1996 Chrysler Town & Country LWB

United StatesGasolineFWDMinivan

Photos

Specifications

Vehicle Details

Year
1996
Make
Chrysler
Model
Town & Country
Variant
LWB
Body Style
Minivan
Generation
NS
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic, 4-speed

Powertrain

Engine Name
3.8 V6 Automatic
Engine Configuration
V
Power (hp)
166 hp
Power (kW)
122 kW
Torque
308 Nm (227 lb-ft)
Displacement
3,778 cc

Dimensions

Length
5,070 mm (199.6 in)
Width
1,905 mm (75.0 in)
Height
1,740 mm (68.5 in)
Wheelbase
3,030 mm (119.3 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,300 rpm
Rev. at Max Torque
3,100 rpm
Engine Configuration
Bore
96 mm (3.8 in)
Stroke
87 mm (3.4 in)
Compression Ratio
9 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
Cam-in-block (Pushrod)
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
Automatic, 4-speed

Fuel

General
Tank Volume
76 litres

Dimensions & Weight

Exterior

Width, with Mirrors
2,200 mm (86.6 in)
Track, Front
1,600 mm (63.0 in)
Track, Rear
1,626 mm (64.0 in)
Turning Circle
12.8 m
Ground Clearance
140 mm (5.5 in)

Interior

Head Room, Front
1,011 mm (39.8 in)
Head Room, Rear
1,016 mm (40.0 in)
Head Room, Third Row
975 mm (38.4 in)
Leg Room, Front
1,046 mm (41.2 in)
Leg Room, Rear
945 mm (37.2 in)
Leg Room, Third Row
978 mm (38.5 in)
Hip Room, Front
1,364 mm (53.7 in)
Hip Room, Rear
1,450 mm (57.1 in)
Shoulder Room, Front
1,588 mm (62.5 in)
Shoulder Room, Rear
1,628 mm (64.1 in)
Shoulder Room, Third Row
1,570 mm (61.8 in)

Exterior

Chassis & Body

Chassis
Chassis
MPV

Interior

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
575 litres
Depth, Back Seat Collapsed
2,466 mm (97.1 in)
Width, Between Wheel Arches
1,247 mm (49.1 in)

Other

Car Classification

American Classification
Minivan
British Classification
Large MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Large MPV
