 - 1,534 mm (60.1 - 60.4 in)
Track, Rear
1,504 - 1,512 mm (59.2 - 59.5 in)
Overhang, Front
835 mm (32.9 in)
Overhang, Rear
737 mm (29.0 in)
Approach Angle
17 °
Breakover Angle
14.4
Departure Angle
20.3 °
Turning Circle
10.7 m

Interior

Head Room, Front
1,034 mm (40.7 in)
Head Room, Rear
966 mm (38.0 in)
Hip Room, Front
1,460 mm (57.5 in)
Hip Room, Rear
1,429 mm (56.3 in)

Weight

Gross Weight
1750 – 1770 kg (3,858 – 3,902 lb)
Max Trailer Load, braked 12%
1,100 kg (2,425 lb)
Max Trailer Load, braked 8%
1,200 kg (2,646 lb)
Max Trailer Load, unbraked
630 kg (1,389 lb)
Cargo Capacity
443 – 480 kg (977 – 1,058 lb)
Max Roof Load
75 kg (165 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Protective Moldings
Yes
Chassis › Protective Moldings
Wheel Arches
Yes
Colour
Non-Painted
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Other Equipment
Tow Hook
  • Front
  • Rear
Roof Railing
Optional

Lights

Main Beam
LED
Low Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Special Features
Come Home/Leaving Lights

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Number of Bolts
5 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
57.1
Central Bore (CB), rear
57.1
Fastening Type
Lug Bolts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Tightening Torque
120 Nm
Rim Material
Alloy
Rim Type
Disc Wheel
Spare Wheel
Yes
Tire Pressure Monitoring System (TPMS)
Indirect
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Manual
Air Condition
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
  • AM
  • FM
App-Connect
  • Android Auto
  • Apple CarPlay
Connectivity › Media Inputs
USB
USB-C
Connectivity › Media Inputs › USB
Placement
Front
Displays
Center Display
8"
Displays › Center Display
Type
Colour
Speakers
Total Number of Speakers
2 - 6 pcs
Rear-view Mirror
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Rear
Yes
Lights
Read Light
Front
Ambient Light
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
Tilt
Colour
Black
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Voice Command
Yes
Volume
Buttons

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
385 litres
Volume, Back Seat Collapsed
1,281 litres
Depth
748 mm (29.4 in)
Depth, Back Seat Collapsed
1,465 mm (57.7 in)
Width, Between Wheel Arches
998 mm (39.3 in)
Trunk Door Opening Height
2,055 mm (80.9 in)

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black

Seats

Colour & Material
Upholstery
Textile
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult

Features

Accessories

Tool Kit and Jack
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Seat Belt Colour
Black
Belt Load Limiter
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Assist Systems

Lane Assist System
Yes
Sign Assist
Yes
Lane Assist System
Lane Keeping Assist (LKA)
Yes

Sensors

Parking Sensors
Rear
Driver Alertness Warning (DAW)
Yes

Other Features

Emergency Call
Yes

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Warranty

Manufacturer
2 years
Paintwork
3 years
Rust Damage
12 years

Car Classification

American Classification
Subcompact SUV
European Segment
J-Segment JB-Segment
Car.info Classification
Small SUV
