2002 Cadillac Escalade

United StatesGasolineAWDSUV

Photos

Specifications

Vehicle Details

Year
2002
Make
Cadillac
Model
Escalade
Body Style
SUV
Generation
2nd Generation
Doors
5
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic, 4-speed

Powertrain

Engine Name
6.0 V8 AWD Hydra-Matic
Engine Configuration
V
Power (hp)
349 hp
Power (kW)
257 kW
Torque
515 Nm (380 lb-ft)
Displacement
5,967 cc

Dimensions

Length
5,052 mm (198.9 in)
Width
2,004 mm (78.9 in)
Height
1,885 mm (74.2 in)
Wheelbase
2,946 mm (116.0 in)
Curb weight
2,512 kg (5,538 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,200 rpm
Rev. at Max Torque
4,000 rpm
Redline
5,600 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 10W-30
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
17 litres
Engine Configuration
Bore
101.6 mm (4.0 in)
Stroke
92 mm (3.6 in)
Compression Ratio
10 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
Cam-in-block (Pushrod)
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Spark Plug
166,000 km (103,148 mi)
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Transmission, Fluid
166,000 km (103,148 mi)
Transmission, Fluid Filter
166,000 km (103,148 mi)

Transmission & Drivetrain

Transmission
Automatic, 4-speed
Gear Selector
Stalk
Gear Selector Location
Steering Column
Gear Ratio
1st Gear
3.06 :1
2nd Gear
1.63 :1
3rd Gear
1 :1
4th Gear
0.7 :1
Final Drive
3.73 :1
Reverse
2.29 :1

Brakes

Parking Brake
Manual
Pedal
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
305 mm (12.0 in)
Width
29 mm (1.1 in)
Rear Brakes
Diameter
330 mm (13.0 in)
Width
30 mm (1.2 in)

Suspensions

Spring, Front
Torsion
Spring, Rear
Coil
Anti-roll Bar
Yes
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Multi-link
Anti-roll Bar
Front
32 mm (1.3 in)
Rear
32 mm (1.3 in)

Fuel

General
Tank Volume
98 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Class
G
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
City
26.1 litres / 100 km
Highway
14.7 litres / 100 km
Combined
18.9 litres / 100 km
Emission NEDC
CO₂, Combined
451 g/km

Dimensions & Weight

Exterior

Track, Front
1,651 mm (65.0 in)
Track, Rear
1,676 mm (66.0 in)
Turning Circle
11.9 m
Ground Clearance
272 mm (10.7 in)

Interior

Head Room, Front
1,034 mm (40.7 in)
Head Room, Rear
1,001 mm (39.4 in)
Head Room, Third Row
950 mm (37.4 in)
Leg Room, Front
1,049 mm (41.3 in)
Leg Room, Rear
980 mm (38.6 in)
Leg Room, Third Row
693 mm (27.3 in)
Hip Room, Front
1,560 mm (61.4 in)
Hip Room, Rear
1,557 mm (61.3 in)
Hip Room, Third Row
1,250 mm (49.2 in)
Shoulder Room, Front
1,656 mm (65.2 in)
Shoulder Room, Rear
1,653 mm (65.1 in)
Shoulder Room, Third Row
1,636 mm (64.4 in)

Weight

Max Trailer Load, braked 12%
3,674 kg (8,100 lb)
Cargo Capacity
643 - 656 kg (1,418 - 1,446 lb)
Max Roof Load
75 kg (165 lb)
Weight Distribution, front
52 %
Weight Distribution, rear
48 %

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Body-on-Frame (Ladder Frame)
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Yes
Door Handles
Pull-out
Platform
General Motors Platforms
GMT Platform (GMT820)

Equipment

Other Equipment
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)
Colour
Silver

Other

Car Classification

American Classification
Full-Size SUV
European Segment
J-Segment JE-Segment
Car.info Classification
Large SUV
